X12 1U4GPU, MBD-X12DGQ-R-P, CSE-118GQE

SYS-120GQ-TNRT

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with Minimum 2 CPUs, 4 DIMMs, 2 GPUs, and 1 Storage device )

For this server, it's best to contact us for a fully validated, configured model. You can also add desired components to your cart, select "pay by bank transfer" at checkout, and we'll try to fulfill your wishes. We'll configure your system as closely as possible and send an updated quote with a validated system shortly. You can then decide if you want this configuration. The final payment method will be agreed upon after you accept the configuration.

https://safeconsulting.no/web/image/product.template/10326/image_1920?unique=a1dbe1e

kr 39 037,44 39037.44 NOK kr 39 037,44

kr 39 037,44

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Terms and Conditions

    Summary Description

    The Supermicro SYS-120GQ-TNRT server is built for high-performance computing, AI/deep learning, and scientific virtualization. Featuring dual-socket P+ LGA-4189 3rd Gen Intel Xeon Scalable Processors, support for up to 4TB DRAM, and multiple high-speed PCIe 4.0 slots, this server delivers exceptional performance and versatility.

    Key Features

    • Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
    • Intel® C621A Chipset
    • 16 DIMM Slots; Up to 4TB DRAM; Up to 4TB Intel® Optane™ Persistent Memory (up to 6TB with DRAM) ; 3200/2933/2666 ECC DDR4 LRDIMM;RDIMM; Intel® Optane™ Persistent Memory 200 series
    • 6 PCIe Gen 4.0 x16 (4 FHFL & 2 LP)
    • 2x 2.5" SATA Internal Fixed drive bays1 M.2 NVMe for boot drive only2x 2.5" NVMe/SATA Hot-swap drive bays
    • 9 counter rotating fans w/ Optimal Fan Speed Control
    • 2x 2000W redundant Titanium level power supplies

    Key Applications

    • Scientific Virtualization
    • High Performance Computing
    • Rendering
    • AI/Deep Learning Training

    Description

    The SYS-120GQ-TNRT from Supermicro is an advanced 1U rackmount server designed for demanding IT environments. Powered by dual-socket P+ (LGA-4189) 3rd Gen Intel Xeon Scalable processors and the Intel C621A chipset, this system supports up to 4TB of DDR4 memory and 6TB of DRAM with Intel Optane Persistent Memory 200 series. Its robust architecture includes 6 PCIe Gen 4.0 x16 slots, multiple 2.5" NVMe/SATA drive bays, and 2 redundant 2000W Titanium level power supplies. With extensive support for NVIDIA GPUs and comprehensive management software, it meets the needs of modern data centers effectively.

    Product Specifications

    Specification Details
    Product SKUs
    SKUs
    • SuperServer SYS-120GQ-TNRT
    Motherboard
    Installed Motherboard
    • Super X12DGQ-R
    Processor
    CPU
    • Dual Socket P+ (LGA-4189)
    • 3rd Gen Intel® Xeon® Scalable processors
    Core Count
    • Up to 40C/80T; Up to 60MB Cache per CPU
    Note
    • Supports up to 235W TDP CPUs (Air Cooled)
    GPU
    Max GPU Count
    • Up to 4 double-width or 4 single-width GPUs
    Supported GPU
    • NVIDIA PCIe: RTX A6000, RTX A5000, A40, A30, A16, A2, A100
    CPU-GPU Interconnect
    • PCIe 4.0 x16 CPU-to-GPU Interconnect
    GPU-GPU Interconnect
    • PCIe
    System Memory
    Memory
    • Slot Count: 16 DIMM slots
    • Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
    • Supports Intel® Optane™ persistent memory 200 series
    Memory Voltage
    • 1.2V
    On-Board Devices
    SATA
    • SATA (6Gbps) ; RAID 0/1/5/10 support
    Chipset
    • Intel® C621A
    Network Connectivity
    • 2 RJ45 10GbE
    Input / Output
    Video
    • 1 VGA port(s)
    System BIOS
    BIOS Type
    • AMI 32MB SPI Flash EEPROM
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • Power-on mode for AC power recovery
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • System Lockdown
    PC Health Monitoring
    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory
    • 7 +1 Phase-switching voltage regulator
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors
    Chassis
    Form Factor
    • 1U Rackmount
    Model
    • CSE-118GQE2TS-R2K05P
    Dimensions and Weight
    Height
    • 1.7" (43 mm)
    Width
    • 17.2" (437 mm)
    Depth
    • 35.2" (894 mm)
    Package
    • 8" (H) x 24" (W) x 46" (D)
    Weight
    • Gross Weight: 58 lbs (26.31 kg)
    • Net Weight: 45 lbs (20.4 kg)
    Available Color
    • Black Front & Silver Body
    Front Panel
    Buttons
    • 2 USB 3.0
    • Power On/Off button
    • System Reset button
    LED
    • Fan fail LED
    • Hard drive activity LED
    • Network activity LEDs
    • Power status LED
    • UID LED
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 4 PCIe 4.0 x16 FHFL slots
    • 2 PCIe 4.0 x16 LP slots

    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 4 bays:
    • 2 front hot-swap 2.5" NVMe drive bays
    • 2 internal fixed 3.5" SATA drive bays

    M.2
    • 1 M.2 NVMe/SATA slot (M-key)
    System Cooling
    Fans
    • 9 heavy duty fans with optimal fan speed control
    Power Supply
    1x 2000W Redundant Titanium Level (96%) power supply
    Dimension (WxHxL):
    • 73.5 x 40 x 265 mm

    AC Input:
    • 1000W: 100-120Vac / 50-60Hz
    • 1800W: 200-220Vac / 50-60Hz
    • 2000W: 200-240Vac / 50-60Hz (for UL/cUL only)
    • 1980W: 220-230Vac / 50-60Hz
    • 2000W: 230-240Vac / 50-60Hz

    +12V:
    • Max: 83.3A / Min: 0A (100Vac-120Vac)
    • Max: 150A / Min: 0A (200Vac-220Vac)
    • Max: 166.7A / Min: 0A (200Vac-240Vac) (for UL/cUL only)
    • Max: 165A / Min: 0A (220Vac-230Vac)
    • Max: 166.7A / Min: 0A (230Vac-240Vac)

    12V SB:
    • Max: 2.1A / Min: 0A

    Output Type:
    • Backplanes (gold finger)

    Certification:
    • Titanium Level

    Operating Environment
    Environmental Spec.
    • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity: 8% to 90% (non-condensing)
    • Non-operating Relative Humidity: 5% to 95% (non-condensing)

    Optional Part List

    Part Number Quantity Description
    Intel VROC RAID Key
    AOC-VROCINTMOD1Intel VROC, RAID 0, 1, 5, 10 (Intel SSD Only)
    AOC-VROCSTNMOD1Intel VROC Standard, RAID 0, 1, 10
    AOC-VROCPREMOD1Intel VROC Premium, RAID 0, 1, 5, 10
    Software
    SFT-DCMS-Single1DataCenter Management Package (per node license)
    Storage Control Card and Cable(s)
    AOC-S3908L-H8iR-16DD & 1x CBL-SAST-1275A-100-8 int 12Gb/s ports, x8 Gen4, ROC - LP, 16 HDD w/ exp,RoHS
    AOC-S3108L-H8iR & 1x CBL-SAST-0699-Std LP, 8 internal ports, 12Gb/s per port- Gen3, 16HDD,RAID 0, 1, 5, 6, 10, 50, 60; MINI SAS HD,12G,INT,30AWG
    Super Cap for LSI 3108
    1x BTR-TFM8G-LSICVM02 & 1x BKT-BBU-BRACKET-05-Supercap mounting bracket for PCIe location
    TPM Security Module
    AOM-TPM-9670V1SPI capable vertical TPM 2.0 provisioned for client,RoHS
