    The Supermicro MBD-X12SDV-8C-SPT4F-O motherboard is a powerful System on Chip solution powered by Intel Xeon Processor D-1736NT. It supports up to 128GB of ECC RDIMM DDR4-2666MT/s in 2 DIMM slots and offers versatile connectivity and expansion options.

    Key Features

    • System on Chip
    • Intel® Xeon® Processor D-1736NT, CPU TDP 67W, Intel Quick Assist Technology
    • Up to 128GB Registered ECC RDIMM, DDR4-2667MHz, in 2 DIMM slots
    • 1 PCIe 4.0 x8
    • 1 OCuLink Connector (4 SATA/PCIe 3.0 x4)
    • 1 M.2 M-Key 2280 (SATA/PCIe 4.0 x4)
    • Dual 25G SFP28 with Intel SoCDual 10Gbase-T RJ-45 with Intel® Ethernet Controller X550-AT2
    • 12V DC or ATX Power Input


    The Supermicro MBD-X12SDV-8C-SPT4F-O is a Mini-ITX motherboard equipped with a high-performance Intel Xeon Processor D-1736NT. This System on Chip solution supports up to 128GB of ECC RDIMM DDR4-2666MT/s, providing exceptional processing power and memory capacity for demanding applications. The motherboard features dual 25G SFP28 and dual 10GBase-T network interfaces, extensive I/O capabilities, and various expansion options including 1 PCIe 4.0 x8 and 1 M.2 M-Key 2280 (SATA/PCIe 4.0 x4). Additionally, it integrates comprehensive management and monitoring features, making it an ideal choice for enterprise-class server systems.

    Product Specifications

    Product SKUs
    Physical Stats
    Form FactorMini-ITX
    Dimension6.75" x 6.75" (17.15cm x 17.15cm)
    CPUIntel® Xeon® Processor D-1736NT
    Single Socket FCBGA-2227 supported, CPU TDP supports Up to 67W TDP
    CoreUp to 8 cores / 15MB Cache
    System Memory
    Memory Capacity2 DIMM slots
    Up to 128GB ECC RDIMM, DDR4-2666MT/s; Up to 128GB ECC/non-ECC , DDR4-2666MT/s
    Memory Type2666/2400 MT/s ECC/non-ECC DDR4 RDIMM
    DIMM SizesRDIMM: 8GB, 16GB, 32GB, 64GB
    UDIMM: 4GB, 8GB, 16GB, 32GB
    Memory Voltage1.2V
    Error DetectionCorrects single-bit errors
    Detects double-bit errors (using ECC memory)
    On-Board Devices
    ChipsetSystem on Chip
    SATASoC controller for 4 SATA3 (6 Gbps) ports; RAID 0,1,5,10
    4 SATA ports via OCuLink (or PCIE3.0 x4 for NVMe)
    Graphics1 Aspeed AST2600 BMC port(s)
    Network ControllersDual LAN with 25G SFP28 LAN via SoC
    Dual LAN with 10GBase-T with Intel® X550
    Input / Output
    LAN2 SFP28 25 Gigabit Ethernet LAN ports
    2 RJ45 10GBase-T ports
    USB2 USB 2 port(s) (2 via header)
    2 USB 3 port(s) (2 rear type A)
    Video Output1 VGA D-Sub Connector port(s)
    Serial Port1 COM Port(s) (1 header)
    TPM1 TPM Header & Chip both
    Expansion Slots
    PCIe1 PCIe 4.0 x8,
    1 PCIe 3.0 x4 (or 4x SATA), via Oculink
    M.2M.2 Interface: 1 SATA/PCIe 4.0 x4
    Form Factor: 2280
    Key: M-Key
    System BIOS
    BIOS FeaturesACPI 6.3
    UEFI 2.7
    SMBIOS 3.3
    Plug and Play (PnP)
    PCI FW 3.0
    SoftwareRedfish API,Supermicro Server Manager (SSM),Supermicro Update Manager (SUM),Supermicro SuperDoctor® 5 (SD5),Super Diagnostics Offline (SDO),KVM with dedicated LAN,IPMI 2.0
    Power ConfigurationsATX Power connector, +12V DC Power Input, CPU thermal trip support for processor protection, Power-on mode for AC power recovery
    PC Health Monitoring
    Voltage3.3V standby, +5V standby, +5V, +3.3V, +12V, Memory Voltages, Monitors CPU Core Voltages
    LEDUID/Remote UID
    BMC/IPMI Heartbeat LED
    Overheat/Fan Fail/PWR Fail LED
    Power Indicator LED
    LAN temperature
    TemperatureMonitoring for CPU and chassis environment
    CPU thermal trip support
    peripheral temperature
    System temperature
    Memory temperature
    NVMe temperature
    Platform Environment Control Interface (PECI)/TSI
    FAN3x 4-pin fan headers (up to 3 fans)
    System level control
    PWM fan speed control
    Fan speed control
    3 fans with tachometer monitoring
    Overheat LED indication
    Other FeaturesUID, RoHS, Node Manager Support, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, 12V DC or ATX Power Source, Intel® QuickAssist Technology
    Operating Environment
    Operating Temperature Range0°C - 60°C (32°F - 140°F)
    Non-Operating Temperature Range-40°C - 85°C (-40°F - 185°F)
    Operating Relative Humidity Range10% - 85% (non-condensing)
    Non Operating Relative Humidity Range10% - 95% (non-condensing)

    Standard Part List

    Bulk Package
    ATX Power Cable
    Part NumberQuantityDescription
    CBL-PWEX-106316CM ATX Power Signal Cable
    I/O Shield
    Part NumberQuantityDescription
    MCP-260-00098-0N1Standard I/O Shield
    Retail Package
    ATX Power Cable
    Part NumberQuantityDescription
    CBL-PWEX-106316CM ATX Power Signal Cable
    COM Cable
    Part NumberQuantityDescription
    CBL-CDAT-06051COM Cable 20cm
    I/O Shield
    Part NumberQuantityDescription
    MCP-260-00098-0N1Standard I/O Shield
    OCuLink to 4x SATA Cable
    Part NumberQuantityDescription
    CBL-SAST-0933150CM OCuLink to 4x SATA Cable
    OCuLink to U.2 Cable
    Part NumberQuantityDescription
    CBL-SAST-0956155CM OCuLink to U.2 Cable with Molex Power Header
    Part NumberQuantityDescription
    MNL-2478-QRG1Motherboard Quick Reference Guide
