Name: X13 SSG 2U 16 Bay: X13DEI-T, CSE-829HTS-R1K62LPBP2, S391
Brand: supermicro
SKU: SSG-621E-ACR16H
Price: 43154.67 NOK
Availability: OutOfStock

SKU:

SSG-621E-ACR16H

Product Note:

For this server, it's best to contact us for a fully validated, configured model. You can also add desired components to your cart, select "pay by bank transfer" at checkout, and we'll try to fulfill your wishes. We'll configure your system as closely as possible and send an updated quote with a validated system shortly. You can then decide if you want this configuration. The final payment method will be agreed upon after you accept the configuration.

kr 43 154,67 43154.67 NOK kr 43 154,67

kr 43 154,67

Denne kombinasjonen eksisterer ikke.

Legg i handlekurv

Terms and Conditions

Summary Description

The Supermicro SSG-621E-ACR16H is a powerful and versatile 2U rackmount server designed for enterprise environments. It supports dual-socket E 5th/4th Gen Intel Xeon Scalable processors and up to 4TB of DDR5 memory across 16 DIMM slots. The server offers flexible storage configurations with 16x 3.5"/2.5" hot-swap SAS3/SATA3 drives and multiple on-board devices for networking and management. Designed for high performance and reliability, it includes features like redundant power supplies and advanced hardware RAID support.

Key Features

Dual Socket E (LGA-4677) 5th/4th Gen Intel® Xeon® Scalable processors
Up to 4TB 3DS ECC RDIMM, DDR5-5600MT/s(1DPC) in 16 DIMM slots
2x 10 GbE onboard via Broadcom BCM574161x GbE Dedicated LAN for server remote management: IPMI 2.0 / KVM over LAN / Media over LAN
16x 3.5"/2.5" Hot-swap SAS3/SATA3 drives, 2x Rear 2.5" SATA Slots, 2x NVMe M.2 (form factor: 2280 and 22110)
4x 8cm hot-swap counter-rotate redundant PWM cooling fans
1600W Redundant Power Supplies Titanium Level (96%)
HW RAID support via Broadcom® 3916

Key Applications

Enterprise Server
iSCSI SAN
HPC, Data Center
Database Processing & Storage
Corporate Database
Appliance Optimized Storage Building Blocks

Description

The Supermicro SSG-621E-ACR16H is a 2U rackmount server that provides exceptional performance and versatility for enterprise workloads. It features dual-socket E (LGA-4677) support for 5th/4th Gen Intel Xeon Scalable processors, accommodating up to 4TB of DDR5-5600MT/s ECC RDIMM memory across 16 DIMM slots. Storage capabilities are robust, with 16x 3.5"/2.5" hot-swap SAS3/SATA3 drives, 2x rear 2.5" SATA slots, and 2x NVMe M.2 slots. Networking is powered by dual 10G Base-T ports and a dedicated IPMI LAN port for comprehensive remote management. The server is equipped with redundant 1600W Titanium Level power supplies and cooling via 4x 8cm hot-swap PWM fans. Security features include TPM 2.0, Silicon Root of Trust, and cryptographically signed firmware. The system's dimensions are 3.5" x 17.2" x 27.75", and it weighs 41.5 lbs net.

Product Specifications

Specification	Details
Product SKUs
SKUs	SuperServer SSG-621E-ACR16H
Motherboard
Installed Motherboard	Super X13DEI-T
Processor
CPU	Dual Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
Note	Supports up to 270W TDP CPUs (Air Cooled)
System Memory
Memory	Slot Count: 16 DIMM slots Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM
Memory Voltage	1.1V
On-Board Devices
Chipset	Intel® C741
Network Connectivity	2 RJ45 10GbE with Broadcom® BCM57416
Input / Output
LAN	1 RJ45 1 GbE Dedicated BMC LAN port(s) 2 RJ45 10 GbE LAN port(s) (Broadcom® BCM57416) (IPMI shared on LAN port 1)
USB	4 USB 3.0 port(s) (rear)
Video	1 VGA port(s) (Rear)
Serial	1 COM port(s) (Rear)
TPM	1 TPM header
System BIOS
BIOS Type	AMI 32MB SPI Flash EEPROM
Management
Software	SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New!
Power configurations	Power-on mode for AC power recovery ACPI Power Management
Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown
PC Health Monitoring
CPU	Monitors for CPU Cores, Chipset Voltages, Memory 7+1 Phase-switching voltage regulator
FAN	Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
Chassis
Form Factor	2U Rackmount
Model	CSE-829HTS-R1K62LPBP2
Dimensions and Weight
Height	3.5" (89 mm)
Width	17.2" (437 mm)
Depth	27.75" (705 mm)
Package	10.8" (H) x 25.9" (W) x 39.3" (D)
Weight	Gross Weight: 62 lbs (28.12 kg) Net Weight: 41.5 lbs (18.82 kg)
Available Color	Silver
Front Panel
LED	HDD Fail LED Network Activity LEDs Power Fail LED Power status LED System Information LED
Buttons	Power On/Off button System Reset button
Expansion Slots
PCI-Express (PCIe) Configuration	Default: 4 PCIe 5.0 x16 (in x16) LP slots 2 PCIe 5.0 x8 (in x8) LP slots
Drive Bays / Storage
Drive Bays Configuration	Default: Total 18 bays: 12 front hot-swap 3.5" SAS/SATA drive bays 4 internal hot-swap 3.5" SAS/SATA drive bays 2 rear hot-swap 2.5" SATA drive bays Option A: Total 6 bays: 6 front hot-swap 3.5" PCIe 5.0 x4 NVMe* drive bays (*NVMe support may require additional storage controller and/or cables, please see the optional parts list for details)
M.2	2 M.2 PCIe 4.0 x2 NVMe slots (M-key 2280/22110)
System Cooling
Fans	4 Heavy Duty 8cm Fan(s)
Power Supply
2x 1600W Redundant Titanium Level (96%) Hot-plug power supplies	Dimension (WxHxL): 73.5 x 40 x 203 mm AC Input: 1000W: 100-127Vac / 50-60Hz 1600W: 200-240Vac / 50-60Hz +12V: Max: 83.3A / Min: 0A (100Vac-127Vac) Max: 133A / Min: 0A (200Vac-240Vac) 12V SB: Max: 2.1A / Min: 0A Output Type: Backplanes (gold finger) Certification: Titanium Level
Operating Environment
ROHS	RoHS Compliant
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (Non-Condensing) Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
General
Standard Parts (Parts Included)

Standard Part List

Part Number	Quantity	Description
Motherboard / Chassis
MBD-X13DEI-T	1	Super X13DEI-T Motherboard
CSE-829HTS-R1K62LPBP2	1	2U Chassis
Add-on Card / Module
AOC-S3916L-H16IR-32DD-O	1	16 int 12Gb/s ports, x8 Gen4, ROC - LP, 32HDDw/exp,RoHS
Backplane
BPN-NVME5-LA26A-S12	1	2U 12-Slot 3.5" SATA3/SAS3/NVMe5 Hybrid Backplane X13 Cl
BPN-SAS3-829HA-A4	1	4-Port 12Gbps Backplane for 4x3.5" Internal SAS3/SATA3 HDD/S
Cable
CBL-0277L	1	HDD POWER CABLE (BIG 4 PIN; 32CM), PBF
CBL-CDAT-0728	1	4 Pin to 4 Pin I2C Cable, 65cm, 26AWG, 4 Wires, Pinout 1-1
CBL-SAST-1250A-100	1	SlimSAS (x8 ST to x4 STR and miniS)80/50CM,100OHM,RoHS
CBL-SAST-1281-100	1	Slimline x8 (STR) to 2x Slimline x4 (STR),80CM,100 OHM,
CBL-CDAT-0607	1	[NR] FRONT CNTL,20 TO 20 PIN, P0.5, FFC,FLAT, 23.5CM, STD,Ro
CBL-CDAT-0921-85	1	[NR] I2C,(1x4F to 1x4F)/P2.5,85CM,26AWG,RoHS
CBL-PWCD-0160-IS	2	PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,16AWG,RoHS/REACH
CBL-PWEX-1078	4	PWEX,FAN,1X4/P2.5 TO 1X4/P2.54,20CM,22AWG,5A/PIN,RoHS
Parts
MCP-260-00042-3N	1	STD I/O shield for X13 server MB with venting holes
Air Shroud
MCP-310-82619-0B	1	Sponge air Block sets for CSE-826B and LA26-AW
Software
SFT-OOB-LIC	1	License key for enabling OOB BIOS management
Heatsink / Retention
SNK-P0087V	1	1U Passive CPU VC HS for X13 Intel Eagle Stream Platform
SNK-P0088AP4	1	2U Active CPU Heat Sink for X13 Gen. Building Block Solution
*Power Supply
PWS-1K62A-1R	2	AC-DC 1600W, Titanium Level, Redundancy, 1U, DC Output: +12V and +12Vs, 203 x 73.5 x 40 mm, AC Input: 90 - 264 VAC/47-63Hz, PMBus 1.2 with DSP controller,HF,RoHS/REACH
*Power Distributor
PDB-PT829H-2824	1	2U standard output with 24Pin PDB support up to
*Fan
FAN-0209L4	4	80x80x38 mm, 13.5K RPM, Middle Cooling Fan for 2U and above
FAN-0166L4OR	4	80x80x38 mm, 13.5K RPM, Optional Middle Cooling Fan for 2U Ultra Series Servers (Hot-swappable Version of FAN-0162L4)
FAN-0206L4	-	80x80x38 mm, 13.5K RPM, Middle Cooling Fan for 2U and above Servers
*Front Panel
FPB-TB826-T	1	Chassis transfer board for SC826
*Drive Tray(s)
MCP-220-00075-0B	12	Black gen 5.5 hot-swap 3.5" HDD tray
MCP-220-82902-0N	1	Middle tray plate for SC829H
MCP-220-82903-0N	4	Internal mid tray with handle for SC829H
MCP-290-82607-0N	1	826B/216B rear dummy cover for 2 X 2.5" HDD cage,RoHS
*Rail Set
MCP-290-00053-0N-01	1	36"; Rail set for Auto-latch, quick/quick, 2, 3U 17.2";W

Optional Part List

Part Number	Quantity	Description
Cable - for NVMe in main drive bay
CBL-MCIO-1260M5	3	MCIO (x8 STR to x8 STR),60CM,30AWG,85OHM,RoHS
Cable Management Arm
MCP-290-00073-0N	1	Supermicro Cable Management Arm
Converter Tray
MCP-220-00043-0N	1	2.5" HDD TRAY IN 4TH GENERATION 3.5" HOT SWAP TRAY
Converter Tray - orange NVMe tab
MCP-220-00138-0B	1	Black gen-5.5 tool-less NVMe 3.5-to-2.5 drive tray, Orange tab
Network Cards
AOC-S25G-b2S-O	1	Std LP 2-port 25G SFP28, Broadcom BCM57414
AOC-S25G-i2S-O	1	Std. Low Profile 25G dual port SFP28, based on Intel XXV710
AOC-S25G-M2S-O	1	Std LP 2-port 25G SFP28, Mellanox ConnectX-4 LX EN
AOC-STG-b2T-O	1	Standard LP 2-port 10Gbase-T, Broadcom 57416,HF,RoHS
AOC-STGS-i2T-O	1	Std LP 2-port 10G RJ45, Intel X550
Power Cord
CBL-PWCD-0300-IS	1	PWCD,US,IEC60320 C14 TO C13,6FT,18AWG,RoHS/REACH
CBL-PWCD-0579-1	1	Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V
CBL-PWCD-0579	1	Power Cord Type IEC (C14 to C13) 6 ft (14AWG), 15A, 250V
Supercap
BTR-CVPM05	1	Cachevault supercap for storage controller
MCP-240-00203-0N	1	PCIe plastic battery holder with FH/LP-bracket
TPM
AOM-TPM-9670V-O	1	TPM 2.0, vertical form factor, provisioned for server
VROC
AOC-VROCSTNMOD	1	Intel VROC HW key (RSTe) standard upgrade module,HF,RoHS
AOC-VROCPREMOD	1	Intel VROC Premium, RAID0,1,5,10,HF,RoHS
