ARECA 12 PORT TRI MODE RAID PCIE 4 X8,

ARC-1886-4X8I
https://safeconsulting.no/web/image/product.template/12495/image_1920?unique=c1c7326

kr 12,066.60 12066.6 NOK kr 12,066.60

kr 12,066.60

Not Available For Sale

    This combination does not exist.

    Summary Description

    The Areca ARC-1886-4X8I RAID adapter is designed for enterprise environments, providing advanced technology to increase performance and enhance data protection with a 1.6 GHz dual core ROC processor, DDR4-2666 memory, and PCIe 4.0 interface.

    Key Features

    • Supports 8GB DDR4-2666 Cache
    • Complies with SFF-9402
    • Read/Write Cache Allocation by Policy
    • Supports Up to 32 NVMe Drives Using PCIe Switch
    • Redundant Flash Image for Adapter Availability
    • UBM, SES2, SMP, and SGPIO Enclosure Management
    • Supports Up to 512 SAS/SATA/SSD Drives with Expanders
    • Optional Cache Backup Module with SuperCap
    • Tri-Mode Interface at Each Drive Port
    • Advanced RAID Levels and Mirroring

    Description

    The ARC-1886-4X8I adapter supports up to 8GB DDR4-2666 cache, SFF-9402 compliant connector pin-out, up to 32 NVMe drives using PCIe switch, and up to 512 12Gb/s SAS, SATA, or SSD drives with SAS expanders. It includes hardware encryption and other advanced features tailored for enterprise environments.

    Product Specifications

    Specification Details
    General Information
    Model Number
    • ARC-1886-4X8I
    Series
    • ARC-1886 Series
    Physical Dimensions
    Low Profile
    • 167.65(L) x 64.4(H) mm
    Ports and Interfaces
    Ports
    • 8 x internal
    • 4 x external
    Drive Connectors
    • 1 x SFF-8654 [x8]
    • 1 x SFF-8644 [x4]
    Host Bus Interface
    • 8-Lane PCI Express® 4.0
    Performance
    I/O Processor
    • Tri-Mode Dual Core ARM A15 1.6GHz ROC
    Cache Memory
    • 8GB on-board DDR4-2666 SDRAM with ECC Protection
    Data Transfer Rate
    • Up to 12Gb/s SAS/SATA/Gen 4.0 PCIe (NVMe) per port
    Drive Support
    Drive Compatibility
    • Up to 512 12Gb/s SAS or 6Gb/s and 3Gb/s SAS/SATA HDDs/SSDs, using 12Gb/s SAS expander
    • Up to 32 NVMe drives through the PCIe switches
    Power and Environmental
    Power Consumption
    • Approximately 14 Watts
    Operating Temperature
    • 0 °C to 60 °C
    Operating Humidity
    • 10% to 85%, non-condensing
    General
    Cache Protection
    • ARC-1886-CBM
