SKL 3106 2P 8C/8T 1.7G 11M 9.6GT 85W 3647 U0

CD8067303561900
https://safeconsulting.no/web/image/product.template/6462/image_1920?unique=8d6572e

kr 4,296.50 4296.5 NOK kr 4,296.50

kr 4,296.50

Not Available For Sale

    This combination does not exist.

    Summary Description

    Intel Xeon 3106. Processor family: Intel Xeon Bronze, Processor socket: LGA 3647 (Socket P), Processor lithography: 14 nm. Memory channels: Hexa-channel, Maximum internal memory supported by processor: 768 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512, Scalability: 2S. Package type: Retail box. Processor package size: 76mm x 56.5mm

    Key Features

    • Intel Xeon Bronze 3106 1.7 GHz
    • 11 MB L3 LGA 3647 (Socket P)
    • Processor cores: 8 14 nm 64-bit 85 W
    • Maximum internal memory supported by processor: 768 GB DDR4-SDRAM

    Key Applications

    • Enterprise Servers
    • Data Centers
    • Virtualization
    • High-Performance Computing
    • Database Management
    • Cloud Computing
    • Server Workloads
    • Secure Transactions
    • Memory-Intensive Applications
    • Storage Management

    Description

    Intel® Trusted Execution Technology
    Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

    Intel® Virtualization Technology for Directed I/O (VT-d)
    Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

    Intel® Virtualization Technology (VT-x)
    Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

    Intel® 64
    Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

    Cache
    CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

    Intel® AES New Instructions
    Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

    Intel® Turbo Boost Technology
    Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

    Execute Disable Bit
    Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

    Intel® Hyper-Threading Technology
    Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

    Intel vPro® Platform Eligibility
    The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.

    Intel® VT-x with Extended Page Tables (EPT)
    Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

    Intel® Optane™ Memory Supported
    Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

    Enhanced Intel SpeedStep® Technology
    Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

    Intel® Speed Shift Technology
    Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

    Instruction Set Extensions
    Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

    Intel® Turbo Boost Max Technology 3.0
    Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

    Max # of UPI Links
    Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI.

    # of AVX-512 FMA Units
    Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.

    Intel® Volume Management Device (VMD)
    Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

    Mode-based Execute Control (MBEC)
    Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

    Intel® Transactional Synchronization Extensions
    Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor generation
    • Intel Xeon Scalable 1st Gen
    Processor model
    • 3106
    Processor base frequency
    • 1.7
    Processor family
    • Intel Xeon Bronze
    Processor cores
    • 8
    Processor socket
    • LGA 3647 (Socket P)
    Component for
    • Server/Workstation
    Processor lithography
    • 14
    Processor threads
    • 8
    Processor operating modes
    • 64-bit
    Processor cache
    • 11
    Processor cache type
    • L3
    Thermal Design Power (TDP)
    • 85
    Box
    • No
    Cooler included
    • No
    Stepping
    • U0
    Bus type
    • UPI
    Processor codename
    • Skylake
    Processor code
    • SR3GL
    Processor ARK ID
    • 123540
    Memory
    Maximum internal memory supported by processor
    • 768
    Memory types supported by processor
    • DDR4-SDRAM
    Memory clock speeds supported by processor
    • 2133
    Memory channels
    • Hexa-channel
    ECC
    • Yes
    Graphics
    On-board graphics card
    • No
    Features
    Execute Disable Bit
    • Yes
    Market segment
    • Server
    Maximum number of PCI Express lanes
    • 48
    PCI Express slots version
    • 3.0
    Supported instruction sets
    • SSE4.2,AVX,AVX 2.0,AVX-512
    Scalability
    • 2S
    Embedded options available
    • Yes
    PCI Express CEM revision
    • 3.0
    Export Control Classification Number (ECCN)
    • 5A992C
    Commodity Classification Automated Tracking System (CCATS)
    • G077159
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • No
    Intel® Turbo Boost Technology
    • No
    Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    Enhanced Intel SpeedStep Technology
    • Yes
    Intel Trusted Execution Technology
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Transactional Synchronization Extensions
    • Yes
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel TSX-NI
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Intel TSX-NI version
    • 1.00
    Conflict-Free processor
    • Yes
    Intel Turbo Boost Max Technology 3.0
    • No
    Intel® Optane™ Memory Ready
    • No
    AVX-512 Fused Multiply-Add (FMA) units
    • 1
    Intel® Volume Management Device (VMD)
    • Yes
    Mode-based Execute Control (MBE)
    • Yes
    Intel® vPro™ Platform Eligibility
    • Yes
    Operational conditions
    Tcase
    • 77
    Technical details
    Launch date
    • Q3'17
    Processor cache
    • 11264
    Product type
    • Processor
    Status
    • Launched
    Maximum memory
    • 768
    Processor brand name
    • Intel Xeon Bronze Intel Xeon Bronze Processor
    Supported memory types
    • DDR4-SDRAM
    Last change
    • 63903513
    Product family
    • Intel Xeon Processors
    Intel® Speed Shift Technology version
    • 1.00
    Intel® Volume Management Device (VMD) version
    • 1.00
    Memory speed (max)
    • 2133
    Mode-based Execute Control (MBE) version
    • 1.00
    Number of UPI links
    • 2
    Servicing status
    • ESU Notification Issued
    End of servicing updates date
    • Sunday, December 31, 2023
    Logistics data
    Harmonized System (HS) code
    • 8542310001
    Packaging data
    Package type
    • Retail box
    Weight & dimensions
    Processor package size
    • 76mm x 56.5mm
    Other features
    Maximum internal memory
    • 768
    • 786432
