ADL-S Core i5-12500 6C(6P+0E)/12T 3.0G 18MB 65W 770 1700 H0

CM8071504647605
https://safeconsulting.no/web/image/product.template/9392/image_1920?unique=4175d88

kr 2,980.70 2980.7000000000003 NOK kr 2,980.70

kr 2,980.70

Not Available For Sale

    This combination does not exist.

    Summary Description

    Intel Core i5-12500. Processor family: Intel® Core™ i5, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, Workstation, PCI Express slots version: 5.0, 4.0. Package type: Retail box

    Key Features

    • Intel® Core™ i5 i5-12500
    • 18 MB Smart Cache LGA 1700
    • Processor cores: 6 64-bit
    • Maximum internal memory supported by processor: 128 GB DDR4-SDRAM, DDR5-SDRAM
    • On-board graphics card Intel UHD Graphics 770

    Key Applications

    • Desktop computing
    • Professional workstations
    • General purpose applications
    • Office productivity software
    • High-definition media playback
    • Web browsing
    • Virtualization
    • Software development
    • Gaming
    • AI and deep learning

    Description

    Intel® Deep Learning Boost (Intel® DL Boost)
    A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

    Intel® Optane™ Memory Supported
    Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

    Intel® Speed Shift Technology
    Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

    Intel® Turbo Boost Technology
    Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

    Intel® Hyper-Threading Technology
    Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

    Intel® Virtualization Technology (VT-x)
    Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

    Intel® Virtualization Technology for Directed I/O (VT-d)
    Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

    Intel® Virtualization Technology for Directed I/O (VT-d)
    Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

    Intel® VT-x with Extended Page Tables (EPT)
    Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

    Intel® 64
    Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

    Idle States
    Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

    Enhanced Intel SpeedStep® Technology
    Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.

    Thermal Monitoring Technologies
    Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.

    Intel® Volume Management Device (VMD)
    Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

    Intel® AES New Instructions
    Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

    Secure Key
    Intel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.

    Execute Disable Bit
    Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

    Intel® Boot Guard
    Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.

    Mode-based Execute Control (MBE)
    Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

    Intel® Control-Flow Enforcement Technology
    CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor generation
    • Intel Core i5-12xxx
    Processor model
    • i5-12500
    Processor family
    • Intel Core i5
    Processor cores
    • 6
    Processor socket
    • LGA 1700
    Processor threads
    • 12
    Processor operating modes
    • 64-bit
    Performance cores
    • 6
    Processor boost frequency
    • 4.6
    Performance-core boost frequency
    • 4.6
    Performance-core base frequency
    • 3
    Processor cache
    • 18
    Processor cache type
    • Smart Cache
    Box
    • No
    Processor base power
    • 65
    Maximum turbo power
    • 117
    Bus type
    • DMI4
    Maximum number of DMI lanes
    • 8
    Memory bandwidth supported by processor (max)
    • 76.8
    Processor codename
    • Alder Lake
    Processor ARK ID
    • 96144
    Memory
    Maximum internal memory supported by processor
    • 128
    Memory types supported by processor
    • DDR4-SDRAM,DDR5-SDRAM
    Memory channels
    • Dual-channel
    ECC
    • Yes
    Memory bandwidth (max)
    • 76.8
    Graphics
    On-board graphics card
    • Yes
    Discrete graphics card
    • No
    On-board graphics card model
    • Intel UHD Graphics 770
    On-board graphics card outputs supported
    • Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1
    On-board graphics card base frequency
    • 300
    On-board graphics card dynamic frequency (max)
    • 1450
    Number of displays supported (on-board graphics)
    • 4
    On-board graphics card DirectX version
    • 12.0
    On-board graphics card OpenGL version
    • 4.5
    On-board graphics card maximum resolution (DisplayPort)
    • 7680 x 4320
    On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
    • 5120 x 3200
    On-board graphics card maximum resolution (HDMI)
    • 4096 x 2160
    On-board graphics card refresh rate at maximum resolution (DisplayPort)
    • 60
    On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
    • 120
    On-board graphics card refresh rate at maximum resolution (HDMI)
    • 60
    On-board graphics card ID
    • 0x4690
    Discrete graphics card model
    • Not available
    Number of execution units
    • 32
    Multi-Format Codec Engines
    • 2
    Features
    Execute Disable Bit
    • Yes
    Idle States
    • Yes
    Thermal Monitoring Technologies
    • Yes
    Market segment
    • Desktop
    Use conditions
    • PC/Client/Tablet,Workstation
    Maximum number of PCI Express lanes
    • 20
    PCI Express slots version
    • 5.0,4.0
    PCI Express configurations
    • 1x16+1x4,2x8+1x4
    Supported instruction sets
    • SSE4.1,SSE4.2,AVX 2.0
    Scalability
    • 1S
    CPU configuration (max)
    • 1
    Embedded options available
    • No
    Direct Media Interface (DMI) Revision
    • 4.0
    Export Control Classification Number (ECCN)
    • 5A992CN3
    Commodity Classification Automated Tracking System (CCATS)
    • G167599
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® Quick Sync Video Technology
    • Yes
    Intel® Clear Video HD Technology (Intel® CVT HD)
    • Yes
    Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    Enhanced Intel SpeedStep Technology
    • Yes
    Intel Trusted Execution Technology
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Total Memory Encryption
    • Yes
    Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
    • Yes
    Intel® Control-flow Enforcement Technology (CET)
    • Yes
    Intel® Thread Director
    • No
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel® Secure Key
    • Yes
    Intel® Active Management Technology (Intel® AMT)
    • Yes
    Intel Stable Image Platform Program (SIPP)
    • Yes
    Intel® OS Guard
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Intel Turbo Boost Max Technology 3.0
    • No
    Intel® Optane™ Memory Ready
    • Yes
    Intel® Boot Guard
    • Yes
    Intel® Deep Learning Boost (Intel® DL Boost)
    • Yes
    Intel® Volume Management Device (VMD)
    • Yes
    Mode-based Execute Control (MBE)
    • Yes
    Intel® vPro™ Platform Eligibility
    • Yes
    Intel® Standard Manageability (ISM)
    • Yes
    Intel® One-Click Recovery
    • Yes
    Intel® Virtualization Technology with Redirect Protection (VT-rp)
    • Yes
    Intel vPro® Enterprise Platform Eligibility
    • Yes
    Intel® Threat Detection Technology (TDT)
    • Yes
    Intel® Hardware Shield Eligibility
    • Yes
    Intel® Total Memory Encryption - Multi Key
    • Yes
    Intel vPro® Essentials Platform Eligibility
    • Yes
    Operational conditions
    Tjunction
    • 100
    Technical details
    Target market
    • Gaming
    OpenCL version
    • 2.1
    Launch date
    • Q1'22
    Status
    • Launched
    Logistics data
    Harmonized System (HS) code
    • 85423119
    Packaging data
    Package type
    • Retail box
    Weight & dimensions
    Processor package size
    • 45 x 37.5
    Other features
    Maximum internal memory
    • 128
    Graphics output
    • eDP 1.4b, DP 1.4a, HDMI 2.1
