  2. 4U X13 Liquid cooled HGX H100 8GPU, X13DEG-M, CSE-GP401

4U X13 Liquid cooled HGX H100 8GPU, X13DEG-M, CSE-GP401

SYS-421GE-TNHR2-LCC

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with Minimum 2 CPUs and 1 Storage Device HDD/HDS/M.2, and 1 NIC).

For this server, it's best to contact us for a fully validated, configured model. You can also add desired components to your cart, select "pay by bank transfer" at checkout, and we'll try to fulfill your wishes. We'll configure your system as closely as possible and send an updated quote with a validated system shortly. You can then decide if you want this configuration. The final payment method will be agreed upon after you accept the configuration.

https://safeconsulting.no/web/image/product.template/10318/image_1920?unique=a1dbe1e

kr 274,596.37 274596.37 NOK kr 274,596.37

kr 274,596.37

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    The Supermicro SYS-421GE-TNHR2-LCC is designed for extreme performance and versatility. Featuring dual 5th/4th Gen Intel® Xeon® Scalable processors, support for up to 8 GPUs, 8TB of DDR5 memory, and flexible networking, this server is ideal for AI, HPC, and industrial automation applications.

    Key Features

    • 5th/4th Gen Intel®  Xeon® Scalable processor support
    • 32 DIMM slots Up to 8TB: 32x 256 GB DRAM Memory Type: 5600MTs ECC DDR5
    • 8 PCIe Gen 5.0 X16 LP2 PCIe Gen 5.0 X16 FHHL Slots, 2 PCIe Gen 5.0 X16 FHHL Slots (optional)
    • Flexible networking options
    • 2 M.2 NVMe for boot drive onlyOptional: 8x 2.5" Hot-swap  SATA drive bays8x 2.5" Hot-swap  NVMe drive bays
    • 4 heavy duty fans with optimal fan speed control
    • 4x 5250W(2+2) Redundant Power Supplies, Titanium Level

    Key Applications

    • High Performance Computing
    • AI/Deep Learning Training
    • Industrial Automation, Retail
    • Healthcare
    • Conversational AI
    • Business Intelligence & Analytics
    • Drug Discovery
    • Climate and Weather Modeling
    • Finance & Economics

    Description

    The Supermicro SYS-421GE-TNHR2-LCC is a high-performance 4U rackmount server designed to meet the needs of the most demanding applications such as AI, HPC, and industrial automation. Equipped with dual 5th/4th Gen Intel® Xeon® Scalable processors, it supports up to 8TB of DDR5 memory and 8 NVIDIA GPUs. With flexible networking options, robust security features, and comprehensive management tools, it provides unparalleled performance and reliability.

    Product Specifications

    Specification Details
    Product SKUs
    SKUs
    • SuperServer SYS-421GE-TNHR2-LCC
    Motherboard
    Installed Motherboard
    • Super X13DEG-M
    Processor
    CPU
    • Dual Socket E (LGA-4677)
    • 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
    • Supports Intel Xeon CPU Max Series with high bandwidth memory (HBM)​
    Core Count
    • 64C/128T; 320MB Cache per CPU
    Note
    • Supports up to 385W TDP CPUs (Liquid Cooled)​
    GPU
    Max GPU Count
    • Up to 8 onboard GPUs
    Supported GPU
    • NVIDIA SXM: HGX H100 8-GPU (80GB), HGX H200 8-GPU (141GB)
    CPU-GPU Interconnect
    • PCIe 5.0 x16 CPU-to-GPU Interconnect
    GPU-GPU Interconnect
    • NVIDIA® NVLink® with NVSwitch™
    System Memory
    Memory
    • Slot Count: 32 DIMM slots
    • Max Memory (1DPC): 4TB 5600MT/s ECC DDR5 RDIMM
    • Max Memory (2DPC): 8TB 4400MT/s ECC DDR5 RDIMM
    On-Board Devices
    Chipset
    • Intel® C741
    Network Connectivity
    • 2 SFP28 25GbE with Broadcom® BCM57414 (optional)
    • 2 RJ45 10GbE with Intel® X710-AT2 (optional)
    Input / Output
    Video
    • 1 VGA port(s)
    System BIOS
    BIOS Type
    • AMI 32MB SPI Flash EEPROM
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • Power-on mode for AC power recovery
    • ACPI Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    PC Health Monitoring
    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory
    • 8+4 Phase-switching voltage regulator
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors
    Chassis
    Form Factor
    • 4U Rackmount
    Model
    • CSE-GP401TS-R000NP
    Dimensions and Weight
    Height
    • 6.85" (174 mm)
    Width
    • 17.7" (449 mm)
    Depth
    • 33.2" (842 mm)
    Package
    • 13" (H) x 48" (W) x 26.4" (D)
    Weight
    • Gross Weight: 138.89 lbs (63 kg)
    • Net Weight: 80.03 lbs (53 kg)
    Available Color
    • Silver
    Front Panel
    Buttons
    • UID button
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 8 PCIe 5.0 x16 LP slots
    • 2 PCIe 5.0 x16 FHHL slots

    Option A:
    • 8 PCIe 5.0 x16 LP slots
    • 4 PCIe 5.0 x16 FHHL slots

    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 8 bays:
    • 8 front hot-swap 2.5" NVMe drive bays

    M.2
    • 2 M.2 NVMe slots (M-key)
    System Cooling
    Fans
    • 4 Fan 8cm Fan(s)
    Liquid Cooling
    • Direct to Chip (D2C) Cold Plate (optional)
    Power Supply
    4x 5250W Redundant Titanium (certification pending) Level (96%) power supplies
    Dimension (WxHxL):
    • 106.5 x 82.1 x 245.3 mm

    AC Input:
    • 5250W: 200-240Vac / 50-60Hz

    +12V:
    • Max: 125A / Min: 0A (200Vac-240Vac)

    Output Type:
    • Backplanes (gold finger)

    Certification:
    • Titanium (certification pending) Level

    Operating Environment
    Environmental Spec.
    • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity: 8% to 90% (non-condensing)
    • Non-operating Relative Humidity: 5% to 95% (non-condensing)

    Optional Part List

    Part Number Quantity Description
    Side expention sets
    AOM-GP401-SW-P1NIC adaptor board with Switch for 4U Liquid-Cool GPU Sys
    AOM-GP401-PCIE-P1NIC IO board for 4U Liquid-Cool GPU System,RoHS
    CBL-PWEX-1142-301MicroHi,(2x4 to 2x4),PH3.0,30CM,8A/pin,18AWG,RoHS
    CBL-CDAT-0923A-401I2C, (1x6F to 1x6F)/PH2.0,40CM,24AWG,2A/p,RoHS
    CBL-MCIO-1419M5FXLC4-E12 MCIOx8 (STR to STR),LtF,FOLD,19cm,32AWG,RoHS
