  2. [NR]HyperE, Front I/O, 6x2.5", X14DBM-SP, HE211-R000NFP

[NR]HyperE, Front I/O, 6x2.5", X14DBM-SP, HE211-R000NFP

SKU: SYS-222HE-FTN
Brand: Supermicro
Produktnotat:

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system with minimum 2 CPUs, 2 DIMMs and 1 storage device HDD/HDS/M.2 and 1 NIC. NIC can be either AIOM or PCIe card.

For denne serveren er det best å kontakte oss for å få en fullstendig validert og konfigurert modell. Du kan også legge ønskede komponenter i handlekurven, velge «betal via bankoverføring» ved utsjekk, så forsøker vi å imøtekomme dine ønsker. Vi vil konfigurere systemet ditt så nøyaktig som mulig og sende deg et oppdatert tilbud med et validert system om kort tid. Deretter kan du bestemme om du ønsker denne konfigurasjonen. Den endelige betalingsmetoden avtales når du har akseptert konfigurasjonen.

https://safeconsulting.no/web/image/product.template/12110/image_1920?unique=509f216

kr 26 496,34 26496.34 NOK kr 26 496,34 Ekskl. mva

kr 26 496,34 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    Supermicro SYS-222HE-FTN is a versatile 2U server featuring dual Intel Xeon 6 6700 series processors with E-cores, 32 DIMM slots for up to 2TB of memory, and configurable PCIe slots. It's designed for demanding applications such as AI, cloud, and edge computing.

    Nøkkelfunksjoner

    • Dual Intel® Xeon® 6 6700 series processors with E-cores
    • 32 DIMM slots supporting up to 2TB of memory
    • Optional PCIe slot configurations up to 8 PCIe 5.0 x8 (6FHFL + 2 FHHL) or 4 PCIe 5.0 x16 (3 FHFL + 1 FHHL) slots with support for double-width GPU/Accelerator cards
    • Flexible networking options with up to 2 AIOM networking slots (OCP NIC 3.0 compatible)
    • 6 Rear hot-swap 2.5" NVMe/SAS/SATA drive bays with optional configurations for additional 2 or 4 front hot-swap 2.5" NVMe drive bays (space share with PCIe slots); 2x internal M.2 NVMe drive slots; Optional RAID support via storage add-on card

    Viktige bruksområder

    • Virtualization
    • Software-defined Storage
    • 5G Core and Edge
    • AI Inference and Machine Learning
    • Cloud Computing
    • Enterprise Server

    Beskrivelse

    The Supermicro SYS-222HE-FTN provides exceptional performance with dual Intel Xeon 6 6700 series processors equipped with E-cores and up to 144 cores in total. The server supports up to 2TB of memory across 32 DIMM slots, ensuring ample capacity for memory-intensive applications. Flexible I/O options include PCIe 5.0 slots for GPUs and accelerators, and AIOM slots for advanced networking. Storage configurations are highly versatile, with hot-swap NVMe/SAS/SATA drive bays and M.2 slots. Robust security features and extensive management options make this server a top choice for enterprise environments.

    Produktspesifikasjoner

    Specification Details
    Product SKUs
    SKUs
    • SuperServer SYS-222HE-FTN
    Motherboard
    Installed Motherboard
    • Super X14DBM-SP
    Processor
    CPU
    • Dual Socket E2 (LGA-4710)
    • Intel® Xeon® 6 6700 series processors with E-cores
    Core Count
    • Up to 144C/144T; Up to 108MB Cache per CPU
    Note
    • Supports up to 330W TDP CPUs (Air Cooled)
    • Supports up to 330W TDP CPUs (Liquid Cooled)​
    GPU
    Max GPU Count
    • Up to 3 double-width or 4 single-width GPU(s)
    CPU-GPU Interconnect
    • PCIe 5.0 x16 CPU-to-GPU Interconnect
    GPU-GPU Interconnect
    • PCIe
    System Memory
    Memory
    • Slot Count: 32 DIMM slots/16 Channels
    • Max Memory (1DPC): Up to 2 TB 6400MT/s ECC DDR5 RDIMM
    • Max Memory (2DPC): Up to 2 TB 5200MT/s ECC DDR5 RDIMM
    On-Board Devices
    NVMe
    • NVMe; RAID 0/1/5/10 support(Intel® VROC RAID key required)
    Chipset
    • System on Chip
    Network Connectivity
    • Via AIOM
    Input / Output
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port(s)
    USB
    • 2 USB 3.0 port(s) (front)
    Video
    • 1 VGA port(s)
    System BIOS
    BIOS Type
    • AMI 64MB SPI Flash
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • Power-on mode for AC power recovery
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    PC Health Monitoring
    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors
    Chassis
    Form Factor
    • 2U Rackmount
    Model
    • CSE-HE211-R000NFP
    Dimensions and Weight
    Height
    • 3.5" (88.9 mm)
    Width
    • 17.2" (436.88 mm)
    Depth
    • 22.6" (574 mm)
    Package
    • 9.7" (H) x 23.5" (W) x 36.9" (D)
    Weight
    • Gross Weight: 47.4 lbs (21.5 kg)
    • Net Weight: 34.4 lbs (15.6 kg)
    Available Color
    • Silver
    Front Panel
    LED
    • HDD activity LED
    • LAN1 activity
    • LAN2 activity
    • Power Fail
    • Power status LED
    • System information
    Buttons
    • Power On/Off
    • UID button
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Option A*:
    • 3 PCIe 5.0 x16 FH/10.5"L double-width slot(s)
    • 1 PCIe 5.0 x16 FHHL slot(s)
    • 2 PCIe 5.0 x16 AIOM slot(s) (OCP 3.0 compatible)

    Option B*:
    • 6 PCIe 5.0 x8 (in x16) FH/10.5"L slot(s)
    • 2 PCIe 5.0 x8 (in x16) FHHL slot(s)
    • 2 PCIe 5.0 x16 AIOM slot(s) (OCP 3.0 compatible)

    • (*Requires additional parts, please see the optional parts list for details. For more details on PCIe slot configuration options, please refer to the system callout images above.)
    CXL Support
    • Up to 4 CXL 2.0 x16/x8 devices
    M.2
    • 2 M.2 PCIe 5.0 x2 NVMe slot(s) (M-key 2280/22110)
    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 6 bay(s):
    • 6 rear hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s)

    Option A: Total 8 bay(s):
    • 6 rear hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s)
    • 2 front hot-swap 2.5" NVMe* drive bay(s)

    Option B: Total 10 bay(s):
    • 6 rear hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s)
    • 4 front hot-swap 2.5" NVMe* drive bay(s)

    • (*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details)
    M.2
    • 2 M.2 PCIe 5.0 x2 NVMe slot(s) (M-key 2280/22110/25110)
    System Cooling
    Fans
    • 6 counter-rotating 60x60x56mm Fan(s)
    Liquid Cooling
    • Direct to Chip (D2C) Cold Plate (optional)
    Power Supply
    2x 2000W Redundant (1 + 1) Titanium (certification pending) Level (96%) Hot-plug power supplies
    Dimension (WxHxL):
    • 73.5 x 40 x 203 mm

    AC Input:
    • 1000W: 100-127Vac / 50-60Hz
    • 1800W: 200-220Vac / 50-60Hz
    • 1980W: 220-230Vac / 50-60Hz
    • 2000W: 220-240Vac / 50-60Hz (for UL only)
    • 2000W: 230-240Vac / 50-60Hz
    • 2000W: 230-240Vdc / 50-60Hz (for China only)

    +12V:
    • Max: 83A (100Vac-127Vac)
    • Max: 150A (200Vac-220Vac)
    • Max: 165A (220Vac-230Vac)
    • Max: 166A (230Vac-240Vac)

    12V SB:
    • Max: 3.5A

    Output Type:
    • Backplanes (gold finger)

    2x 1200W power supplies
    Dimension (WxHxL):
    • 100 x 40 x 326 mm

    5V SB:
    • Max: 4A

    2x 1300W Redundant (1 + 1) power supplies
    Dimension (WxHxL):
    • 73.5 x 40 x 203 mm

    DC Input:
    • 108.3A Max

    Operating Environment
    Environmental Spec.
    • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
    • Operating Relative Humidity: 8% to 90% (non-condensing)
    • Non-operating Relative Humidity: 5% to 95% (non-condensing)

    Valgfrie Opsjoner

    Part Number Quantity Description
    2nd AIOM/OCP NIC 3.0 Slot
    AOM-AIOM-2X8-G5-P1AIOM slot A2 kit
    CBL-MCIO-1213M52AIOM slot A2 kit
    Cable Management Arm + Rail Set
    MCP-290-00168-0N + MCP-290-11901-0N-7.5" cable management arm + 41" long ball-bearing rail set
    Drive Bay Configuration Options
    Refer to User's Manual-8 & 10 drive bay configuration options for NVMe, SAS, or SATA support
    Global Services & Support
    OS4HR3/2/1-Gold Level, 3/2/1-year onsite 24x7x4 SLA
    OSNBD3/2/1-Silver Level, 3/2/1-year onsite NBD SLA
    SMSAD3/2/1-Bronze Level, 3/2/1-year 3BD SLA
    PCIe Slot Configuration Options
    Refer to User's Manual-PCIe slot configuration options to enable PCIe slots 1-8
    Rail Set
    MCP-290-11901-0N141" ball-bearing rail set for Hyper servers
    MCP-290-11902-0N135.25" ball-bearing rail set for Hyper servers
    MCP-290-21103-0N (included in the system )121.65" ball-bearing rail set for Hyper servers
    Software
    SFT-DCMS-Single1DataCenter Management Package (per node license)
    Trusted Platform Module Options
    AOM-TPM-9672V-FIPS-O1AOM-TPM-9672V-FIPS TPM 2.0 support FIPS
    AOM-TPM-9672V-O1SPI capable vertical TPM 2.0
