  2. [NR]CSE-E403BiF-000NDBP2 + X13SEW-TF,HF,RoHS

[NR]CSE-E403BiF-000NDBP2 + X13SEW-TF,HF,RoHS

SKU: SYS-E403-13E-FRN2T
Brand: Supermicro
Produktnotat:

For denne serveren er det best å kontakte oss for å få en fullstendig validert og konfigurert modell. Du kan også legge ønskede komponenter i handlekurven, velge «betal via bankoverføring» ved utsjekk, så forsøker vi å imøtekomme dine ønsker. Vi vil konfigurere systemet ditt så nøyaktig som mulig og sende deg et oppdatert tilbud med et validert system om kort tid. Deretter kan du bestemme om du ønsker denne konfigurasjonen. Den endelige betalingsmetoden avtales når du har akseptert konfigurasjonen.

https://safeconsulting.no/web/image/product.template/10486/image_1920?unique=de84d91

kr 18 679,74 18679.74 NOK kr 18 679,74 Ekskl. mva

kr 18 679,74 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    The Supermicro SYS-E403-13E-FRN2T is a cutting-edge server designed for multi-access edge computing (MEC), industrial automation, and AI on the edge. Supporting the latest Intel Xeon scalable processors, it offers immense processing power with up to 2TB of DDR5 memory.

    Nøkkelfunksjoner

    • Support 5th and 4th Gen Intel® Xeon® Scalable processors
    • Up to 8 DIMMs and total 2TB 3DS ECC DDR5-5600 RDIMM
    • 3x PCIe5.0 x16 slot
    • 2x 10 Gigabit Ethernet Ports
    • Up to 4x 2.5" U.2 NVMe drive(2 Hot-swap, Optional 2 fixed)

    Viktige bruksområder

    • Multi-Access Edge Computing (MEC)
    • Universal Customer Premise Equipment (uCPE)
    • Industrial Automation
    • Artificial Intelligence (AI) on Edge
    • Machine Learning (ML)
    • Smart Retail/Medical Expert Systems

    Beskrivelse

    Ideal for applications such as MEC, uCPE, and smart retail, the Supermicro SYS-E403-13E-FRN2T incorporates the latest 5th and 4th Gen Intel Xeon scalable processors and up to 2TB DDR5 memory. It features three PCIe5.0 x16 slots, two 10GbE ports, and up to four 2.5" U.2 NVMe drives. The robust management suite, including SuperCloud Composer and Supermicro Server Manager, ensures seamless operation. Enhanced security and environmental resilience make this server a top choice for demanding environments.

    Produktspesifikasjoner

    Specification Details
    Product SKUs
    SKUs
    • SuperServer SYS-E403-13E-FRN2T
    Motherboard
    Installed Motherboard
    • Super X13SEW-TF
    Processor
    CPU
    • Single Socket E (LGA-4677)
    • 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
    Core Count
    • Up to 32C/64T; Up to 60MB Cache
    Note
    • Supports up to 300W TDP CPUs (Air Cooled)
    System Memory
    Memory
    • Slot Count: 8 DIMM slots
    • Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM
    Memory Voltage
    • 1.1V
    On-Board Devices
    NVMe
    • NVMe; RAID 0/1 support(Intel® VROC RAID key required)
    Chipset
    • Intel® C741
    Network Connectivity
    • 2 RJ45 10GBASE-T with Intel® X550-AT2
    • 1 RJ45 1GbE with Realtek RTL8211F PHY (dedicated IPMI)
    Input / Output
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port(s)
    • 2 RJ45 10 GbE LAN port(s) (Intel® X550-AT2)
    USB
    • 2 USB 2.0 Type-A port(s) (rear)
    • 4 USB 3.2 Gen1 Type-A port(s) (Rear)
    Video
    • 1 VGA port(s) (Rear)
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • Power-on mode for AC power recovery
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    Chassis
    Form Factor
    • Fan-based Embedded
    Model
    • CSE-E403BiF-000NDBP2
    Dimensions and Weight
    Height
    • 4.62" (117.348 mm)
    Width
    • 10.5" (266.7 mm)
    Depth
    • 16" (406.4 mm)
    Package
    • 10.4" (H) x 16.4" (W) x 26" (D)
    Weight
    • Gross Weight: 24.5 lbs (10.95 kg)
    • Net Weight: 18.5 lbs (8.16 kg)
    Available Color
    • Black
    Front Panel
    LED
    • HDD activity
    • LAN1 activity
    • LAN2 activity
    • Power status
    • reset status
    • System information
    Buttons
    • Power On/Off
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 3 PCIe 5.0 x16 FHFL slots

    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 4 bays:
    • 2 front hot-swap 2.5" NVMe drive bays
    • 2 internal fixed 2.5" SATA* drive bays

    • (*SATA support may require additional storage controller and/or cables, please see the optional parts list for details)
    M.2
    • 1 M.2 PCIe 3.0 x2 NVMe slot (M-key 2280/22110)
    System Cooling
    Fans
    • 3x 8cm heavy duty fans with optimal fan speed control 80x80x38mm Fan(s)
    Power Supply
    1x 800W Redundant Platinum Level (94%) power supply
    Dimension (WxHxL):
    • 54.5 x 40.25 x 220 mm

    AC Input:
    • 750W: 100-127Vac / 50-60Hz
    • 800W: 200-240Vac / 50-60Hz
    • 800W: 230-240Vdc / 50-60Hz

    +12V:
    • Max: 62.5A / Min: 0.5A (100Vac-127Vac)
    • Max: 66.6A / Min: 0.5A (200Vac-240Vac)
    • Max: 66.6A / Min: 0.5A (230Vdc-240Vdc)

    5V SB:
    • Max: 4A / Min: 0A

    Output Type:
    • Backplanes (gold finger)

    Operating Environment
    Environmental Spec.
    • Operating Temperature: 0°C ~ 45°C (32°F ~ 113°F)
    • Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
    • Operating Relative Humidity: 8% to 90% (non-condensing)
    • Non-operating Relative Humidity: 5% to 95% (non-condensing)

    Standard Delliste

    Part Number Quantity Description
    Motherboard / Chassis
    MBD-X13SEW-TF1Super X13SEW-TF Motherboard
    CSE-E403BiF-000NDBP21Fan-based Embedded Chassis
    Cable
    CBL-CUSB-08321USB 3.0(F) Type A 2x to USB3.0 20pin,73CM,30AWG,RoHS
    CBL-MCIO-1324M52MCIO (x8 to x8), STR, 24cm,G5,32AWG, RoHS,RoHS
    CBL-PWCD-0260-IS1PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,18AWG,RoHS/REACH
    CBL-0156L1ROUND 16PIN TO 16PIN FP CABLE,40CM, PB FREE
    Fan
    FAN-0200L4380x80x38 mm, 13.5K RPM Cooling Fan for CSE-E403IF, RoHS
    Power Supply
    MCP-250-00018-0N1PWS dummy cover for 1U redundant power suppy w/ handle (54.5mm wide)
    PWS-804P-1R11U 800W 100-240VAC/50-60Hz, and DC240V input
    Parts
    MCP-260-00078-0B11U I/O shield for X11 Server MB with 5X5mm vent hole and EMI Gasket, Black
    Power Distributor
    PDB-PT403-88241PDB-PT403-8824 is modified from PDB-PT802-8824 for E403 syst
    Riser Card
    RSC-W2R-666G512.5U RHS WIO Riser card with three PCIe 5.0 X16 slots,HF
    Software
    SFT-OOB-LIC1License key for enabling OOB BIOS management
    Heatsink / Retention
    SNK-P0089P11.5U Passive 45 mm Tall CPU Heat Sink for X13 SYS-241H/E
    *Front Panel
    FPB-FP826-D1Front control board Dual color LED(FP826-D)forSC826,213,216,
    FPB-TB826116 pin Cable Adaptor Board for SC826

    Valgfrie Opsjoner

    Part Number Quantity Description
    For internal U.2 drive cable
    CBL-MCIO-1245U2Y-E1MCIO x8 to 2x SFF-8639/U.2+Pwr,45cm,G5,RoHS
    Nvdia GPU rear-support bracket
    MCP-120-82906-0N1GPU bracket for SC829U,219U, Right (nVidia)
