  2. ATOM Baytrail QC2.0G MINI-ITX w/VGA,LVDS,DP,2GbE

ATOM Baytrail QC2.0G MINI-ITX w/VGA,LVDS,DP,2GbE

SKU: AIMB-215D-S6B1E
Brand: Advantech
https://safeconsulting.no/web/image/product.template/13128/image_1920?unique=7297a8c

kr 3 656,78 3656.78 NOK kr 3 656,78 Ekskl. mva

kr 3 656,78 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    Supermicro's ATOM Baytrail QC2.0G Mini-ITX motherboard, featuring Intel J1900, supports DDR3L memory and offers diverse connectivity, including dual GbE LAN and multiple graphics outputs. Designed for various industrial applications.

    Nøkkelfunksjoner

    • Intel J1900 Quad-Core 2.0 GHz
    • Supports Dual Display
    • Dual GbE LAN Ports
    • Mini-ITX Form Factor
    • Wide Temperature Range Operation

    Viktige bruksområder

    • Industrial Automation
    • Embedded Systems
    • Digital Signage
    • Networking Appliances

    Beskrivelse

    The Supermicro ATOM Baytrail QC2.0G Mini-ITX motherboard offers powerful performance for compact computing needs. Equipped with Intel J1900, this board supports DDR3L memory and versatile display options including VGA, LVDS, and DisplayPort. Ideal for industrial and embedded applications, it includes dual GbE LAN and multiple internal connectors. With a robust design, it operates efficiently in varying temperatures, ensuring reliability in different environments.

    Produktspesifikasjoner

    Specification Details
    Processor System
    CPUTechnology:
    • 22nm

    Model:
    • Intel J1900

    Max Speed:
    • 2.0 GHz (Quad Core)

    L2 Cache:
    • 2 MB

    BIOS
    • AMI 16 Mbit SPI
    Memory
    Technology
    • Dual Channel DDR3L 1066/1333 MHz SDRAM
    Max Capacity
    • 8 GB / 4 GB per SO-DIMM
    Socket
    • 2 x 204-pin SO-DIMM (Non-ECC)
    Graphics
    Controller
    • Intel Gen 7 Graphics Engines
    GPU FrequencyJ1900:
    • 688 MHz

    N2930:
    • 313 MHz

    VRAM
    • Shared System Memory up to 224 MB
    Display OutputsVGA:
    • Supports up to 2560 x 1600

    LVDS:
    • Supports Dual Channel 48-bit up to 1920 x 1200

    DisplayPort 1.2:
    • Supports up to 2560 x 1600

    Dual Display
    • VGA + DP1.2
    • VGA + LVDS
    • LVDS + DP1.2
    Ethernet
    Interface
    • 10/100/1000 Mbps
    Controller
    • Realtek 811E GbE LAN
    Connector
    • RJ-45 x2
    Storage
    SATAMax Data Transfer Rate:
    • 300 MB/s

    Channels:
    • 2, SATA 2

    I/O
    RearUSB:
    • 4 (3x USB 2.0, 1x USB 3.0)

    Audio:
    • 1 (Mic-in/Line-out)

    DC Jack:
    • 1 (2.5 mm)

    Internal ConnectorsUSB:
    • 4 (USB 2.0)

    Serial:
    • 6 (5x RS-232, 1x RS-232/422/485)

    Power
    Power Type
    • Single Voltage 12V DC Input
    Consumption
    • 10.17 W (Typical Load)
    Environment
    Operating Temperature
    • 0 ~ 60°C
    Non-Operating Temperature
    • -40 ~ 85°C
