6544Y 2P 16C/3.6G/270W(12/3.6/225,8/3.9/205)45M SGX128 1xDSA

PK8072205559800
https://safeconsulting.no/web/image/product.template/9516/image_1920?unique=a415753

kr 44,694.04 44694.04 NOK kr 44,694.04

kr 44,694.04

Not Available For Sale

    This combination does not exist.

    Summary Description

    The Intel® Xeon® Gold 6544Y Processor is part of the 5th Generation Intel® Xeon® Scalable Processors. It comes equipped with 16 cores, 32 threads, and a 45M Cache, making it ideal for server and enterprise use. The processor supports Intel® Speed Select Technology and boasts a Max Turbo Frequency of 4.1 GHz. With support for up to 4TB of DDR5 memory, it also includes advanced security features such as Intel® Trust Domain Extensions and Intel® Crypto Acceleration.

    Key Features

    • Supports Intel® Speed Select Technology
    • Processor Base Frequency: 3.6 GHz
    • Max Memory Size: 4 TB
    • TDP: 270 W
    • Intel® UPI Speed: 20 GT/s
    • 45M Cache, 3.60 GHz
    • Memory Types: Up to DDR5 5200 MT/s 1DPC
    • 16 cores and 32 threads
    • Max Turbo Frequency: 4.1 GHz
    • Intel® On Demand Activation Model

    Key Applications

    • Server
    • Enterprise

    Description

    The Intel® Xeon® Gold 6544Y Processor from the 5th Generation Intel® Xeon® Scalable lineup offers a robust set of features designed for high-performance computing. It boasts 16 cores and 32 threads, with a base frequency of 3.6 GHz and a maximum turbo frequency of 4.1 GHz. The processor includes a 45M Cache and supports Intel® UPI Speed of 20 GT/s. With a TDP of 270W, it supports up to 4TB of DDR5 memory across 8 channels. Key technologies include Intel® Speed Select Technology, Intel® Deep Learning Boost, and Intel® Virtualization Technology, making it suitable for a range of server and enterprise applications.

    Product Specifications

    Specification Details
    Essentials
    Product Collection
    • 5th Generation Intel® Xeon® Scalable Processors
    Code Name
    • Products formerly Emerald Rapids
    Vertical Segment
    • Server
    Processor Number
    • 6544Y
    Lithography
    • Intel 7
    Recommended Customer Price
    • $3622.00
    CPU Specifications
    Total Cores
    • 16
    Total Threads
    • 32
    Max Turbo Frequency
    • 4.1 GHz
    Processor Base Frequency
    • 3.6 GHz
    Cache
    • 45 MB
    Intel® UPI Speed
    • 20 GT/s
    Max # of UPI Links
    • 3
    TDP
    • 270 W
    Memory Specifications
    Max Memory Size
    • 4 TB
    Memory Types
    • Up to DDR5 5200 MT/s 1DPC
    Max # of Memory Channels
    • 8
    ECC Memory Supported
    • Yes
    Expansion Options
    Scalability
    • 2S
    PCI Express Revision
    • 5.0
    Max # of PCI Express Lanes
    • 80
    Package Specifications
    Sockets Supported
    • FCLGA4677
    Package Size
    • 77.5mm x 56.5mm
    TCASE
    • 75 °C
    DTS Max
    • 103 °C
    Advanced Technologies
    Intel® On Demand Activation Model
    • Yes
    Intel® Data Streaming Accelerator (DSA)
    • 1 default devices
    Intel® Advanced Matrix Extensions (AMX)
    • Yes
    Intel® Speed Select Technology – Core Power
    • Yes
    Intel® Speed Select Technology – Turbo Frequency
    • Yes
    Intel® Deep Learning Boost (Intel® DL Boost) on CPU
    • Yes
    Intel® Speed Select Technology - Base Frequency
    • Yes
    High Priority Cores
    • 4
    High Priority Core Frequency
    • 3.7 GHz
    Low Priority Cores
    • 12
    Low Priority Core Frequency
    • 3.5 GHz
    Intel® Resource Director Technology (Intel® RDT)
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® Hyper-Threading Technology
    • Yes
    Intel® Transactional Synchronization Extensions
    • Yes
    Intel® 64
    • Yes
    Instruction Set Extensions
    • Intel® AMX, Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
    # of AVX-512 FMA Units
    • 2
    Intel® Volume Management Device (VMD)
    • Yes
    Security & Reliability
    Intel® Trust Domain Extensions (Intel® TDX)
    • Yes
    Intel® Crypto Acceleration
    • Yes
    Intel® QuickAssist Software Acceleration
    • Yes
    Intel® Platform Firmware Resilience Support
    • Yes
    Intel® Control-Flow Enforcement Technology
    • Yes
    Intel® Total Memory Encryption - Multi Key
    • Yes
    Intel® Total Memory Encryption
    • Yes
    Intel® AES New Instructions
    • Yes
    Intel® Software Guard Extensions (Intel® SGX)
    • Yes with Intel® SPS
    Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX
    • 128 GB
    Intel® OS Guard
    • Yes
    Intel® Trusted Execution Technology
    • Yes
    Execute Disable Bit
    • Yes
    Intel® Boot Guard
    • Yes
    Intel® Run Sure Technology
    • Yes
    Mode-based Execute Control (MBEC)
    • Yes
    Intel® Virtualization Technology (VT-x)
    • Yes
    Intel® Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Intel® VT-x with Extended Page Tables (EPT)
    • Yes
