    Summary Description

    The Supermicro MBD-X12SCZ-QF-B motherboard supports 11th/10th Gen Intel Core i9/i7/i5/i3/Pentium/Celeron processors, featuring Intel Q470E chipset, 4 DIMM slots up to 128GB DDR4-2933MHz, and advanced LAN, RAID, and video output options.

    Key Features

    • 11th/10th Generation Intel® Core™ i9/Core™ i7/Core™i5/Core™i3/Pentium®/Celeron® ProcessorSingle Socket LGA-1200 (Socket H5) supported, CPU TDP support Up to 125W TDP
    • Intel® Q470E
    • Up to 128GB Unbuffered non-ECC UDIMM, DDR4-2933MHz, in 4 DIMM slots
    • 1 PCIe 3.0 x16,1 PCIe 3.0 x4 (in x8 slot),1 PCIe 3.0 x41 M.2 M-Key SATA/PCIe 3.0 x4, 2280/221101 M.2 E-Key CNVi/PCIe 3.0 x1, 2230
    • Single LAN with Intel® PHY I219LM LAN controllerSingle LAN with Intel® Ethernet Controller I210-AT
    • Intel® Q470E controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
    • 1 VGA D-Sub Connector port, 2 DP++(Dual-Mode DisplayPort) ports, 1 DVI - D port

    Key Applications

    • High-performance computing
    • Advanced gaming systems
    • Workstation setup
    • Multimedia production
    • Server management
    • Industrial automation
    • Business applications
    • Educational uses
    • Research and development

    Description

    The Supermicro MBD-X12SCZ-QF-B is a Micro-ATX motherboard designed to deliver top-tier performance and reliability for a variety of applications. With support for 11th/10th Generation Intel Core i9/i7/i5/i3/Pentium/Celeron processors and CPU TDP up to 125W, this motherboard is equipped with the Intel Q470E chipset. It offers up to 128GB DDR4 RAM across 4 DIMM slots, extensive I/O ports including VGA, dual-mode DP++, DVI, numerous USB ports, SATA3, and PCIe slots. It also integrates high-quality audio, IPMI, and dual LAN capabilities. The board is suitable for demanding environments with extensive health monitoring features, secure boot, cryptographically signed firmware, and system management software.

    Product Specifications

    Specification Details
    Product SKUs
    SKUs
    • MBD-X12SCZ-QF
    Physical Stats
    Form Factor
    • Micro-ATX
    Dimension
    • 9.6" x 9.6" (24.38cm x 24.38cm)
    Processor
    CPU
    • 11th/10th Generation Intel® Core™ i9/Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processor
    • Single Socket Socket H5 (LGA-1200) supported, CPU TDP supports Up to 125W TDP
    • A graphic integrated CPU is required to have onboard video from the DVI and DP ports
    Core
    • Up to 10 cores
    Note
    • ** Motherboard supports this maximum TDP. Please verify your system can thermally support.**The X12SCZ does not support the Intel 10th/11th generation processor 2M cache SKUs. These processors will not boot with the latest BIOS version.
    System Memory
    Memory Capacity
    • 4 DIMM slots
    • Up to 128GB Unbuffered non-ECC UDIMM, DDR4-2933MT/s
    Memory Type
    • 2933/2666/2400/2133 MT/s
    DIMM Sizes
    • 4GB, 8GB, 16GB, 32GB
    Memory Voltage
    • 1.2V
    On-Board Devices
    Chipset
    • Intel® Q470E
    SATA
    • Intel® Q470E controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
    IPMI
    • ASPEED AST2500 BMC
    Audio
    • ALC 888S HD Audio
    Graphics
    • 1 Intel® HD Graphics port(s)
    • 1 ASPEED AST2500 BMC port(s)
    Network Controllers
    • Single LAN with Intel® PHY I219LM LAN controller
    • Single LAN with Intel® Ethernet Controller I210-AT
    Input / Output
    SATA
    • 4 SATA3 (6Gbps) port(s)
    LAN
    • 2 RJ45 Gigabit Ethernet LAN ports
    USB
    • 6 USB 3.2 Gen2 port(s) (4 rear type A; 2 via header)
    • 6 USB 2.0 port(s) (6 via header)
    Video Output
    • 1 DVI - D port(s), 1 VGA D-Sub Connector port(s), 2 DP++(Dual-Mode DisplayPort) port(s)
    Serial Port
    • 1 COM Port(s) (1 header)
    DOM
    • 1 SATADOM(Disk on Module) power connector support
    TPM
    • 1 TPM TPM 2.0 onboard
    Expansion Slots
    PCIe
    • 1 PCIe 3.0 x4,
    • 1 PCIe 3.0 x16,
    • 1 PCIe 3.0 x4 (in x8 slot)
    M.2
    • M.2 Interface: 1 SATA/PCIe 3.0 x4; 1 CNVi/PCIe 3.0 x1
    • Form Factor: 2280/22110, 2230
    • Key: M-Key, E-Key
    System BIOS
    BIOS Type
    • AMI UEFI
    BIOS Features
    • ACPI 6.1
    • SMBIOS 3.1
    • PCI FW 3.0
    • UEFI 2.6
    • RTC (Real Time Clock) Wakeup
    Management
    Software
    • Redfish API,Supermicro SuperDoctor® 5 (SD5),Super Diagnostics Offline (SDO),KVM with dedicated LAN,IPMI 2.0
    System Management Software
    • IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
    Power Configurations
    • ACPI Power Management, ATX Power connector, +12V DC Power Input
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • System Lockdown
    PC Health Monitoring
    Voltage
    • VBAT, Memory, CPU, Chassis intrusion header, 5 -fan status, 1.2V (VDIMM), 1.05 (PCH), +5V standby, +5V, +3.3V, +12V
    LED
    • UID/Remote UID
    • Power LED
    • BMC/IPMI Heartbeat LED
    Temperature
    • Thermal Control for 5 Fan Connectors
    FAN
    • 5x 4-pin fan headers (up to 5 fans)
    • Fan speed control
    • Dual Cooling Zone
    • 5 fans with tachometer status monitoring
    Other Features
    • UID, RoHS, M.2 NGFF connector, Dual Cooling Zones, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, 12V DC or ATX Power Source
    Operating Environment
    Operating Temperature Range
    • 0°C - 60°C (32°F - 140°F)
    Non-Operating Temperature Range
    • -40°C - 85°C (-40°F - 185°F)
    Operating Relative Humidity Range
    • 10% - 85% (non-condensing)
    Non Operating Relative Humidity Range
    • 5% - 95% (non-condensing)

    Standard Part List

    Part Number Quantity Description
    Bulk Package
    I/O Cables
    CBL-0044L257.5CM SATA FLAT S-S PBF
    I/O Shield
    MCP-260-00093-0N1Standard I/O Shield for X12SCZ with EMI Gasket
    Retail Package
    I/O Cables
    CBL-0044L457.5CM SATA FLAT S-S PBF
    I/O Shield
    MCP-260-00093-0N1Standard I/O Shield for X12SCZ with EMI Gasket
    QRG
    MNL-2257-QRG1Motherboard Quick Reference Guide

    Optional Part List

    Part Number Quantity Description
    1U I/O Shield
    MCP-260-00094-0N-1U I/O Shield for X12SCZ with EMI Gasket in CSE-512/813
    4U CPU Heat Sink for Socket H(optional, not included)
    SNK-P0051AP4.-4U Active CPU Heat Sink
    USB3.1 Cable
    CBL-CUSB-0835-Dual USB3.1 Type A Cable with Bracket
