LinkIT QSFP+ 40Gbps PSM4 10km Cisco

LI-QSFP-PLR4-40G-CIS
https://safeconsulting.no/web/image/product.template/15448/image_1920?unique=37af576

kr 3,057.62 3057.62 NOK kr 3,057.62 VAT Excluded

kr 3,057.62 VAT Excluded

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    High-performance LinkIT QSFP+ module with 40Gbps speed, supporting up to 10km range and single mode operation. Compatible with QSFP MSA and Cisco systems.

    Key Features

    • MPO-12 optical interface
    • Maximum link length up to 10km
    • 10.3125Gb/s data links per lane
    • +3.3 V power supply
    • QSFP MSA compliant package
    • Hot Pluggable
    • High sensitivity PIN/TIA optical receiver
    • BER < 1E-12@-13.6dBm(OMA)

    Key Applications

    • 40G BASE Ethernet
    • Infiniband EDR interconnects
    • Enterprise networking

    Description

    Product Specifications

    Specification Details
    General
    Coding
    • Cisco
    Optical Interface
    • MPO-12
    Maximum Link Length
    • 10km
    Data Links
    • Up to 10.3125Gb/s per lane
    Power Supply
    • +3.3 V
    Compliance
    • QSFP MSA
    Pluggability
    • Hot Pluggable
    Tx Data
    • CML/AC Coupled
    Rx Data
    • CML/AC Coupled
    Performance
    Transmitter
    • High performance single mode DML
    Receiver
    • High sensitivity PIN/TIA
    Operation Mode
    • Single Mode
    BER
    • < 1E-12@-13.6dBm(OMA)
    Operating Conditions
    Case Temperature
    • 0 to 70ºC
    Interfaces
    Control Interfaces
    • ModSelL LVTTL
    • ResetL LVTTL
    • ModPrsL LVTTL
    • LPMode LVTTL
    Communication Bus
    • 2-wire I2C
    Compliance
    RoHS
    • RoHS 6 compliance
