1U AC-DC 800/860W, AC inlet:C14,Titanium efficiency, Input:
PWS-862S-1R
Summary Description
The PWS-862S-1R power supply unit offers robust output power of 860W for both AC and DC inputs across a range of voltages. It ensures reliable and redundant performance, essential for critical systems. With its compact dimensions of 220 mm length, 54.5 mm width, and 40.25 mm height, this unit is adaptable to various configurations. The 12V outputs cater to high current needs, and the 5V Standby offers additional flexibility. Certified with an 80 Plus rating, it promises energy efficiency, while PM Bus 1.2 support ensures seamless management. It weighs only 0.79 Kg, making it easy to handle and install.
Key Features
- +12V: 66.67A, 71.67A, 71.67A
- Dimensions: 220 mm Length, 54.5 mm Width, 40.25 mm Height
- Output: 800W (100 - 127Vac), 860W (200 - 240Vdc), 860W (200 - 240Vac)
- Redundant: Yes
- PM Bus: 1.2
- Weight: 0.79 Kg
- 80 Plus: Yes
- 5V Standby: 4A
Key Applications
- Servers
- Workstations
- High-performance computing
- Data Centers
- Network Switches
- Industrial Equipment
Description
The PWS-862S-1R power supply unit delivers exceptional performance with an output range of 800W (100 - 127Vac) to 860W (200 - 240Vac and 200 - 240Vdc). It supports redundant operation, ensuring uninterrupted power supply during critical operations. The unit measures 220 mm in length, 54.5 mm in width, and 40.25 mm in height, allowing it to fit seamlessly into various configurations. It features multiple +12V outputs (66.67A, 71.67A, 71.67A) to cater to high current requirements, along with a 5V standby offering 4A. The PWS-862S-1R is 80 Plus certified, ensuring high energy efficiency. The inclusion of PM Bus 1.2 support enhances its management capabilities. Despite its robust features, the unit is lightweight, weighing only 0.79 Kg.
Product Specifications
| Specification | Details |
|---|---|
| Dimensions | |
| length |
|
| width |
|
| height |
|
| Voltages | |
| +12V |
|
| 5V_standby |
|
| Weight | |
| |
| General | |
| Part_number |
|
| Output_power |
|
| Redundant |
|
| 80_plus_certified |
|
| Pm_bus |
|
