[NR] All flash 1U E3.S Grace CPU Petascale Storage Server

[NR] All flash 1U E3.S Grace CPU Petascale Storage Server

SKU:

ARS-121L-NE316R

kr 65 529,60 65529.6 NOK kr 65 529,60 Ekskl. mva

kr 65 529,60 Ekskl. mva

Denne kombinasjonen eksisterer ikke.

Legg i handlekurv

Salgsbetingelser

Beskrivelsesammendrag

This server integrates a powerful NVIDIA Grace CPU Superchip for robust computing needs, designed for software-defined storage and data-intensive tasks. It includes advanced memory support and storage capabilities, making it perfect for enterprise-scale applications.

Nøkkelfunksjoner

Single NVIDIA Grace™ CPU Superchip, up to 144 Arm v9 cores, TDP 600W
Up to 960GB LPDDR onboard memory
2 PCIe 5.0 x16 FHHL slots & 1 AIOM connector (OCP 3.0 SFF Compliant)
16 Front Hot-Swap E3.S (7.5mm) NVMe drive bays
Reduntant Titanium 1600W Power Supplies

Viktige bruksområder

Software-defined Storage
In-Memory Computing
Data Intensive HPC
Private & Hybrid Cloud
NVMe Over Fabrics Solution

Beskrivelse

The [NR] All Flash 1U E3.S Grace CPU Petascale Storage Server offers high-performance computing with a single NVIDIA Grace CPU Superchip. Suitable for data intensive HPC, software-defined storage, and NVMe over fabrics solutions, it supports up to 144 Arm v9 cores and up to 960GB LPDDR5X memory. Featuring 16 front hot-swap E3.S NVMe drive bays, redundant power supplies, and comprehensive monitoring for CPU, memory, and environment.

Produktspesifikasjoner

Specification	Details
Product SKUs
SKUs	ARS-121L-NE316R
Motherboard
Installed Motherboard	Super G1SMP
Processor
CPU	Single processor(s) NVIDIA Dual 72-core CPUs on a Grace™ CPU Superchip
Note	Supports up to 600W TDP CPUs (Air Cooled)
System Memory
Memory	Slot Count: Onboard Memory Max Memory: Up to 960GB ECC LPDDR5X
On-Board Devices
Chipset	System on Chip
Input / Output
LAN	1 RJ45 1 GbE Dedicated BMC LAN port
USB	1 USB 3.0 Type-A port(Rear)
Video	1 mini-DP port
System BIOS
BIOS Type	AMI 64MB SPI Flash EEPROM
Management
Power configurations	Power-on mode for AC power recovery ACPI Power Management
PC Health Monitoring
CPU	Monitors for CPU Cores, Chipset Voltages, Memory
FAN	Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
Chassis
Form Factor	1U Rackmount
Model	CSE-SG101E3-R000NDP
Dimensions and Weight
Height	1.7" (43.6 mm)
Width	17.2" (438.4 mm)
Depth	30.4" (772.15 mm)
Package	8.82" (H) x 26.46" (W) x 43.31" (D)
Weight	Gross Weight: 66.8 lbs (30.3 kg) Net Weight: 43.6 lbs (19.8 kg)
Available Color	Silver
Front Panel
LED	HDD activity LAN1 activity LAN2 activity Power Fail LED Power status System information
Buttons	Power On/Off UID button
Expansion Slots
PCI-Express (PCIe) Configuration	*Default: 2 PCIe 5.0 x16 (in x16) FHHL slots Option A:** 1 PCIe 5.0 x16 (in x16) AIOM slot (OCP 3.0 compatible) (*Requires additional parts, please see the optional parts list for details. For more details on PCIe slot configuration options, please refer to the system callout images above.)
Drive Bays / Storage
Drive Bays Configuration	Default: Total 16 bays: 16 front hot-swap E3.S 1T NVMe drive bays
M.2	2 M.2 NVMe slots (M-key)
System Cooling
Fans	8 Removable heavy-duty 4cm Fan(s)
Power Supply
2x 1600W Redundant (1 + 1) Titanium Level (96%) power supplies	Dimension (WxHxL): 73.5 x 40 x 203 mm Input: 1000W: 100-127Vac 1000W: 100-127Vac / 50-60Hz 1600W: 200-240Vac 1600W: 200-240Vac / 50-60Hz +12V: Max: 83.3A / Min: 0A (100Vac-127Vac) Max: 83A / Min: 0A (100Vac-127Vac) Max: 133A / Min: 0A (200Vac-240Vac) 12V SB: Max: 2.1A / Min: 0A Output Type: Backplanes (gold finger) Certification: Titanium Level
Operating Environment
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
