6548Y+ 2P 32C2.5G250W(24/2.6/225,16/3/205)60M SGX128 DIQD 7y
PK8072205559700
Summary Description
The Intel® Xeon® Gold 6548Y+ Processor is part of the 5th Generation Intel® Xeon® Scalable Processors. It features 32 cores and 64 threads, with a maximum turbo frequency of 4.1 GHz and a processor base frequency of 2.5 GHz. The processor includes 60 MB of cache, supports up to DDR5 5200 MT/s memory, and offers advanced technologies like Intel® DL Boost and Intel® SST. With robust security features such as Intel® TDX and Intel® SGX, this processor is ideal for server and enterprise use.
Key Features
- Robust security features including Intel® TDX and Intel® SGX
- 80 PCI Express Lanes
- Processor Base Frequency of 2.5 GHz
- Supports up to DDR5 5200 MT/s and 4 TB memory
- 32 total cores and 64 total threads
- Advanced technologies like Intel® DL Boost, Intel® RDT, and Intel® SST
- TDP of 250 W
- 60 MB cache
- Max Turbo Frequency of 4.1 GHz
- Intel® UPI Speed of 20 GT/s with 3 UPI links
Key Applications
- Server applications
- Enterprise workloads
Description
The Intel® Xeon® Gold 6548Y+ Processor is a high-performance processor designed for server and enterprise applications. It boasts 32 total cores and 64 total threads, offering superior multitasking capabilities. With a max turbo frequency of 4.1 GHz and a processor base frequency of 2.5 GHz, it ensures efficient processing for demanding workloads. The processor also features a 60 MB cache, 20 GT/s Intel® UPI Speed with 3 UPI links, and a TDP of 250 W. It supports up to 4 TB of DDR5 memory with speeds up to 5200 MT/s and offers 80 PCI Express lanes for high bandwidth. Advanced technologies like Intel® DL Boost, Intel® RDT, and various Intel® Speed Select Technologies enhance performance further. The robust security suite includes Intel® TDX, Intel® SGX, and Intel® Total Memory Encryption, providing comprehensive protection for critical data.
Product Specifications
| Specification | Details |
|---|---|
| Essentials | |
| Product Collection |
|
| Code Name |
|
| Vertical Segment |
|
| Processor Number |
|
| Lithography |
|
| Recommended Customer Price |
|
| CPU Specifications | |
| Total Cores |
|
| Total Threads |
|
| Max Turbo Frequency |
|
| Processor Base Frequency |
|
| Cache |
|
| Intel® UPI Speed |
|
| Max # of UPI Links |
|
| TDP |
|
| Supplemental Information | |
| Marketing Status |
|
| Launch Date |
|
| Servicing Status |
|
| Embedded Options Available |
|
| Use Conditions |
|
| Memory Specifications | |
| Max Memory Size (dependent on memory type) |
|
| Memory Types |
|
| Max # of Memory Channels |
|
| ECC Memory Supported |
|
| Expansion Options | |
| Scalability |
|
| PCI Express Revision |
|
| Max # of PCI Express Lanes |
|
| Package Specifications | |
| Sockets Supported |
|
| Package Carrier |
|
| DTS Max |
|
| TCASE |
|
| Package Size |
|
| Advanced Technologies | |
| Intel® On Demand Activation Model |
|
| Intel® QuickAssist Technology (QAT) |
|
| Intel® Dynamic Load Balancer (DLB) |
|
| Intel® Data Streaming Accelerator (DSA) |
|
| Intel® In-memory Analytics Accelerator (IAA) |
|
| Intel® Advanced Matrix Extensions (AMX) |
|
| Intel® Speed Select Technology – Core Power |
|
| Intel® Speed Select Technology – Turbo Frequency |
|
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
|
| Intel® Speed Select Technology - Base Frequency |
|
| High Priority Cores |
|
| High Priority Core Frequency |
|
| Low Priority Cores |
|
| Low Priority Core Frequency |
|
| Intel® Resource Director Technology (Intel® RDT) |
|
| Intel® Speed Shift Technology |
|
| Intel® Turbo Boost Technology |
|
| Intel® Hyper-Threading Technology |
|
| Intel® Transactional Synchronization Extensions |
|
| Intel® 64 |
|
| Instruction Set Extensions |
|
| # of AVX-512 FMA Units |
|
| Intel® Volume Management Device (VMD) |
|
| Security & Reliability | |
| Intel® Trust Domain Extensions (Intel® TDX) |
|
| Intel® Crypto Acceleration |
|
| Intel® QuickAssist Software Acceleration |
|
| Intel® Platform Firmware Resilience Support |
|
| Intel® Control-Flow Enforcement Technology |
|
| Intel® Total Memory Encryption - Multi Key |
|
| Intel® Total Memory Encryption |
|
| Intel® AES New Instructions |
|
| Intel® Software Guard Extensions (Intel® SGX) |
|
| Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX |
|
| Intel® OS Guard |
|
| Intel® Trusted Execution Technology |
|
| Execute Disable Bit |
|
| Intel® Boot Guard |
|
| Intel® Run Sure Technology |
|
| Mode-based Execute Control (MBEC) |
|
| Intel® Virtualization Technology (VT-x) |
|
| Intel® Virtualization Technology for Directed I/O (VT-d) |
|
| Intel® VT-x with Extended Page Tables (EPT) |
|
