HyperE Front I/O, MBD-X13DEM, CSE-HE211, PWS-2K08F-1R

SKU: SYS-221HE-FTNR
Brand: Supermicro
Produktnotat:

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with Minimum 2 CPUs, 4 DIMMs, 1 NIC adapter*, and 1 drive). *NIC adapter requirement includes either 1 AIOM networking card or 1 standard PCIe NIC adapter.*For only 1 CPU installed customer request, please contact PM.

For denne serveren er det best å kontakte oss for å få en fullstendig validert og konfigurert modell. Du kan også legge ønskede komponenter i handlekurven, velge «betal via bankoverføring» ved utsjekk, så forsøker vi å imøtekomme dine ønsker. Vi vil konfigurere systemet ditt så nøyaktig som mulig og sende deg et oppdatert tilbud med et validert system om kort tid. Deretter kan du bestemme om du ønsker denne konfigurasjonen. Den endelige betalingsmetoden avtales når du har akseptert konfigurasjonen.

https://safeconsulting.no/web/image/product.template/10296/image_1920?unique=2d13a42

kr 36 970,70 36970.700000000004 NOK kr 36 970,70 Ekskl. mva

kr 36 970,70 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    The Supermicro SYS-221HE-FTNR is a robust 2U rackmount server designed for 5G, AI, and cloud computing applications. It supports dual 5th/4th Gen Intel Xeon Scalable processors, up to 8TB of DDR5 memory, and flexible PCIe and networking options.

    Nøkkelfunksjoner

    • Dual Socket E (LGA-4677) 5th/4th Gen Intel® Xeon® Scalable processors
    • 32 DIMM slots supporting up to 8TB of memory; RDIMMs up to DDR5-5600
    • Configurable PCIe slot options up to 8 PCIe 5.0 x8 (6 FHFL+ 2 FHHL) or 4 PCIe 5.0 x16 (3 FHFL + 1 FHHL)
    • Flexible networking options with 2 AIOM networking slots (OCP NIC 3.0 compatible)
    • Up to 6x 2.5" hot-swap drive bays with options to support NVMe/SATA drives
    • 6 heavy duty hot-swap fans with optimal fan speed control
    • Redundant 2000W Titanium level AC power supplies

    Viktige bruksområder

    • 5G Core and Edge
    • Telecom Micro Data Center
    • AI Inference and Machine Learning
    • Network Function Virtualization
    • Cloud Computing

    Beskrivelse

    The Supermicro SYS-221HE-FTNR is a high-performance 2U server designed for demanding applications such as 5G, AI inference, machine learning, and cloud computing. Supporting dual socket E (LGA-4677) 5th/4th Gen Intel Xeon Scalable processors, it offers unparalleled processing power. The system features 32 DIMM slots for up to 8TB of DDR5-5600 memory, flexible networking with 2 AIOM networking slots, and various configurable PCIe slot options. The server includes 6x 2.5" hot-swap drive bays, redundant 2000W Titanium level AC power supplies, and advanced cooling with 6 heavy duty hot-swap fans.

    Produktspesifikasjoner

    Specification Details
    Product SKUs
    SKUs
    • SuperServer SYS-221HE-FTNR
    Motherboard
    Installed Motherboard
    • Super X13DEM
    Processor
    CPU
    • Dual Socket E (LGA-4677)
    • 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
    • Supports Intel Xeon CPU Max Series with high bandwidth memory (HBM)​
    Core Count
    • Up to 60C/120T; Up to 112.5MB Cache per CPU
    Note
    • Supports up to 350W TDP CPUs (Air Cooled)
    GPU
    Max GPU Count
    • Up to 3 double-width or 3 single-width GPUs
    Supported GPU
    • NVIDIA PCIe: H100, L40, L40S, A40, A2, A10
    • Intel PCIe: Intel Data Center GPU Flex 170
    CPU-GPU Interconnect
    • PCIe 5.0 x16 CPU-to-GPU Interconnect
    GPU-GPU Interconnect
    • PCIe
    System Memory
    Memory
    • Slot Count: 32 DIMM slots/16 Channels
    • Max Memory (2DPC): Up to 8TB 5600MT/s ECC DDR5 RDIMM
    Memory Voltage
    • 1.1V
    On-Board Devices
    SATA
    • SATA (6Gbps) ; RAID 0/1/5/10 support
    NVMe
    • NVMe; RAID 0/1/5/10 support(Intel® VROC RAID key required)
    Chipset
    • Intel® C741
    Network Connectivity
    • 2 SFP28 25GbE with Broadcom® BCM57414 (optional)
    • 2 QSFP28 100GbE with Broadcom® BCM57508 (optional)
    • 2 QSFP28 100GbE with Intel® E810-CAM2 (optional)
    • 2 QSFP28 100GbE (optional)
    • 4 SFP+ 10GbE with Intel® X710-BM2 (optional)
    • 2 QSFP56 200GbE (optional)
    • 2 QSFP56 100GbE (optional)
    • 2 RJ45 1GbE with Intel® I350-AM2 (optional)
    • 4 SFP+ 10GbE with Intel® X710-TM4 (optional)
    • 1 OSFP 400GbE with NVIDIA® ConnectX®-7 NDR (optional)
    • 4 RJ45 10GbE with Intel® X550 (optional)
    Input / Output
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port(s)
    USB
    • 2 USB 2.0 port(s) (front)
    Video
    • 1 VGA port(s)
    System BIOS
    BIOS Type
    • AMI 256MB SPI Flash
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • Power-on mode for AC power recovery
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    PC Health Monitoring
    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors
    Chassis
    Form Factor
    • 2U Rackmount
    Model
    • CSE-HE211-R000NFP
    Dimensions and Weight
    Height
    • 3.5" (88.9 mm)
    Width
    • 17.2" (436.88 mm)
    Depth
    • 22.6" (574 mm)
    Package
    • 9.7" (H) x 23.5" (W) x 36.9" (D)
    Weight
    • Gross Weight: 47.4 lbs (21.5 kg)
    • Net Weight: 34.4 lbs (15.6 kg)
    Available Color
    • Silver
    Front Panel
    LED
    • HDD activity LED
    • LAN1 activity
    • LAN2 activity
    • Power Fail
    • Power status LED
    • System information
    Buttons
    • Power On/Off
    • UID button
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 3 PCIe 5.0 x16 FHFL slots
    • 2 PCIe 5.0 x8 FHHL slots
    • 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

    Option A*:
    • 6 PCIe 5.0 x8 FHFL slots
    • 2 PCIe 5.0 x8 FHHL slots
    • 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

    Option B*:
    • 3 PCIe 5.0 x16 FHFL slots
    • 1 PCIe 5.0 x16 FHHL slot
    • 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

    • (*Requires additional parts, please see the optional parts list for details. For more details on PCIe slot configuration options, please refer to the system callout images above.)
    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 6 bays:
    • 6 front hot-swap 2.5" NVMe/SAS*/SATA drive bays

    • (*SAS support may require additional storage controller and/or cables, please see the optional parts list for details)
    M.2
    • 2 M.2 NVMe/SATA slots (M-key 2280/22110)
    System Cooling
    Fans
    • 6 Counter-rotating, Hot-swappable 6cm Fan(s)
    Power Supply
    2x 2000W Redundant Titanium (certification pending) Level (96%) power supplies
    Dimension (WxHxL):
    • 73.5 x 40 x 203 mm

    AC Input:
    • 1000W: 100-127Vac / 50-60Hz
    • 1800W: 200-220Vac / 50-60Hz
    • 1980W: 220-230Vac / 50-60Hz
    • 2000W: 220-240Vac / 50-60Hz (for UL only)
    • 2000W: 230-240Vac / 50-60Hz
    • 2000W: 230-240Vdc / 50-60Hz (for China only)

    +12V:
    • Max: 83A (100Vac-127Vac)
    • Max: 150A (200Vac-220Vac)
    • Max: 165A (220Vac-230Vac)
    • Max: 166A (230Vac-240Vac)

    12V SB:
    • Max: 3.5A

    Output Type:
    • Backplanes (gold finger)

    Operating Environment
    Environmental Spec.
    • Operating Temperature: 0°C ~ 35°C (32°F ~ 95°F)
    • Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
    • Operating Relative Humidity: 8% to 90% (non-condensing)
    • Non-operating Relative Humidity: 5% to 95% (non-condensing)

    Valgfrie Opsjoner

    Part Number Quantity Description
    Cable
    CBL-PWEX-0962Y-20012VHPWR 2x6+4S to 2x 2x4 MicroHi power cable for PCIe slot 1/5 (H100, L40S, L40 RTX 6000 Ada, RTX 5000 Ada, RTX 4000 Ada)
    CBL-PWEX-0962Y-30012VHPWR 2x6+4S to 2x 2x4 MicroHi power cable for PCIe slot 3 (H100, L40S, L40 RTX 6000 Ada, RTX 5000 Ada, RTX 4000 Ada)
    CBL-PWEX-1148-300CPU 8-pin connector to 2x4 MicroHi power cable for PCIe slot 1/3/5 (A40, A100)
    CBL-GNZ4-1227M5YR210Cable to config PCIe slots 3/4 x8/x8
    CBL-MCIO-1232M50Cable to config PCIe slots1/2 x8/x8
    CBL-PWEX-10400Cable to convert CPU 8-pin to 2 PCI 2x3 + 2x1
    Optional sliding rail kit
    MCP-290-11901-0N0Optional sliding rail kit for Post to Post: 26.5" ~ 41.2"
    MCP-290-11902-0N0Optional sliding rail kit for Post to Post: 24" ~ 35.3"
    MCP-290-11903-0N030.5" ball-bearing rail set, without auto latch for Hyper 1U & 2U Project
    Riser Card
    RSC-H2-668G5S0Optional Riser Card for PCIe Slot 7 5.0 x16/ PCIe Slot 8 disable
