4509Y 2P 8C/2.6G/125W (8/1.9, 4/2.7/105) 22.5M SGX64 DSA 7yr

PK8071305554400
https://safeconsulting.no/web/image/product.template/9502/image_1920?unique=4175d88

kr 7,513.56 7513.56 NOK kr 7,513.56

kr 7,513.56

Not Available For Sale

    This combination does not exist.

    Summary Description

    Intel Xeon Silver 4509Y. Processor family: Intel Xeon Silver, Processor socket: FCLGA4677, Processor manufacturer: Intel. Memory channels: Octa-channel, Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5-SDRAM. Market segment: Server, Use conditions: Server/Enterprise, Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2. Maximum Enclave Size Support for Intel® SGX: 64 GB, Intel® Data Streaming Accelerator (DSA): 1 default devices. Processor package size: 77.5 x 56.5 mm

    Key Features

    • 22.5 MB FCLGA4677
    • Maximum internal memory supported by processor: 4 TB DDR5-SDRAM
    • Intel Xeon Silver 4509Y 2.6 GHz
    • Processor cores: 8 64-bit 125 W

    Key Applications

    • Server operations
    • Enterprise-level deployments
    • High-performance computing
    • Data streaming and encryption
    • Virtualized environments

    Description

    The Intel Xeon Silver 4509Y processor offers a base frequency of 2.6 GHz with a 22.5 MB cache, designed for FCLGA4677 sockets. Featuring eight 64-bit cores and 16 threads, it efficiently supports high-performance server operations. With a thermal design power (TDP) of 125 W, the processor is optimized for robust server tasks, supporting up to 4 TB of DDR5-SDRAM memory across octa-channel configurations. The unit integrates several advanced technologies including Intel® Turbo Boost Technology 2.0, Intel® Hyper-Threading Technology, Intel® AES New Instructions (Intel® AES-NI), and Intel® Data Streaming Accelerator (DSA). Additionally, the processor supports comprehensive virtualization technologies like Intel® VT-x and Intel® VT-d, ensuring optimal performance for virtualized environments. The processor package measures 77.5 x 56.5 mm, suitable for enterprise-level deployments requiring reliable and scalable server solutions.

    Product Specifications

    Specification Details
    Processor
    Processor manufacturer
    • Intel
    Processor generation
    • Intel Xeon Scalable 5th Gen
    Processor model
    • 4509Y
    Processor base frequency
    • 2.6
    Processor family
    • Intel Xeon Silver
    Processor cores
    • 8
    Processor socket
    • FCLGA4677
    Processor threads
    • 16
    Intel® UPI Speed
    • 16
    Processor operating modes
    • 64-bit
    Processor boost frequency
    • 4.1
    Processor cache
    • 22.5
    Thermal Design Power (TDP)
    • 125
    Box
    • No
    Stepping
    • U1
    Processor codename
    • Sapphire Rapids
    Processor ARK ID
    • 236636
    Memory
    Maximum internal memory supported by processor
    • 4000
    Memory types supported by processor
    • DDR5-SDRAM
    Memory clock speeds supported by processor
    • 4400
    Memory channels
    • Octa-channel
    ECC
    • Yes
    Graphics
    On-board graphics card
    • No
    Discrete graphics card
    • No
    On-board graphics card model
    • Not available
    Discrete graphics card model
    • Not available
    Features
    Execute Disable Bit
    • Yes
    Market segment
    • Server
    Use conditions
    • Server/Enterprise
    Maximum number of PCI Express lanes
    • 80
    PCI Express slots version
    • 5.0
    Supported instruction sets
    • AMX,AVX,AVX 2.0,AVX-512,SSE4.2
    Scalability
    • 2S
    Embedded options available
    • Yes
    Export Control Classification Number (ECCN)
    • 5A992C
    Commodity Classification Automated Tracking System (CCATS)
    • 740.17B1
    Processor special features
    Intel® Hyper Threading Technology (Intel® HT Technology)
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    Intel Trusted Execution Technology
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Transactional Synchronization Extensions
    • Yes
    Intel® Total Memory Encryption
    • Yes
    Intel® Control-flow Enforcement Technology (CET)
    • Yes
    Intel® Crypto Acceleration
    • Yes
    Intel® Platform Firmware Resilience Support
    • Yes
    Maximum Enclave Size Support for Intel® SGX
    • 64
    Intel VT-x with Extended Page Tables (EPT)
    • Yes
    Intel® OS Guard
    • Yes
    Intel Software Guard Extensions (Intel SGX)
    • Yes
    Intel 64
    • Yes
    Intel Virtualization Technology (VT-x)
    • Yes
    Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    AVX-512 Fused Multiply-Add (FMA) units
    • 2
    Intel® Boot Guard
    • Yes
    Intel® Deep Learning Boost (Intel® DL Boost)
    • Yes
    Intel® Resource Director Technology (Intel® RDT)
    • Yes
    Intel® Volume Management Device (VMD)
    • Yes
    Mode-based Execute Control (MBE)
    • Yes
    Intel® Total Memory Encryption - Multi Key
    • Yes
    Intel® QuickAssist Software Acceleration
    • Yes
    Intel® On Demand Feature Activation
    • Yes
    Intel® Data Streaming Accelerator (DSA)
    • 1 default devices
    Intel® Advanced Matrix Extensions (AMX)
    • Yes
    Operational conditions
    Tcase
    • 8Pin / 4Pin (12V) Connector
    DTS Max
    • 100
    Technical details
    Launch date
    • Q4'23
    Status
    • Launched
    Number of UPI links
    • 2
    Package carrier
    • E1B
    Servicing status
    • Baseline Servicing
    Logistics data
    Harmonized System (HS) code
    • 8542310001
    Weight & dimensions
    Processor package size
    • 77.5 x 56.5
    Other features
    Maximum internal memory
    • 4000
