  2. CSE-126E32-R1K62P; H13SSF

CSE-126E32-R1K62P; H13SSF

SKU: ASG-1115S-NE316R
Brand: Supermicro
Produktnotat:

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with 1 CPU, Min. of 4 DIMMs, 1 AIOM/AOC NIC, 1 Storage Device and 1 Server-Grade M.2)

For denne serveren er det best å kontakte oss for å få en fullstendig validert og konfigurert modell. Du kan også legge ønskede komponenter i handlekurven, velge «betal via bankoverføring» ved utsjekk, så forsøker vi å imøtekomme dine ønsker. Vi vil konfigurere systemet ditt så nøyaktig som mulig og sende deg et oppdatert tilbud med et validert system om kort tid. Deretter kan du bestemme om du ønsker denne konfigurasjonen. Den endelige betalingsmetoden avtales når du har akseptert konfigurasjonen.

https://safeconsulting.no/web/image/product.template/10686/image_1920?unique=dab50a2

kr 41 799,56 41799.56 NOK kr 41 799,56 Ekskl. mva

kr 41 799,56 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    The Supermicro ASG-1115S-NE316R offers robust performance with a single Socket SP5 AMD EPYC™ 9004 Series processor, supports up to 6TB of DDR5 ECC memory, and features 16x hot-swap NVMe drive bays. Ideal for private & hybrid cloud and NVMe over Fabrics solutions.

    Nøkkelfunksjoner

    • Single Socket SP5 AMD EPYC™ 9004 Series processors. Up to 300W TDP.
    • Supports 24 DIMMs with 2DPC, up to 6TB memory capacity with 24 DIMMs of 256GB 3DS RDIMM/RDIMM DDR5 ECC memory
    • Two PCIe 5.0 x16 slots & two AIOM connectors (OCP 3.0 SFF compliant)
    • 16x hot-swap E3.S (7.5mm) NVMe drive bays
    • Redundant Titanium 1600W Power Supplies

    Viktige bruksområder

    • Software-defined Storage
    • In-Memory Computing
    • Data Intensive HPC
    • Private & Hybrid Cloud
    • NVMe Over Fabrics Solution

    Beskrivelse

    Built for versatility and high-performance, the Supermicro ASG-1115S-NE316R server is equipped with a single Socket SP5 AMD EPYC™ 9004 Series processor, capable of handling up to 96 cores and 192 threads. This server supports 24 DDR5 DIMM slots, allowing up to 6TB of memory. It also features 16 front hot-swap E3.S NVMe drive bays for fast storage and data access. Additional highlights include two PCIe 5.0 x16 slots, dual AIOM connectors, and redundant Titanium 1600W power supplies. The ASG-1115S-NE316R is designed to meet the demands of software-defined storage, in-memory computing, data-intensive HPC, private & hybrid cloud environments, and NVMe over Fabrics solutions.

    Produktspesifikasjoner

    Specification Details
    Product SKUs
    SKUs
    • A+ Server ASG-1115S-NE316R
    Motherboard
    Installed Motherboard
    • Super H13SSF
    Processor
    CPU
    • Single Socket SP5
    • AMD EPYC™ 9004 Series Processors
    Core Count
    • Up to 96C/192T
    Note
    • Supports 200W - 300W TDP CPUs (Air Cooled)
    System Memory
    Memory
    • Slot Count: 24 DIMM slots
    • Max Memory (2DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM/LRDIMM
    Memory Voltage
    • 1.1V
    On-Board Devices
    Chipset
    • AMD System on Chip
    Network Connectivity
    • Via AIOM
    Input / Output
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port(s)
    USB
    • 2 USB 3.0 port(s) (rear)
    • 2 USB 3.0 port(s) (front)
    Video
    • 1 VGA port(s)
    System BIOS
    BIOS Type
    • AMI 32MB SPI Flash EEPROM
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • Power-on mode for AC power recovery
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    PC Health Monitoring
    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory
    • 4+1 Phase-switching voltage regulator
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors
    Voltage
    • +1.8V, +12V, +3.3V, +5V, +5V standby, 10 -fan status, 3.3V standby, HT, Memory, VBAT
    Chassis
    Form Factor
    • 1U Rackmount
    Model
    • CSE-126E32-R1K62P
    Dimensions and Weight
    Height
    • 1.7" (43.6 mm)
    Width
    • 17.2" (438.4 mm)
    Depth
    • 30.4" (773.25 mm)
    Package
    • 7.87" (H) x 23.81" (W) x 40.55" (D)
    Weight
    • Gross Weight: 68.74 lbs (31.2 kg)
    • Net Weight: 48 lbs (21.8 kg)
    Available Color
    • Silver
    Front Panel
    LED
    • Network activity
    • Power status
    • SSD activity
    • System information (overheat/UID)
    Buttons
    • Power On/Off
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 2 PCIe 5.0 x16 FHHL slots
    • 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

    M.2
    • 2 M.2 PCIe 3.0 x2 NVMe slots (M-key 2280/22110)
    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 16 bays:
    • 16 front hot-swap E3.S 1T NVMe drive bays

    M.2
    • 2 M.2 NVMe slots (M-key 2280/22110)
    System Cooling
    Fans
    • 8 Heavy Duty 4cm Fan(s)
    Power Supply
    1x 1600W Redundant Titanium Level (96%) power supply
    Dimension (WxHxL):
    • 73.5 x 40 x 203 mm

    AC Input:
    • 1000W: 100-127Vac / 50-60Hz
    • 1600W: 200-240Vac / 50-60Hz

    +12V:
    • Max: 83.3A / Min: 0A (100Vac-127Vac)
    • Max: 133A / Min: 0A (200Vac-240Vac)

    12V SB:
    • Max: 2.1A / Min: 0A

    Output Type:
    • Backplanes (gold finger)

    Certification:
    • Titanium Level

    Operating Environment
    ROHS
    • RoHS Compliant
    Environmental Spec.
    • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity: 8% to 90% (Non-condensing)
    • Non-operating Relative Humidity: 8% to 95% (Non-condensing)
    Environmental / Recycling
    Recycle
    • Return Server-End of Life Product

    Valgfrie Opsjoner

    Part Number Quantity Description
    Network Cards
    AOC-S25G-M2S-Standard LP, 2x 25GbE SFP28, Mellanox ConnectX-4 LX EN
    AOC-S40G-I2Q-Standard LP 2-port 40GbE controller, Intel Fortville XL710
    AOC-SGP-I2-Standard LP 2-port GbE, Intel 82575
    More-AOC Compatibility Matrix (Select Storage & Generation)
    Power Cord
    CBL-PWCD-0579-Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V
    CBL-PWCD-0300-IS-PWCD,US,IEC60320 C14 TO C13,6FT,18AWG,RoHS/REACH
    CBL-PWCD-0579-1-Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V
    TPM
    AOM-TPM-9670V-O1TPM 2.0, vertical form factor, provisioned for server
    AOM-TPM-9671V-O1TPM 1.2, vertical form factor, provisioned for server
