ICX 6326 2P 16C/32T 2.9G 24M 11.2GT 185W 4189 M1

P4X-ICX6326-SRKXK
https://safeconsulting.no/web/image/product.template/8834/image_1920?unique=8d6572e

kr 19,297.61 19297.61 NOK kr 19,297.61

kr 19,297.61

Not Available For Sale

    This combination does not exist.

    Summary Description

    Intel Xeon Gold 6326. Processor family: Intel® Xeon® Gold, Processor socket: LGA 4189, Processor lithography: 10 nm. Memory channels: Octa-channel, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512, Scalability: 2S. Maximum Enclave Size Support for Intel® SGX: 64 GB. Processor package size: 77.5 x 56.5 mm

    Key Features

    • Intel® Xeon® Gold 6326 2.9 GHz
    • 24 MB LGA 4189
    • Processor cores: 16 10 nm 64-bit 185 W
    • DDR4-SDRAM

    Key Applications

    • Data Centers
    • Cloud Computing
    • Virtualization
    • Machine Learning
    • High-Performance Computing
    • Enterprise Servers
    • Big Data Analytics
    • Networking
    • AI Workloads
    • Database Management

    Description

    Intel® Trusted Execution Technology
    Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

    Intel® Virtualization Technology for Directed I/O (VT-d)
    Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

    Intel® Virtualization Technology (VT-x)
    Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

    Intel® 64
    Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

    Cache
    CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.

    Intel® AES New Instructions
    Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

    Intel® Turbo Boost Technology
    Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

    Max Turbo Frequency
    Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

    Execute Disable Bit
    Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.

    Intel® Hyper-Threading Technology
    Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

    Intel® VT-x with Extended Page Tables (EPT)
    Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.

    Intel® Speed Shift Technology
    Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

    Intel® Crypto Acceleration
    Intel® Crypto Acceleration reduces the performance impact of pervasive encryption and increases the performance of encryption-intensive workloads including SSL web serving, 5G infrastructure, and VPN/firewalls.

    Intel® Software Guard Extensions (Intel® SGX)
    Intel® Software Guard Extensions (Intel® SGX) provide applications the ability to create hardware enforced trusted execution protection for their applications’ sensitive routines and data. Intel® SGX provides developers a way to partition their code and data into CPU hardened trusted execution environments (TEE’s).

    Intel® Speed Select Technology – Core Power
    Enables flexibility for workloads that benefit from higher base frequency on a subset of the processor’s cores. While the max turbo frequency across the cores remain constant across the cores, a subset of the cores can be assigned as to run at a higher base frequency than specified, while the other cores run at lower base frequency.

    Intel® Speed Select Technology – Turbo Frequency
    Enables flexibility for workloads that benefit from higher turbo frequency on a subset of the processor’s cores. While the base frequency remains constant across the cores, a subset of the cores can be assigned to run at a higher turbo frequency than specified, while the other cores run at lower turbo frequency.

    Intel® Deep Learning Boost (Intel® DL Boost) on CPU
    A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

    Instruction Set Extensions
    Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).

    Intel® Run Sure Technology
    Intel® Run Sure Technology, includes advanced RAS (reliability, availability and serviceability) features that deliver high reliability and platform resiliency, to maximize uptime of servers running mission-critical workloads.

    Intel® Total Memory Encryption
    TME – Total Memory Encryption (TME) helps protect data against exposure via physical attack on memory, such as cold-boot attacks.

    Max # of UPI Links
    Intel® Ultra Path Interconnect (UPI) links are a high speed, point-to-point interconnect bus between the processors, delivering increased bandwidth and performance over Intel® QPI.

    # of AVX-512 FMA Units
    Intel® Advanced Vector Extensions 512 (AVX-512), new instruction set extensions, delivering ultra-wide (512-bit) vector operations capabilities, with up to 2 FMAs (Fused Multiply Add instructions), to accelerate performance for your most demanding computational tasks.

    Intel® Resource Director Technology (Intel® RDT)
    Intel® RDT brings new levels of visibility and control over how shared resources such as last-level cache (LLC) and memory bandwidth are used by applications, virtual machines (VMs) and containers.

    Intel® Speed Select Technology - Base Frequency
    Enables users to increase guaranteed base frequency on certain cores (high priority cores) in exchange for lower base frequency on remaining cores (low priority cores). Improves overall performance by boosting frequency on critical cores.

    Intel® Volume Management Device (VMD)
    Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

    Intel® Optane™ Persistent Memory Supported
    Intel® Optane™ persistent memory is a revolutionary tier of non-volatile memory that sits between memory and storage to provide large, affordable memory capacity that is comparable to DRAM performance.  Delivering large system-level memory capacity when combined with traditional DRAM, Intel Optane persistent memory is helping transform critical memory constrained workloads – from cloud, databases, in-memory analytics, virtualization, and content delivery networks.

    Mode-based Execute Control (MBEC)
    Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.

    Intel® Transactional Synchronization Extensions
    Intel® Transactional Synchronization Extensions (Intel® TSX) are a set of instructions that add hardware transactional memory support to improve performance of multi-threaded software.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor generation
    • Intel Xeon Scalable 3rd Gen
    Processor model
    • 6326
    Processor base frequency
    • 2.9
    Processor family
    • Intel Xeon Gold
    Processor cores
    • 16
    Processor socket
    • LGA 4189
    Component for
    • Server/Workstation
    Processor lithography
    • 10
    Processor series
    • Intel Xeon Gold 6000 Series
    Processor threads
    • 32
    System bus rate
    • 11.2
    Processor operating modes
    • 64-bit
    Processor boost frequency
    • 3.5
    High priority cores
    • 4
    High priority core frequency
    • 3
    Low priority cores
    • 12
    Low priority core frequency
    • 2.6
    Processor cache
    • 24
    Thermal Design Power (TDP)
    • 185
    Box
    • No
    Cooler included
    • No
    Processor codename
    • Ice Lake
    Processor ARK ID
    • 215274
    Memory
    Memory types supported by processor
    • DDR4-SDRAM
    Memory channels
    • Octa-channel
    ECC
    • Yes
    Graphics
    On-board graphics card
    • No
    Discrete graphics card
    • No
    On-board graphics card model
    • Not available
    Discrete graphics card model
    • Not available
    Features
    Execute Disable Bit
    • Yes
    Market segment
    • Server
    Maximum number of PCI Express lanes
    • 64
    PCI Express slots version
    • 4.0
    Supported instruction sets
    • SSE4.2,AVX,AVX 2.0,AVX-512
    Scalability
    • 2S
    Embedded options available
    • Yes
    Export Control Classification Number (ECCN)
    • 5A992CN3
    Commodity Classification Automated Tracking System (CCATS)
    • G178966
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    Intel Trusted Execution Technology
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Transactional Synchronization Extensions
    • Yes
    Intel® Total Memory Encryption
    • Yes
    Intel® Crypto Acceleration
    • Yes
    Intel® Platform Firmware Resilience Support
    • Yes
    Maximum Enclave Size Support for Intel® SGX
    • 64
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel Software Guard Extensions (Intel SGX)
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    AVX-512 Fused Multiply-Add (FMA) units
    • 2
    Intel® Deep Learning Boost (Intel® DL Boost)
    • Yes
    Intel® Resource Director Technology (Intel® RDT)
    • Yes
    Intel® Volume Management Device (VMD)
    • Yes
    Intel® Run Sure Technology
    • Yes
    Mode-based Execute Control (MBE)
    • Yes
    Intel® Optane™ DC Persistent Memory Supported
    • Yes
    Operational conditions
    Tcase
    • 78
    Technical details
    Target market
    • Cloud Computing
    Launch date
    • Q2'21
    Status
    • Launched
    Supported memory types
    • DDR4-SDRAM
    Memory speed (max)
    • 3200
    Number of UPI links
    • 3
    Servicing status
    • Baseline Servicing
    Logistics data
    Harmonized System (HS) code
    • 85423119
    Weight & dimensions
    Processor package size
    • 77.5 x 56.5
    Other features
    Maximum internal memory
    • 6000
