CLX 4215R 2P 8C/16T 3.2G 11M 10.4GT 130W 3647 B1

CD8069504449200
https://safeconsulting.no/web/image/product.template/8689/image_1920?unique=5e77b27

kr 11,048.06 11048.06 NOK kr 11,048.06

kr 11,048.06

Not Available For Sale

    This combination does not exist.

    Summary Description

    Intel Xeon 4215R. Processor family: Intel Xeon Silver, Processor socket: LGA 3647 (Socket P), Processor lithography: 14 nm. Memory channels: Hexa-channel, Maximum internal memory supported by processor: 1.02 TB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512, Scalability: 2S. Processor package size: 76mm x 56.5mm. Maximum internal memory: 1 TB

    Key Features

    • Intel Xeon Silver 4215R 3.2 GHz
    • 11 MB LGA 3647 (Socket P)
    • Processor cores: 8 14 nm 64-bit 130 W
    • Maximum internal memory supported by processor: 1.02 TB DDR4-SDRAM

    Key Applications

    • Enterprise Servers
    • Workstations
    • Data Centers
    • Virtualization
    • Cloud Computing
    • AI and Machine Learning
    • Database Management
    • High Performance Computing
    • Storage Solutions
    • Networking Equipment

    Description

    Intel® Trusted Execution Technology
    Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

    Intel® Virtualization Technology for Directed I/O (VT-d)
    Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

    Intel® Virtualization Technology (VT-x)
    Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

    Intel® 64
    Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

    Cache
    CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

    Intel® AES New Instructions
    Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

    Intel® Turbo Boost Technology
    Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

    Max Turbo Frequency
    Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

    Execute Disable Bit
    Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

    Intel® Hyper-Threading Technology
    Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

    Intel vPro® Platform Eligibility
    The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.

    Intel® VT-x with Extended Page Tables (EPT)
    Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

    Enhanced Intel SpeedStep® Technology
    Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

    Intel® Speed Shift Technology
    Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

    Intel® Deep Learning Boost (Intel® DL Boost) on CPU
    A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

    Instruction Set Extensions
    Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

    Intel® Run Sure Technology
    Intel® Run Sure Technology, includes advanced RAS (reliability, availability and serviceability) features that deliver high reliability and platform resiliency, to maximize uptime of servers running mission-critical workloads.

    Intel® Turbo Boost Max Technology 3.0
    Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

    Max # of UPI Links
    Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI.

    # of AVX-512 FMA Units
    Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.

    Intel® Resource Director Technology (Intel® RDT)
    Intel® RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.

    Intel® Speed Select Technology - Performance Profile
    A capability to configure the processor to run at three distinct operating points.

    Intel® Speed Select Technology - Base Frequency
    Enables users to increase guaranteed base frequency on certain cores (high priority cores) in exchange for lower base frequency on remaining cores (low priority cores). Improves overall performance by boosting frequency on critical cores.

    Intel® Volume Management Device (VMD)
    Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

    Intel® Optane™ Persistent Memory Supported
    Intel® Optane™ persistent memory is a revolutionary tier of non-volatile memory that sits between memory and storage to provide large, affordable memory capacity that is comparable to DRAM performance.  Delivering large system-level memory capacity when combined with traditional DRAM, Intel Optane persistent memory is helping transform critical memory constrained workloads – from cloud, databases, in-memory analytics, virtualization, and content delivery networks.

    Mode-based Execute Control (MBEC)
    Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

    Intel® Transactional Synchronization Extensions
    Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor generation
    • Intel Xeon Scalable 2nd Gen
    Processor model
    • 4215R
    Processor base frequency
    • 3.2
    Processor family
    • Intel Xeon Silver
    Processor cores
    • 8
    Processor socket
    • LGA 3647 (Socket P)
    Component for
    • Server/Workstation
    Processor lithography
    • 14
    Processor threads
    • 16
    Processor operating modes
    • 64-bit
    Processor boost frequency
    • 4
    Processor cache
    • 11
    Thermal Design Power (TDP)
    • 130
    Box
    • No
    Cooler included
    • No
    Processor codename
    • Cascade Lake
    Processor ARK ID
    • 199349
    Memory
    Maximum internal memory supported by processor
    • 1024
    Memory types supported by processor
    • DDR4-SDRAM
    Memory clock speeds supported by processor
    • 2400
    Memory channels
    • Hexa-channel
    ECC
    • Yes
    Graphics
    On-board graphics card
    • No
    Discrete graphics card
    • No
    On-board graphics card model
    • Not available
    Discrete graphics card model
    • Not available
    Features
    Execute Disable Bit
    • Yes
    Market segment
    • Server
    Maximum number of PCI Express lanes
    • 48
    PCI Express slots version
    • 3.0
    Supported instruction sets
    • SSE4.2,AVX,AVX 2.0,AVX-512
    Scalability
    • 2S
    Embedded options available
    • Yes
    PCI Express CEM revision
    • 3.0
    Export Control Classification Number (ECCN)
    • 5A992C
    Commodity Classification Automated Tracking System (CCATS)
    • G077159
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    Enhanced Intel SpeedStep Technology
    • Yes
    Intel Trusted Execution Technology
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Transactional Synchronization Extensions
    • Yes
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Intel Turbo Boost Max Technology 3.0
    • No
    AVX-512 Fused Multiply-Add (FMA) units
    • 1
    Intel® Deep Learning Boost (Intel® DL Boost)
    • Yes
    Intel® Speed Select technology - Performance Profile (Intel® SST-PP)
    • No
    Intel® Resource Director Technology (Intel® RDT)
    • Yes
    Intel® Volume Management Device (VMD)
    • Yes
    Intel® Run Sure Technology
    • No
    Mode-based Execute Control (MBE)
    • Yes
    Intel® Optane™ DC Persistent Memory Supported
    • Yes
    Intel® vPro™ Platform Eligibility
    • Yes
    Intel Speed Select Technology (SST)
    • No
    Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)
    • No
    Intel® Optane™ DC Persistent Memory technology
    • Yes
    Operational conditions
    Tcase
    • 79
    Technical details
    Launch date
    • Q1'20
    Product type
    • Processor
    Status
    • Launched
    Supported memory types
    • DDR4-SDRAM
    Memory speed (max)
    • 2400
    Number of UPI links
    • 2
    Servicing status
    • Baseline Servicing
    Logistics data
    Harmonized System (HS) code
    • 85423119
    Weight & dimensions
    Processor package size
    • 76mm x 56.5mm
    Other features
    Maximum internal memory
    • 1000
