Ethernet to Multi mode Fiber Media converter

Ethernet to Multi mode Fiber Media converter

SKU:	EKI-2541M-BE
Brand:	Advantech

kr 1 992,74 1992.74 NOK kr 1 992,74 Ekskl. mva

kr 1 992,74 Ekskl. mva

Denne kombinasjonen eksisterer ikke.

Legg i handlekurv

Salgsbetingelser

Beskrivelsesammendrag

The EKI-2541M-BE is an industrial-grade Ethernet to Multi Mode Fiber Media Converter designed for rugged environments. It provides advanced features such as Link Fault Pass-Through and supports full/half duplex flow control.

Nøkkelfunksjoner

1 x 10/100 Mbps Ethernet RJ45
100 Mbps Multi-Mode SC fiber
Link Fault Pass-Through
Full/Half Duplex Flow Control
Store and Forward Transmission
Auto-negotiation
MDI/MDI-X Auto Crossover
Redundant Power Input
DIN-rail and Panel Mounting

Beskrivelse

The EKI-2541M-BE is a robust Ethernet to Multi Mode Fiber Media Converter providing a high-speed network connection with a redundant power supply. It offers an easy mounting format suitable for harsh industrial setups. This device is equipped with advanced transmission and auto-negotiation functionalities to ensure reliable and efficient data communication.

Produktspesifikasjoner

Specification	Details
Power
Power Input (DC)	12 ~ 48 VDC, redundant dual inputs
Interface
Port Number	2
Environment
Operating Temperature	-10 ~ 60°C (14 ~ 140°F)
Storage Temperature	-40 ~ 85°C (-40 ~ 185°F)
Mechanism
Dimensions (W x H x D)	30 x 140 x 95 mm (1.18' x 5.51' x 3.74 in.)
IP Rating	IP30
Mounting	DIN-rail, Wall mount
Ethernet Communication
Fiber Port Interface	Multi-Mode
Fiber Transmission Distance	30 km
Fiber Transmission Speed	100 Mbps
RJ-45 Port Connector Type	1 x RJ-45 and 1 x SFP type fiber connector
RJ-45 Transmission Distance	Up to 100 m
RJ-45 Transmission Speed	100 Mbps
Certification
EMI	FCC Part 15 Subpart B Class A, EN 55022 Class A
EMS	EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8
Safety	UL 60950-1, CAN/CSA-C22.2 No.60950
