8-port Unmanaged Ind. Ethernet Switch,Wide Temp.

SKU: EKI-2528I-BE
GTIN (EAN/UPC): 4719879820355
Brand: Advantech
https://safeconsulting.no/web/image/product.template/12874/image_1920?unique=1b7ede1

kr 1,459.26 1459.26 NOK kr 1,459.26 VAT Excluded

kr 1,459.26 VAT Excluded

Not Available For Sale

    This combination does not exist.

    Summary Description

    The EKI-2528I-BE offers robust and compact management with 8 Fast Ethernet ports. It supports a wide operating temperature range and is ideal for industrial applications.

    Key Features

    • 8 Fast Ethernet ports, Auto MDI/MDI-X
    • Supports 10/100 Mbps Auto Negotiation
    • 4,000 VDC Ethernet ESD protection
    • DIN-rail/Wallmount, and IP30 metal mechanism
    • Redundant 12 ~ 48 VDC power input

    Key Applications

    • Industrial Automation
    • Transportation Systems
    • Oil and Gas Communication
    • Energy Management Systems

    Description

    The EKI-2528I-BE is an 8-port unmanaged industrial Ethernet switch designed for high reliability with Auto MDI/MDI-X, broadcast storm protection, and surge protection. It supports wide temperature operations and offers a compact size with multiple mounting options.

    Product Specifications

    Specification Details
    General
    Ethernet Port Count
    • 8
    Mounting
    • DIN, Panel
    Power
    • 12-48VDC
    Technology
    • Ethernet
    Temperature
    • -40 to 75C
    Unmanaged
    • Yes
    Power
    Power Connector Type
    • 6-pin removable screw terminal
    Power Consumption
    • 4.71W
    Power Input (DC)
    • 12 ~ 48 VDC
    Redundant Dual Inputs
    • Yes
    Protection
    Overload Current
    • Present
    Reverse Polarity
    • Present
    Environment
    Operating Temperature
    • -40 ~ 75°C (-40 ~ 167°F)
    Storage Temperature
    • -40 ~ 85°C (-40 ~ 185°F)
    Mechanism
    Dimensions (W x H x D)
    • 30 x 140 x 95 mm (1.18' x 5.51' x 3.74 in.)
    IP Rating
    • IP30
    Mounting (DIN-rail)
    • Yes
    Mounting (Wall)
    • Yes
    Ethernet Communication
    RJ-45 Port Connector Type
    • RJ-45
    RJ-45 Port Number
    • 8
    RJ-45 Transmission Distance
    • 100 m
    RJ-45 Transmission Speed
    • 10/100 Mbps
    Certification
    EMI
    • CE, FCC Class A
    EMS
    • EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8
    Safety
    • UL 60950-1
    Warranty
    Warranty Period
    • 5 years
    Place of Production
    Place of production
    • China
