  1. All Products
  2. RPL-S i5-14500 14C(6P+8E)/20T 2.6/1.9G 24M65W 770 1700 C0 10

RPL-S i5-14500 14C(6P+8E)/20T 2.6/1.9G 24M65W 770 1700 C0 10

CM8071505093104
https://safeconsulting.no/web/image/product.template/9405/image_1920?unique=2ba5ecc

kr 2,897.31 2897.31 NOK kr 2,897.31

kr 2,897.31

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    Intel Core i5-14500. Processor family: Intel® Core™ i5, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card dynamic frequency (max): 1550 MHz. Market segment: Desktop, Use conditions: Workstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Processor package size: 45 x 37.5 mm

    Key Features

    • Intel® Core™ i5 i5-14500
    • 24 MB Smart Cache LGA 1700
    • Processor cores: 14 64-bit
    • Maximum internal memory supported by processor: 192 GB DDR4-SDRAM, DDR5-SDRAM
    • On-board graphics card Intel UHD Graphics 770

    Key Applications

    • Desktop computing
    • Workstation systems
    • PC/Client usage
    • Tablets
    • High-performance applications
    • Multimedia editing
    • Gaming
    • Office applications
    • Content creation
    • Software development

    Description

    The Intel Core i5-14500 processor features a 24 MB Smart Cache and LGA 1700 socket, making it an excellent choice for desktop systems. It supports dual-channel memory with a maximum internal memory of 192 GB. Integrated with Intel UHD Graphics 770, it offers rich visual performance. This processor is ideal for use in workstations, PCs, and tablets, and supports PCI Express slots versions 4.0 and 5.0. With a package size of 45 x 37.5 mm, it is compact and efficient.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor generation
    • Intel Core i5-14xxx
    Processor model
    • i5-14500
    Processor family
    • Intel Core i5
    Processor cores
    • 14
    Processor socket
    • LGA 1700
    Processor threads
    • 20
    Processor operating modes
    • 64-bit
    Performance cores
    • 6
    Efficient cores
    • 8
    Processor boost frequency
    • 5
    Performance-core boost frequency
    • 5
    Performance-core base frequency
    • 2.6
    Efficient-core boost frequency
    • 3.7
    Efficient-core base frequency
    • 1.9
    Processor cache
    • 24
    Processor cache type
    • Smart Cache
    Box
    • No
    Processor base power
    • 65
    Maximum turbo power
    • 154
    Stepping
    • C0
    Maximum number of DMI lanes
    • 8
    Memory bandwidth supported by processor (max)
    • 76.8
    Processor codename
    • Raptor Lake
    Processor ARK ID
    • 236784
    Memory
    Maximum internal memory supported by processor
    • 192
    Memory types supported by processor
    • DDR4-SDRAM,DDR5-SDRAM
    Memory channels
    • Dual-channel
    ECC
    • Yes
    Memory bandwidth (max)
    • 76.8
    Graphics
    On-board graphics card
    • Yes
    Discrete graphics card
    • No
    On-board graphics card model
    • Intel UHD Graphics 770
    On-board graphics card outputs supported
    • Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1
    On-board graphics card dynamic frequency (max)
    • 1550
    Number of displays supported (on-board graphics)
    • 4
    On-board graphics card DirectX version
    • 12.0
    On-board graphics card OpenGL version
    • 4.5
    On-board graphics card maximum resolution (DisplayPort)
    • 7680 x 4320
    On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
    • 5120 x 3200
    On-board graphics card maximum resolution (HDMI)
    • 4096 x 2160
    On-board graphics card refresh rate at maximum resolution (DisplayPort)
    • 60
    On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
    • 120
    On-board graphics card refresh rate at maximum resolution (HDMI)
    • 60
    On-board graphics card ID
    • 0x4680
    Discrete graphics card model
    • Not available
    Number of execution units
    • 32
    Multi-Format Codec Engines
    • 2
    Features
    Execute Disable Bit
    • Yes
    Idle States
    • Yes
    Thermal Monitoring Technologies
    • Yes
    Market segment
    • Desktop
    Use conditions
    • Workstation,PC/Client/Tablet
    Maximum number of PCI Express lanes
    • 20
    PCI Express slots version
    • 4.0,5.0
    PCI Express configurations
    • 1x16+1x4,2x8+1x4
    Supported instruction sets
    • AVX 2.0,SSE4.1,SSE4.2
    Scalability
    • 1S
    CPU configuration (max)
    • 1
    Embedded options available
    • Yes
    Direct Media Interface (DMI) Revision
    • 4.0
    Export Control Classification Number (ECCN)
    • 5A992C
    Commodity Classification Automated Tracking System (CCATS)
    • 740.17B1
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® Quick Sync Video Technology
    • Yes
    Intel® Clear Video HD Technology (Intel® CVT HD)
    • Yes
    Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    Enhanced Intel SpeedStep Technology
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
    • Yes
    Intel® Control-flow Enforcement Technology (CET)
    • Yes
    Intel® Thread Director
    • Yes
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel® Secure Key
    • Yes
    Intel® OS Guard
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Intel® Boot Guard
    • Yes
    Intel® Deep Learning Boost (Intel® DL Boost)
    • Yes
    Intel® Volume Management Device (VMD)
    • Yes
    Mode-based Execute Control (MBE)
    • Yes
    Intel® Standard Manageability (ISM)
    • Yes
    Operational conditions
    Tjunction
    • 100
    Technical details
    OpenCL version
    • 3.0
    Launch date
    • Q1'24
    Status
    • Launched
    Logistics data
    Harmonized System (HS) code
    • 8542310001
    Weight & dimensions
    Processor package size
    • 45 x 37.5
    Other features
    L2 cache
    • 11776
    Maximum internal memory
    • 192
    Graphics output
    • eDP 1.4b, DP 1.4a, HDMI 2.1
