  2. RPL i7-14700 20C(8P+12E)/28T 2.1/1.5G 33M65W 770 1700 B0 10y

RPL i7-14700 20C(8P+12E)/28T 2.1/1.5G 33M65W 770 1700 B0 10y

SKU: CM8071504820817
GTIN (EAN/UPC): 8592978516932
Brand: Intel
https://safeconsulting.no/web/image/product.template/9428/image_1920?unique=fe9739b

kr 5,092.14 5092.14 NOK kr 5,092.14 VAT Excluded

kr 5,092.14 VAT Excluded

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    Intel Core i7-14700. Processor family: Intel® Core™ i7, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: Workstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.4 GHz

    Key Features

    • Intel® Core™ i7 i7-14700
    • 33 MB Smart Cache LGA 1700
    • Processor cores: 20 64-bit
    • Maximum internal memory supported by processor: 192 GB DDR4-SDRAM, DDR5-SDRAM
    • On-board graphics card Intel UHD Graphics 770

    Key Applications

    • High-end desktops
    • Workstations
    • PCs for gaming
    • Content creation
    • Video editing
    • 3D rendering
    • Software development
    • Data analysis
    • Scientific computing
    • Virtualization

    Description

    The Intel Core i7-14700 processor is designed for high performance in desktop applications. Featuring 20 cores and 28 threads, this processor supports dual-channel DDR4 and DDR5 memory types with a maximum memory support of 192 GB. On-board graphics are provided by Intel UHD Graphics 770 with support for multiple display outputs including Embedded DisplayPort 1.4b, DisplayPort 1.4a, and HDMI 2.1. This processor is ideal for workstations, PCs, and tablets, boasting advanced Intel Turbo Boost Max Technology 3.0 with a peak frequency of 5.4 GHz.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor generation
    • Intel Core i7-14xxx
    Processor model
    • i7-14700
    Processor family
    • Intel Core i7
    Processor cores
    • 20
    Processor socket
    • LGA 1700
    Processor threads
    • 28
    Processor operating modes
    • 64-bit
    Performance cores
    • 8
    Efficient cores
    • 12
    Processor boost frequency
    • 5.4
    Performance-core boost frequency
    • 5.3
    Performance-core base frequency
    • 2.1
    Efficient-core boost frequency
    • 4.2
    Efficient-core base frequency
    • 1.5
    Processor cache
    • 33
    Processor cache type
    • Smart Cache
    Box
    • No
    Processor base power
    • 65
    Maximum turbo power
    • 219
    Stepping
    • B0
    Maximum number of DMI lanes
    • 8
    Memory bandwidth supported by processor (max)
    • 89.6
    Processor codename
    • Raptor Lake
    Processor ARK ID
    • 236781
    Memory
    Maximum internal memory supported by processor
    • 192
    Memory types supported by processor
    • DDR4-SDRAM,DDR5-SDRAM
    Memory channels
    • Dual-channel
    ECC
    • Yes
    Memory bandwidth (max)
    • 89.6
    Graphics
    On-board graphics card
    • Yes
    Discrete graphics card
    • No
    On-board graphics card model
    • Intel UHD Graphics 770
    On-board graphics card outputs supported
    • Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1
    On-board graphics card base frequency
    • 300
    On-board graphics card dynamic frequency (max)
    • 1600
    Number of displays supported (on-board graphics)
    • 4
    On-board graphics card DirectX version
    • 12.0
    On-board graphics card OpenGL version
    • 4.5
    On-board graphics card maximum resolution (DisplayPort)
    • 7680 x 4320
    On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
    • 5120 x 3200
    On-board graphics card maximum resolution (HDMI)
    • 4096 x 2160
    On-board graphics card refresh rate at maximum resolution (DisplayPort)
    • 60
    On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
    • 120
    On-board graphics card refresh rate at maximum resolution (HDMI)
    • 60
    On-board graphics card ID
    • 0xA780
    Discrete graphics card model
    • Not available
    Number of execution units
    • 32
    Multi-Format Codec Engines
    • 2
    Features
    Execute Disable Bit
    • Yes
    Idle States
    • Yes
    Thermal Monitoring Technologies
    • Yes
    Market segment
    • Desktop
    Use conditions
    • Workstation,PC/Client/Tablet
    Maximum number of PCI Express lanes
    • 20
    PCI Express slots version
    • 4.0,5.0
    PCI Express configurations
    • 1x16+1x4,2x8+1x4
    Supported instruction sets
    • AVX 2.0,SSE4.1,SSE4.2
    Scalability
    • 1S
    CPU configuration (max)
    • 1
    Embedded options available
    • Yes
    Direct Media Interface (DMI) Revision
    • 4.0
    Export Control Classification Number (ECCN)
    • 5A992C
    Commodity Classification Automated Tracking System (CCATS)
    • 740.17B1
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® Quick Sync Video Technology
    • Yes
    Intel® Clear Video HD Technology (Intel® CVT HD)
    • Yes
    Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    Enhanced Intel SpeedStep Technology
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Turbo Boost Max Technology 3.0 frequency
    • 5.4
    Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
    • Yes
    Intel® Control-flow Enforcement Technology (CET)
    • Yes
    Intel® Thread Director
    • Yes
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel® Secure Key
    • Yes
    Intel® OS Guard
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Intel Turbo Boost Max Technology 3.0
    • Yes
    Intel® Boot Guard
    • Yes
    Intel® Deep Learning Boost (Intel® DL Boost)
    • Yes
    Intel® Volume Management Device (VMD)
    • Yes
    Mode-based Execute Control (MBE)
    • Yes
    Intel® Standard Manageability (ISM)
    • Yes
    Operational conditions
    Tjunction
    • 100
    Technical details
    OpenCL version
    • 3.0
    Launch date
    • Q1'24
    Status
    • Launched
    Logistics data
    Harmonized System (HS) code
    • 8542310001
    Weight & dimensions
    Processor package size
    • 45 x 37.5
    Other features
    L2 cache
    • 28672
    Maximum internal memory
    • 192
    Graphics output
    • eDP 1.4b, DP 1.4a, HDMI 2.1
