CSE-236E3-R2K08P ; H13SSF

SKU: ASG-2115S-NE332R
Brand: Supermicro
Produktnotat:

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with 1 CPU, Min. of 4 DIMMs, 1 AIOM/AOC NIC, 1 Storage Device and 1 Server-Grade M.2/rear SATA SSD)

For denne serveren er det best å kontakte oss for å få en fullstendig validert og konfigurert modell. Du kan også legge ønskede komponenter i handlekurven, velge «betal via bankoverføring» ved utsjekk, så forsøker vi å imøtekomme dine ønsker. Vi vil konfigurere systemet ditt så nøyaktig som mulig og sende deg et oppdatert tilbud med et validert system om kort tid. Deretter kan du bestemme om du ønsker denne konfigurasjonen. Den endelige betalingsmetoden avtales når du har akseptert konfigurasjonen.

https://safeconsulting.no/web/image/product.template/10687/image_1920?unique=87ba323

kr 52 678,08 52678.08 NOK kr 52 678,08 Ekskl. mva

kr 52 678,08 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    The Supermicro ASG-2115S-NE332R is built for extreme performance and versatility, supporting up to 6TB DDR5 ECC memory and multiple high-speed NVMe drives. Ideal for software-defined storage, in-memory computing, and hybrid cloud solutions.

    Nøkkelfunksjoner

    • Single Socket SP5 AMD EPYC™ 9004 Series processors. Up to 360W TDP.
    • Supports 24 DIMMs with 2DPC, up to 6TB memory capacity with 24 DIMMs of 256GB 3DS RDIMM/RDIMM DDR5 ECC memory
    • Two PCIe 5.0 x16 slots & two AIOM connectors (OCP 3.0 SFF compliant)
    • 32x hot-swap E3.S (7.5mm) NVMe drive bays
    • Redundant Titanium 2000W Power Supplies

    Viktige bruksområder

    • Software-defined Storage
    • In-Memory Computing
    • Data Intensive HPC
    • Private & Hybrid Cloud
    • NVMe Over Fabrics Solution

    Beskrivelse

    The Supermicro ASG-2115S-NE332R is a powerful 2U rackmount server designed to handle extreme computational loads. It features a single socket SP5 AMD EPYC™ 9004 Series processor, capable of supporting up to 360W TDP. The server can accommodate up to 6TB of DDR5 ECC memory through its 24 DIMM slots, and offers exceptional storage capabilities with 32 hot-swap E3.S NVMe drive bays. Connectivity options include two PCIe 5.0 x16 slots and two AIOM connectors compliant with OCP 3.0 SFF standards. Additional features include redundant 2000W Titanium power supplies, comprehensive security measures, and robust management software, making it an excellent choice for data-intensive applications.

    Produktspesifikasjoner

    Specification Details
    Product SKUs
    SKUs
    • A+ Server ASG-2115S-NE332R
    Motherboard
    Installed Motherboard
    • Super H13SSF
    Processor
    CPU
    • Single Socket SP5
    • AMD EPYC™ 9004 Series Processors
    Note
    • Supports 200W - 360W TDP CPUs (Air Cooled)
    System Memory
    Memory
    • Slot Count: 24 DIMM slots
    • Max Memory (1DPC): Up to 4TB 4800MT/s ECC DDR5 RDIMM/LRDIMM
    • Max Memory (2DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM/LRDIMM
    Memory Voltage
    • 1.1V
    On-Board Devices
    Chipset
    • AMD System on Chip
    Network Connectivity
    • Via AIOM
    Input / Output
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port(s)
    USB
    • 2 USB 3.0 port(s) (rear)
    • 2 USB 3.0 port(s) (front)
    Video
    • 1 VGA port(s)
    System BIOS
    BIOS Type
    • AMI 32MB SPI Flash EEPROM
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • Power-on mode for AC power recovery
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    PC Health Monitoring
    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory
    • 4+1 Phase-switching voltage regulator
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors
    Voltage
    • +1.8V, +12V, +3.3V, +5V, +5V standby, 10 -fan status, 3.3V standby, HT, Memory, VBAT
    Chassis
    Form Factor
    • 2U Rackmount
    Model
    • CSE-236E3-R2K08P
    Dimensions and Weight
    Height
    • 3.5" (89.8 mm)
    Width
    • 17.2" (438.4 mm)
    Depth
    • 30.8" (789.9 mm)
    Package
    • 10" (H) x 26.5" (W) x 43.25" (D)
    Weight
    • Gross Weight: 77 lbs (34.93 kg)
    • Net Weight: 55 lbs (24.95 kg)
    Available Color
    • Silver
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 2 PCIe 5.0 x16 FHHL slots
    • 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

    M.2
    • 2 M.2 PCIe 3.0 x2 NVMe slots (M-key 2280/22110)
    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 34 bays:
    • 32 front hot-swap E3.S 1T NVMe drive bays
    • 2 rear hot-swap 2.5" SATA drive bays

    M.2
    • 2 M.2 NVMe slots (M-key 2280/22110)
    System Cooling
    Fans
    • 4 Heavy Duty 8cm Fan(s)
    Power Supply
    1x 2000W Redundant Titanium Level (96%) power supply
    Dimension (WxHxL):
    • 73.5 x 40 x 203 mm

    AC Input:
    • 1000W: 100-127Vac / 50-60Hz
    • 1800W: 200-220Vac / 50-60Hz
    • 1980W: 220-230Vac / 50-60Hz
    • 2000W: 220-240Vac / 50-60Hz (for UL only)
    • 2000W: 230-240Vac / 50-60Hz
    • 2000W: 230-240Vdc / 50-60Hz (for China only)

    +12V:
    • Max: 83A / Min: 0A (100Vac-127Vac)
    • Max: 150A / Min: 0A (200Vac-220Vac)
    • Max: 165A / Min: 0A (220Vac-230Vac)
    • Max: 166A / Min: 0A (230Vac-240Vac)

    12V SB:
    • Max: 3.5A

    Output Type:
    • Backplanes (gold finger)

    Operating Environment
    ROHS
    • RoHS Compliant
    Environmental Spec.
    • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity: 8% to 90% (Non-Condensing)
    • Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
    Environmental / Recycling
    Recycle
    • Return Server-End of Life Product

    Valgfrie Opsjoner

    Part Number Quantity Description
    Network Cards
    AOC-S25G-M2S-Standard LP, 2x 25GbE SFP28, Mellanox ConnectX-4 LX EN
    AOC-S40G-I2Q-Standard LP 2-port 40GbE controller, Intel Fortville XL710
    AOC-SGP-I2-Standard LP 2-port GbE, Intel 82575
    More-AOC Compatibility Matrix (Select Storage & Generation)
    Power Cord
    CBL-PWCD-0579-Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V
    CBL-PWCD-0300-IS-PWCD,US,IEC60320 C14 TO C13,6FT,18AWG,RoHS/REACH
    CBL-PWCD-0579-1-Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V
    TPM
    AOM-TPM-9670V-O1TPM 2.0, vertical form factor, provisioned for server
    AOM-TPM-9671V-O1TPM 1.2, vertical form factor, provisioned for server
