  2. Aten Video HDMI KVM Extender VE803

Aten Video HDMI KVM Extender VE803

SKU: VE803-AT-G
Brand: Aten
https://safeconsulting.no/web/image/product.template/13931/image_1920?unique=9d3b09e

kr 1 064,80 1064.8 NOK kr 1 064,80 Ekskl. mva

kr 1 064,80 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    ATEN USB & HDMI Extender CAT5e/6, USB2.0 Full Speed (12Mbit/s) 1080P (40m) / 1080i (60m). Type: AV transmitter & receiver, Maximum resolution: 1920 x 1200 pixels, Cable types supported: Cat5e. Connectivity technology: Wired, USB connector type: USB Type-A, USB Type-B. Operating voltage (transmitter): 5 V, Operating voltage (receiver): 5 V, Power consumption (TX): 1.04 W. Weight: 495 g, Receiver dimensions (WxDxH): 90 x 57.4 x 24 mm, Receiver weight: 160 g. Package width: 59 mm, Package depth: 239 mm, Package height: 160 mm

    Nøkkelfunksjoner

    • AV transmitter & receiver 1920 x 1200 pixels Black
    • Maximum transfer distance: 60 m
    • HDCP
    • Wired DC-in jack

    Viktige bruksområder

    • Broadcasting Studios
    • Digital Signage
    • Remote Workstations
    • Educational Institutions
    • Conference Rooms

    Beskrivelse

    The VE803 HDMI USB Extender extends an HDMI signal up to 60 meters from the HDMI source using two Cat 5e cables. It is capable of sending 1080i signals up to 60 meters and 1080p signals up to 40 meters.

    The VE803 is equipped with USB connectors which allow you to extend any USB device between the units. The USB feature also provides support for touch panel control, allowing you to control the local HDMI source device from the remote display, or control the remote display through the local unit.

    1x VE803T HDMI USB Extender
    1x VE803R HDMI USB Extender
    1x 0AD6-1705-10EG Power Adapter
    1x USB Cable (1.8 m)
    1x Mounting Kit
    1x User Instructions

    Produktspesifikasjoner

    Specification Details
    Features
    Type
    • AV transmitter & receiver
    Maximum resolution
    • 1920 x 1200
    Cable types supported
    • Cat5e
    Maximum transfer distance
    • 60
    Extended display identification data (EDID)
    • Yes
    Electrostatic Discharge (ESD) protection
    • Yes
    • 15
    Supported video modes
    • 1080i,1080p
    Supported graphics resolutions
    • 640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1600 x 1200 (UXGA),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA)
    Bandwidth
    • 6.75
    • 225
    HDCP
    • Yes
    Material
    • Metal
    3D
    • Yes
    Product colour
    • Black
    Ports & interfaces
    Connectivity technology
    • Wired
    HDMI in
    • 1
    Number of HDMI outputs
    • 1
    USB connector type
    • USB Type-A,USB Type-B
    DC-in jack
    • Yes
    Power
    Operating voltage (transmitter)
    • 5
    Operating voltage (receiver)
    • 5
    Power consumption (TX)
    • 1.04
    Power consumption (RX)
    • 0.75
    Operational conditions
    Operating temperature (T-T)
    • 0 - 50
    Storage temperature (T-T)
    • -20 - 60
    Operating relative humidity (H-H)
    • 0 - 80
    Storage relative humidity (H-H)
    • 0 - 80
    Weight & dimensions
    Weight
    • 495
    Receiver dimensions (WxDxH)
    • 90 x 57.4 x 24
    Receiver weight
    • 160
    Transmitter dimensions (WxDxH)
    • 90 x 57.4 x 24
    Transmitter weight
    • 160
    Packaging data
    Package width
    • 59
    Package depth
    • 239
    Package height
    • 160
    Package weight
    • 652
    Packaging content
    AC adapter included
    • Yes
    Cables included
    • USB
    Manual
    • Yes
    Mounting kit
    • Yes
    Logistics data
    Master (outer) case width
    • 315
    Master (outer) case length
    • 490
    Master (outer) case height
    • 338
    Master (outer) case gross weight
    • 13500
    Master (outer) case net weight
    • 9900
    Products per master (outer) case
    • 20
