    Summary Description

    The Intel® Xeon® Gold 6548N Processor with 60M Cache and a base frequency of 2.80 GHz is designed for high-performance servers. It supports up to 32 cores and advanced technologies such as Intel® Speed Select and Intel® Turbo Boost.

    Key Features

    • 32 Cores and 64 Threads
    • Max Turbo Frequency: 4.1 GHz
    • TDP: 250 W
    • Supports up to 4 TB of memory
    • Intel® Speed Select Technology

    Description

    The Intel® Xeon® Gold 6548N Processor features a base frequency of 2.80 GHz and 60M Cache. With 32 cores and advanced Intel® technologies, it is ideal for high-performance servers. It includes support for Intel® Speed Select and Intel® Turbo Boost technologies for improved performance.

    Product Specifications

    Specification Details
    Essentials
    Product Collection
    • 5th Gen Intel® Xeon® Scalable Processors
    Code Name
    • Products formerly Emerald Rapids
    Vertical Segment
    • Server
    Processor Number
    • 6548N
    Lithography
    • Intel 7
    Recommended Customer Price
    • $3875.00
    CPU Specifications
    Total Cores
    • 32
    Total Threads
    • 64
    Max Turbo Frequency
    • 4.1 GHz
    Processor Base Frequency
    • 2.8 GHz
    Cache
    • 60 MB
    Intel® UPI Speed
    • 20 GT/s
    Max # of UPI Links
    • 3
    TDP
    • 250 W
    Intel® Speed Select Technology - Performance Profile (Intel® SST-PP)
    6548N (0)Active Cores:
    • 32

    Base Frequency:
    • 2.8

    TDP:
    • 250

    6548N (1)Active Cores:
    • 32

    Base Frequency:
    • 2.6

    TDP:
    • 225

    6548N (2)Active Cores:
    • 32

    Base Frequency:
    • 2.3

    TDP:
    • 205

    Supplemental Information
    Marketing Status
    • Launched
    Launch Date
    • Q4'23
    Servicing Status
    • Baseline Servicing
    Embedded Options Available
    • Yes
    Use Conditions
    • Server/Enterprise
    Memory Specifications
    Max Memory Size
    • 4 TB
    Memory Types
    • Up to DDR5 5200 MT/s 1DPC
    Max # of Memory Channels
    • 8
    ECC Memory Supported
    • Yes
    Expansion Options
    Scalability
    • 2S
    PCI Express Revision
    • 5.0
    Max # of PCI Express Lanes
    • 80
    Package Specifications
    Sockets Supported
    • FCLGA4677
    Package Carrier
    • E1B
    DTS Max
    • 98 °C
    TCASE
    • 8Pin / 4Pin (12V) Connector
    Advanced Technologies
    Intel® On Demand Activation Model
    • Yes
    Intel® QuickAssist Technology (QAT)
    • 2 default devices
    Intel® Dynamic Load Balancer (DLB)
    • 2 default devices
    Intel® Data Streaming Accelerator (DSA)
    • 1 default devices
    Intel® Volume Management Device (VMD)
    • Yes
    Intel® Advanced Matrix Extensions (AMX)
    • Yes
    Intel® Speed Select Technology – Core Power
    • Yes
    Intel® Speed Select Technology – Turbo Frequency
    • Yes
    Intel® Deep Learning Boost (Intel® DL Boost) on CPU
    • Yes
    Intel® Speed Select Technology - Base Frequency
    • Yes
    High Priority Cores
    • 12
    High Priority Core Frequency
    • 3 GHz
    Low Priority Cores
    • 20
    Low Priority Core Frequency
    • 2.6 GHz
    Intel® Resource Director Technology (Intel® RDT)
    • Yes
    Intel® Speed Shift Technology
    • Yes
    Intel® Turbo Boost Technology
    • 2.0
    Intel® Hyper-Threading Technology
    • Yes
    Intel® Transactional Synchronization Extensions
    • Yes
    Intel® 64
    • Yes
    Instruction Set Extensions
    • Intel® AMX, Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
    # of AVX-512 FMA Units
    • 2
    Security & Reliability
    Intel® Trust Domain Extensions (Intel® TDX)
    • Yes
    Intel® Software Guard Extensions (Intel® SGX)
    • Yes with Intel® SPS
    Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX
    • 128 GB
    Intel® Crypto Acceleration
    • Yes
    Intel® QuickAssist Software Acceleration
    • Yes
    Intel® Platform Firmware Resilience Support
    • Yes
    Intel® Control-Flow Enforcement Technology
    • Yes
    Intel® Total Memory Encryption - Multi Key
    • Yes
    Intel® Total Memory Encryption
    • Yes
    Intel® AES New Instructions
    • Yes
    Intel® OS Guard
    • Yes
    Intel® Trusted Execution Technology
    • Yes
    Execute Disable Bit
    • Yes
    Intel® Boot Guard
    • Yes
    Intel® Run Sure Technology
    • Yes
    Mode-based Execute Control (MBEC)
    • Yes
    Intel® Virtualization Technology (VT-x)
    • Yes
    Intel® Virtualization Technology for Directed I/O (VT-d)
    • Yes
    Intel® VT-x with Extended Page Tables (EPT)
    • Yes
