H12DGO-6 4U AMD EPYC 7002 DELTA GEN4 PCIE 8x SXM4 A100

H12DGO-6 4U AMD EPYC 7002 DELTA GEN4 PCIE 8x SXM4 A100

SKU:	AS -4124GO-NART
Brand:	Supermicro
Produktnotat:	For denne serveren er det best å kontakte oss for å få en fullstendig validert og konfigurert modell. Du kan også legge ønskede komponenter i handlekurven, velge «betal via bankoverføring» ved utsjekk, så forsøker vi å imøtekomme dine ønsker. Vi vil konfigurere systemet ditt så nøyaktig som mulig og sende deg et oppdatert tilbud med et validert system om kort tid. Deretter kan du bestemme om du ønsker denne konfigurasjonen. Den endelige betalingsmetoden avtales når du har akseptert konfigurasjonen.

kr 133 190,02 133190.02 NOK kr 133 190,02 Ekskl. mva

kr 133 190,02 Ekskl. mva

Denne kombinasjonen eksisterer ikke.

Legg i handlekurv

Salgsbetingelser

Beskrivelsesammendrag

The Supermicro AS -4124GO-NART is engineered for superior performance in high-compute applications, offering unparalleled versatility and power efficiency.

Nøkkelfunksjoner

Supports NVIDIA® HGX™ A100 8-GPU; Highest GPU communication using NVIDIA® NVLINK™ v3.0 + NVIDIA® NVSwitch™; NICs for GPUDirect RDMA (1:1 GPU Ratio) 2. Supports HGX A100 8-GPU 40GB (HBM2) or 80GB (HBM2e) 3. Dual AMD EPYC™ 7003/7002 Series Processors (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer) 4. 8TB Registered ECC DDR4 3200MHz SDRAM in 32 DIMMs 5. 8 PCI-E 4.0 x16 via PCI-E switch; 1 PCI-E 4.0 x 16 LP and 1 PCI-E 4.0 x8 LP via CPUs; AIOM Support 6. 6 Hot-swap U.2 NVMe 2.5" drive bays (4 via PCI-E switch, 2 via CPU) Up to 10 U.2 NVMe 2.5" drives available with an optional 4 drive bays at rear of system 7. Flexible Networking via AIOM, 1 dedicated IPMI LAN Port 8. 4 Hot-swap heavy-duty cooling fans 9. 2200W (3+1) Redundant Platinum Level Power Supplies (full redundancy based on configuration and application load); 3000W (2+2) Redundant Titanium Level (96%+) Power Supply option available for upgrade
Supports NVIDIA® HGX™ A100 8-GPU; Highest GPU communication using NVIDIA® NVLINK™ v3.0 + NVIDIA® NVSwitch™; NICs for GPUDirect RDMA (1:1 GPU Ratio)
Supports HGX A100 8-GPU 40GB (HBM2) or 80GB (HBM2e)
Dual AMD EPYC™ 7003/7002 Series Processors (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
8TB Registered ECC DDR4 3200MHz SDRAM in 32 DIMMs
8 PCI-E 4.0 x16 via PCI-E switch; 1 PCI-E 4.0 x 16 LP and 1 PCI-E 4.0 x8 LP via CPUs; AIOM Support
6 Hot-swap U.2 NVMe 2.5" drive bays (4 via PCI-E switch, 2 via CPU) Up to 10 U.2 NVMe 2.5" drives available with an optional 4 drive bays at rear of system
Flexible Networking via AIOM, 1 dedicated IPMI LAN Port
4 Hot-swap heavy-duty cooling fans
2200W (3+1) Redundant Platinum Level Power Supplies (full redundancy based on configuration and application load); 3000W (2+2) Redundant Titanium Level (96%+) Power Supply option available for upgrade

Viktige bruksområder

High Performance Computing
AI / Deep Learning

Beskrivelse

The Supermicro AS -4124GO-NART server is meticulously designed to deliver exceptional performance for data-intensive and high-compute environments. Equipped with advanced GPU capabilities, this system is ideal for AI, deep learning, and high-performance computing tasks. With its robust architecture and efficient power management, the AS -4124GO-NART ensures reliable operation and scalability, making it a preferred choice for modern data centers.

Produktspesifikasjoner

Specification	Details
Product SKUs
AS -4124GO-NART	A+ Server 4124GO-NART
Motherboard
Installed Motherboard	Super H12DGO-6
Processor/Cache
CPU	Dual AMD EPYC™ 7003/7002 Series Processors(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer) Socket SP3 Supports CPU TDP up to 280W*
Cores	Up to 128 Cores (64 per CPU)
Note	* Certain CPUs with high TDP may be supported only under specific conditions. Please contact Safe Consulting Technical Support for additional information about specialized system optimization
GPU
Supported GPUs	HGX A100 8-GPU 40GB/80GB SXM4 Multi-GPU Board
CPU-GPU Interconnect	PCI-E Gen 4 x16 Switch CPU-to-GPU Interconnect
GPU-GPU Interconnect	NVIDIA® NVLink™ with NVSwitch™ GPU-GPU Interconnect
System Memory
Memory Capacity	32 DIMM slots Up to 8TB 3DS ECC DDR4-3200MH RDIMM/LRDIMM
Memory Type	3200MHz ECC DDR4 RDIMM/LRDIMM
On-Board Devices
Chipset	System on Chip (SoC)
SATA	SATA3 (6Gbps)
Network Controllers	Provided via AIOM
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Graphics	ASPEED AST2600 BMC
Input / Output
SATA	4 SATA3 (6Gbps) ports
LAN	Provided by AIOM 1 RJ45 Dedicated IPMI LAN port
USB	2 USB 3.0 ports (front)
Video	1 VGA Connector (front)
COM Port	1 COM port (header)
System BIOS
BIOS Type	AMI 256Mb SPI Flash ROM
Management
Software	IPMI 2.0 KVM with dedicated LAN SSM , SPM , SUM SuperDoctor® 5 Watchdog
PC Health Monitoring
CPU	Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator
FAN	Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
Chassis
Form Factor	4U Rackmountable Rackmount Kit (MCP-290-00180-0N)
Model	CSE-438G
Dimensions
Height	6.9" (174mm)
Width	17.6" (446mm)
Depth	35.4" (900mm)
Package	29.5" (750mm) H x 27.4" (695mm) W x 44.9" (1140mm) D
Weight	Net Weight: 166.0 lbs (75.3 kg) Gross Weight: 225.0 lbs (102.1 kg)
Drive Bays / Storage
Hot-swap	6 hot-swap U.2 NVMe 2.5" drive bays (4 via PCI-E switch, 2 via CPU, SATA/NVMe Hybrid or SAS with optional HBA)(up to 10 hot-swap U.2 NVMe 2.5" available)
M.2	2 M.2 NVMe
Expansion Slots
PCI-Express	8 PCI-E 4.0 x16 via PCI-E switch - supporting HGX A100 8-GPU's 1:1 connection to 8 NICs 1 PCI-E 4.0 x16 LP and 1 PCI-E 4.0 x8 LP via CPUs
System Cooling
Fans	4 x Hot-swap 11.5K RPM heavy duty fans
Power Supply
2200W Redundant Platinum Level Power Supplies
Total Output Power	1000W with Input 100 - 127Vac 2200W with Input 220 - 240Vac (for UL/cUL only) 2090W with Input 230 - 240Vdc (for CQC only)
Dimension(W x H x L)	106.5 x 82.4 x 203.5 mm
Input	1000W: 100-127 Vac / 12-9.5 A / 50-60 Hz 1800W: 200-220 Vac / 10-9.5 A / 50-60 Hz 1980W: 220-230 Vac / 10-9.5 A / 50-60 Hz 2090W: 230-240 Vac / 10-9.8 A / 50-60 Hz 2200W: 220-240 Vac / 11.8-9.6 A / 50-60 Hz (for UL/cUL only) 2090W: 230-240 Vdc / 10-9.8 A / 50-60 Hz (for CQC only)
+12V	Max: 41.67A / Min: 0A (500W)
+54V	Max: 18.5A / Min: 0A (1000W) Max: 33.33A / Min: 0A (1800W) Max: 36.6A / Min: 0A (1980W) Max: 38.7A / Min: 0A (2090W) Max: 40.74A / Min: 0A (2200W)
12Vsb	Max: 3A / Min: 0A
Output Type	Gold Finger (connector on M/P)
Certification	Platinum Certified
Operating Environment
RoHS	RoHS Compliant
Environmental Spec.	Operating Temperature:10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature:-40°C to 60°C (-40°F to 140°F) Operating Relative Humidity:8% to 90% (non-condensing) Non-operating Relative Humidity:5% to 95% (non-condensing)

Valgfrie Opsjoner

Part Number	Quantity	Description
GPU Baseboard(s)*
GPU-NVTHGX-A100-SXM4-88D	-	NVIDIA Air Cool DELTA HGX GPU Baseboard, 8 A100 80GB
Backplane
BPN-NVME4-HS119N-S4R	-	1U 4-Slot SFF Backplane Supports 4 x SAS3/SATA3/NVMe4 Storage Devices,HF,RoHS
Cable(s)
CBL-PWEX-1133-35	-	(MicroHi to MicroFit) 2x2,PH3.0, 35cm,10A/pin,16AWG,RoHS
Network Card(s)
AOC-613106A-VDAT	-	Mellanox MCX613106A-VDAT PCIe 2-port 200GbE QSFP56 Gen4x16 CX-6. HF, RoHS.
AIOM Dummy Cover
MCP-240-00194-0N	-	S-AIOM 2x2 Dummy Cover
RAID Card(s)
AOC-S3008L-L8I	-	8 int 12Gb/s ports, 8xGen3, IOC/IR mode - LP
Thin Profile Drive
MCP-220-00178-0B	-	2.5" thin profile drive tray, Orange tab (for hotswap NVMe drive), for SC119UH
TPM security module
AOM-TPM-9665V	-	TPM 2.0 module with Infineon 9665, RoHS/REACH,PBF;
Global Services & Support
OS4HR3/2/1	-	3/2/1-year onsite 24x7x4 service
OSNBD3/2/1	-	3/2/1-year onsite NBD service
