  2. [NR]X14DBHM + CSE-DC101, CloudDC DC-MHS FLW DP Intel 1U 12 B

[NR]X14DBHM + CSE-DC101, CloudDC DC-MHS FLW DP Intel 1U 12 B

SYS-122C-TN

For this server, it's best to contact us for a fully validated, configured model. You can also add desired components to your cart, select "pay by bank transfer" at checkout, and we'll try to fulfill your wishes. We'll configure your system as closely as possible and send an updated quote with a validated system shortly. You can then decide if you want this configuration. The final payment method will be agreed upon after you accept the configuration.

https://safeconsulting.no/web/image/product.template/15839/image_1920?unique=e0abd13

kr 21,700.79 21700.79 NOK kr 21,700.79 VAT Excluded

kr 21,700.79 VAT Excluded

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    This high-performance server is tailored for networking appliances and cloud solutions, featuring dual Intel Xeon processors. It supports comprehensive storage options and advanced security measures, ensuring optimal power and management flexibility with modern data center support.

    Key Features

    • Designed for Data Center Modular Hardware Systems (DC-MHS) to simplify CSP deployments and serviceability
    • Optimized power & balanced performance for cloud applications
    • Server management flexibility with OpenBMC

    Key Applications

    • Networking Appliance
    • Data Center Optimized, Value IaaS
    • Cloud Computing
    • HPC, Data Center
    • Private & Hybrid Cloud
    • Cloud Solution Provider (CSP)

    Description

    The Supermicro SuperServer SYS-122C-TN is built for cloud computing and data center environments. It supports dual Intel Xeon processors with up to 288 cores and 216 threads, providing balanced power for demanding workloads. Designed for CSP deployments, it is equipped with OpenBMC for flexible server management. The 1U rackmount chassis includes 12 NVMe/SAS/SATA drive bays and integrates optimized cooling with 8 heavy-duty fans.

    Product Specifications

    Specification Details
    Product SKUs
    SKUs
    • SuperServer SYS-122C-TN
    Motherboard
    Installed Motherboard
    • Super X14DBHM
    Processor
    CPU
    • Dual Socket E2 (LGA-4710)
    • Intel® Xeon® 6700 series processors with E-cores
    Core Count
    • Up to 144C/144T; Up to 108MB Cache per CPU
    Note
    • Supports up to 270W TDP CPUs (Air Cooled)
    GPU
    Max GPU Count
    • Up to 3 single-width GPUs
    System Memory
    Memory
    • Slot Count: 32 DIMM slots
    • Max Memory (1DPC): Up to 2TB 6400MT/s ECC DDR5 RDIMM
    • Max Memory (2DPC): Up to 4TB 5200MT/s ECC DDR5 RDIMM
    Memory Voltage
    • 1.1V
    On-Board Devices
    NVMe
    • NVMe; RAID 0/1/5/10 support(VROC HW key required)
    Chipset
    • System on Chip
    Network Connectivity
    • Via AIOM
    Input / Output
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port
    USB
    • 1 USB 2.0 Type-A port(Rear)
    • 1 USB 3.2 Gen1 Type-A port(Rear)
    Video
    • 1 VGA port(Rear)
    TPM
    • 1 TPM header
    System BIOS
    BIOS Type
    • AMI 64MB SPI Flash ROM
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    Chassis
    Form Factor
    • 1U Rackmount
    Model
    • CSE-DC101TS-R000NP
    Dimensions and Weight
    Height
    • 1.7" (43.6 mm)
    Width
    • 17.2" (438.4 mm)
    Depth
    • 29.7" (755.1 mm)
    Package
    • 7.28" (H) x 22.83" (W) x 42.5" (D)
    Weight
    • Gross Weight: 41 lbs (19 kg)
    • Net Weight: 31 lbs (17 kg)
    Palletized Packing (W x H x L)
    • 49.6" (1260 mm) x 4.7" (120 mm) x 44.5" (1130 mm)
    Available Color
    • Silver
    Front Panel
    LED
    • HDD activity
    • LAN1 activity
    • LAN2 activity
    • Power Fail LED
    • Power status
    • System information
    Buttons
    • Power On/Off
    • UID button
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 2 PCIe 5.0 x16 LP slots
    • 1 PCIe 5.0 x8 LP slot
    • 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 12 bays:
    • 12 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays

    • (*NVMe/SAS/SATA support may require additional storage controller and/or cables)
    M.2
    • 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 22110(default)/2280; VROC required for RAID)
    System Cooling
    Fans
    • 8x 4cm heavy duty fans with optimal fan speed control
    Air Shroud
    • 2 Air Shrouds
    Power Supply
    2x 1000W Redundant (1 + 1) Titanium Level (96%) power supplies
    Dimension (WxHxL):
    • 73.5 x 40 x 185 mm

    Input:
    • 800W: 100-127Vac / 50-60Hz
    • 1000W: 200-240Vac / 50-60Hz

    +12V:
    • Max: 66.7A (100Vac-127Vac)
    • Max: A (100Vdc-240Vdc)
    • Max: 83A (200Vac-240Vac)

    12V SB:
    • Max: 2.1A

    Output Type:
    • Backplanes (gold finger)

    Certification:
    • Titanium Level

    Operating Environment
    ROHS
    • RoHS Compliant
    Environmental Spec.
    • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature: -30°C to 60°C (-30°F to 140°F)
    • Operating Relative Humidity: 8% to 80% (Non-Condensing)
    • Non-operating Relative Humidity: 8% to 90% (Non-Condensing)

    Optional Part List

    Part Number Quantity Description
    3808 HBA Card
    AOC-S3808L-L8IT1Standard LP 8 internal ports (12Gb/s) Gen-4 16HDD HBA
    3816 HBA Card
    AOC-S3816L-L16IT1Standard LP 16 internal ports (12Gb/s) Gen-4 122HDD HBA
    3908 RAID Card
    AOC-S3908L-H8IR-16DD1Standard LP 8 internal ports (12Gb/s) Gen-4 122HDD RAID 0, 1, 5, 6, 10, 50, 60
    3908/3916 CacheVault
    BTR-CVPM051CacheVault for Broadcom 3908/3916 (requires a mount)
    3916 RAID Card
    AOC-S3916L-H16IR-32DD1Standard LP 16 internal ports (12Gb/s) Gen-4, 32HDD RAID 0, 1, 5, 6, 10, 50, 60
    AIOM Network Card
    AOC-ATGC-i2TG-OCP 3.0 AIOM 2x 10GbE RJ45 PCIe 3.0 x4 Intel® X710-AT2
    AOC-ATG-i4SG-OCP 3.0 AIOM 4x 10GbE SFP+ PCIe 3.0 x8 Intel® XL710-BM1
    AOC-ATG-b2TG-OCP 3.0 AIOM 2x 10GbE RJ45 PCIe 3.0 x4 Broadcom® BCM57416
    AOC-AG-i4G-OCP 3.0 AIOM 4x 1GbE RJ45 PCIe 2.1 x4 Intel® i350-AM4
    AOC-AG-i2G-OCP 3.0 AIOM 2x 1GbE RJ45 PCIe 2.1 x4 Intel® i350-AM2
    AOC-A25G-i4SG-OCP 3.0 AIOM 4x 25GbE SFP28 PCIe x8 Intel® E810-CAM1
    AOC-A25G-b2SG-OCP 3.0 AIOM 2x 25GbE SFP28 PCIe x8 Broadcom® BCM57414
    AOC-A100G-b2CG-OCP 3.0 AIOM 2x 100GbE QSFP28 PCIe 4.0 x16 Broadcom® BCM57508
    CacheVault Mount
    MCP-240-00203-0N1CacheVault mounting bracket for PCIe slot
    MCP-240-21747-0N1CacheVault mounting card for AIOM slot
    MCP-240-00127-0N1CacheVault mounting tray for 2.5" drive bay
    License
    SFT-SDDC-SINGLE1Supermicro Data Center Monitor License
    SFT-DCMS-SINGLE1Supermicro System Managment Software License
    M.2 Tray
    AOC-SLG4-2H8M2-Standard LP PCIe x8 supporting 2 PCIe 4.0 x4 M-Key M.2 NVMe/SATA Modules RAID 0, 1
    NC-SI Cable
    CBL-PWEX-1099-341FLAT IDC 2X11F/P1.27 TO IDC 2X11F/P1.27 NCSI 0.5A 35CM
    VROC HW Key
    AOC-VROCSTNMOD1Intel VROC Standard RAID 0, 1, 10
    AOC-VROCPREMOD1Intel VROC Premium RAID 0, 1, 5, 10
