Lynnfield 4C X3430 2.4G 8M 2.5GT/s DMI

BV80605001914AG
https://safeconsulting.no/web/image/product.template/6250/image_1920?unique=4175d88

kr 2,697.16 2697.16 NOK kr 2,697.16

kr 2,697.16

Not Available For Sale

    This combination does not exist.

    Summary Description

    Intel Xeon X3430. Processor family: Intel® Xeon® 3000 Sequence, Processor socket: LGA 1156 (Socket H), Processor lithography: 45 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 32 GB, Memory types supported by processor: DDR3-SDRAM. Market segment: Server, PCI Express configurations: 1x16, 2x8, 4x4, Number of Processing Die Transistors: 774 M. Package type: Retail box. Processor package size: 37.5 x 37.5 mm

    Key Features

    • 8 MB Smart Cache LGA 1156 (Socket H)
    • Processor cores: 4 45 nm 64-bit 95 W
    • Intel® Xeon® 3000 Sequence X3430 2.4 GHz
    • Maximum internal memory supported by processor: 32 GB DDR3-SDRAM

    Description

    The Intel® Xeon® processor 3000 sequence-based platforms unleash the computing power of Intel Xeon processors. The new 45 nm Quad and Dual-Core processors feature enhanced Intel® Core™ microarchitecture that provides your business with exceptional performance and power efficiency at a very affordable cost.

    These servers are ideal for small business owners looking for ways to grow business, manage operation more effectively and efficiently, and protect and secure one of their most important assets - information.

    Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

    Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

    Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

    Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor model
    • X3430
    Processor base frequency
    • 2.4
    Processor family
    • Intel Xeon 3000
    Processor cores
    • 4
    Processor socket
    • LGA 1156 (Socket H)
    Component for
    • Server/Workstation
    Processor lithography
    • 45
    Processor series
    • Intel Xeon 3400 series
    Processor threads
    • 4
    System bus rate
    • 2.5
    Processor operating modes
    • 64-bit
    Processor boost frequency
    • 2.8
    Processor cache
    • 8
    Processor cache type
    • Smart Cache
    Thermal Design Power (TDP)
    • 95
    Box
    • No
    Cooler included
    • No
    VID Voltage Range
    • 0.65 - 1.4
    Compatible chipsets
    • Intel 3400,Intel 3420,Intel 3450
    Stepping
    • B1
    Bus type
    • DMI
    CPU multiplier (bus/core ratio)
    • 18
    Memory bandwidth supported by processor (max)
    • 21
    Processor codename
    • Lynnfield
    Processor ARK ID
    • 42927
    Memory
    Maximum internal memory supported by processor
    • 32
    Memory types supported by processor
    • DDR3-SDRAM
    Memory clock speeds supported by processor
    • 800,1066,1333
    Memory channels
    • Dual-channel
    ECC
    • Yes
    Graphics
    On-board graphics card
    • No
    Features
    Execute Disable Bit
    • Yes
    Idle States
    • Yes
    Thermal Monitoring Technologies
    • No
    Market segment
    • Server
    Maximum number of PCI Express lanes
    • 16
    PCI Express slots version
    • 2.0
    PCI Express configurations
    • 1x16,2x8,4x4
    Number of Processing Die Transistors
    • 774
    Processing Die size
    • 296
    Number of Graphics & IMC Die Transistors
    • 774
    Supported instruction sets
    • SSE4.2
    CPU configuration (max)
    • 1
    Embedded options available
    • Yes
    Physical Address Extension (PAE)
    • 36
    PCI Express CEM revision
    • 2.0
    Export Control Classification Number (ECCN)
    • 3A991
    Commodity Classification Automated Tracking System (CCATS)
    • NA
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • No
    Intel® Turbo Boost Technology
    • 1.0
    Intel® AES New Instructions (Intel® AES-NI)
    • No
    Enhanced Intel SpeedStep Technology
    • Yes
    Intel Trusted Execution Technology
    • Yes
    Intel Enhanced Halt State
    • Yes
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel Demand Based Switching
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Conflict-Free processor
    • No
    Intel® vPro™ Platform Eligibility
    • No
    Operational conditions
    Tcase
    • 72.7
    Technical details
    Born on date
    • Q3'09
    Bus bandwidth
    • 2.5
    Bus type units
    • GT/s
    Launch date
    • Q3'09
    Processor cache
    • 8192
    Processor core voltage
    • 0.6500-1.4000
    Product name
    • Intel Xeon X3430 (8M Cache, 2.40 GHz)
    Product type
    • Processor
    Status
    • Discontinued
    Maximum memory
    • 32
    Processor brand name
    • Intel Xeon
    Supported memory types
    • DDR3-SDRAM
    Last change
    • 63903513
    Product family
    • Intel Xeon Processor 3000 Sequence
    Bus speed
    • 2.5 GT/s
    Logistics data
    Harmonized System (HS) code
    • 8542310001
    Packaging data
    Package type
    • Retail box
    Weight & dimensions
    Processor package size
    • 37.5 x 37.5
    Other features
    Intel® Virtualization Technology (Intel® VT)
    • VT-d,VT-x
    Compatibility
    • Intel Server Board S3420GPLC Intel Server Board S3420GPLX Intel Server Board S3420GPV Intel Server Board S3420GPRX Intel Server System SR1630GP Intel Server System SR1630HGP Intel Server System SR1695GPRX1AC Intel Server System SR1695GPRX2AC Intel Server System SR1630GPRX Intel Server System SR1630HGPRX
    Maximum internal memory
    • 32
    • 32768
    Cache memory
    • 8
