High-End Desktop (C9X299-PGF, CSE-GS5A-754K)

SYS-5039AD-I

For this server, it's best to contact us for a fully validated, configured model. You can also add desired components to your cart, select "pay by bank transfer" at checkout, and we'll try to fulfill your wishes. We'll configure your system as closely as possible and send an updated quote with a validated system shortly. You can then decide if you want this configuration. The final payment method will be agreed upon after you accept the configuration.

https://safeconsulting.no/web/image/product.template/2120/image_1920?unique=1caa98b

kr 9,156.27 9156.27 NOK kr 9,156.27

kr 9,156.27

Not Available For Sale

    This combination does not exist.

    Summary Description

    The Supermicro SYS-5039AD-I workstation provides an advanced processing platform with the Intel® X299 chipset, supporting up to 256GB of DDR4 memory and multiple expansion slots for demanding applications in various fields.

    Key Features

    • Single Socket R4 supports Intel® Core™ i9/i7/i5 X-Series, and Intel® Core™ i9 Extreme X-Series Processors 2. Intel® X299 chipset 3. Up to 256GB Non-ECC UDIMM, DDR4-2666MHz, in 8 DIMM slots 4. 4 PCI-E 3.0 x16; 1 PCI-E 3.0 x1, 2 M.2 M key with Intel® Optane™ support, and 2 U.2 5. 6 SATA3 (6 Gbps) ports; RAID 0, 1, 5, 10 6. 5G LAN and 1GbE LAN 7. 6 fixed 3.5" and 4 fixed 2.5" drive bays 2 standard 5.25" drive bays 8. 1 VGA, ALC 1220 7.1 HD Audio 9. 2x 12cm front cooling fan; 1x 12cm rear exhaust fan 10. 750W Multi-output Power Supply
    • Single Socket R4 supports Intel® Core™ i9/i7/i5 X-Series, and Intel® Core™ i9 Extreme X-Series Processors
    • Intel® X299 chipset
    • Up to 256GB Non-ECC UDIMM, DDR4-2666MHz, in 8 DIMM slots
    • 4 PCI-E 3.0 x16; 1 PCI-E 3.0 x1, 2 M.2 M key with Intel® Optane™ support, and 2 U.2
    • 6 SATA3 (6 Gbps) ports; RAID 0, 1, 5, 10
    • 5G LAN and 1GbE LAN
    • 6 fixed 3.5" and 4 fixed 2.5" drive bays 2 standard 5.25" drive bays
    • 1 VGA, ALC 1220 7.1 HD Audio
    • 2x 12cm front cooling fan; 1x 12cm rear exhaust fan
    • 750W Multi-output Power Supply

    Description

    The Supermicro SYS-5039AD-I workstation leverages the Intel® Core™ i9/i7/i5 X-Series processors, delivering high performance for complex computational tasks. This workstation supports up to 256GB DDR4-2666MHz memory across eight DIMM slots. The Intel® X299 chipset ensures robust connectivity and data transfer rates, complemented by multiple PCIe 3.0 slots and M.2 interfaces with Intel® Optane™ support. The system also offers diverse storage options including 6 SATA3 ports with RAID configurations and numerous drive bays. Featuring comprehensive cooling through front and rear fans and a 750W power supply, the SYS-5039AD-I workstation is designed for reliability and efficiency in professional environments.

    Product Specifications

    Product SKUs
    SuperWorkstationSYS-5039AD-I (Black)
    Motherboard
    Super C9X299-PGFSuper C9X299-PGF
    Super C9X299-PGF
    Processor/Cache
    CPUSingle socket R4 (LGA 2066) supported, CPU TDP support up to 165W
    Intel® Core™ i9/i7/i5 X-Series, and Intel® Core™ i9 Extreme X-Series Processors (Skylake-X/Cascade Lake-X)
    System Memory
    Memory Capacity8x 288-pin DDR4 DIMM slots
    Supports up to 256GB DDR4 Non-ECC Un-Buffered memory (UDIMM)
    Memory Type2666/2400/2133/1866/1600MHz Non-ECC DDR4 288-pin UDIMM
    DIMM Sizes32GB, 16GB, 8GB, 4GB
    Memory Voltage1.2V
    On-Board Devices
    ChipsetIntel® X299 Chipset
    SATASATA3 via PCH w/ RAID 0, 1, 5, 10
    IPMIASPEED AST2500
    Network ControllersSingle LAN with Intel® Ethernet Controller I210-AT, shared IPMI port
    Single LAN with Aquantia 5G LAN chip AQC108
    AudioALC 1220 7.1 HD Audio
    Input / Output
    SATA6 SATA3 (6Gbps) ports
    LAN2 RJ45 Gigabit Ethernet LAN ports
    USB4 USB 3.0 ports (2 rear + 2 front)
    4 USB 3.1 ports (rear, 3 Type A + 1 Type C)
    Display1 VGA port
    Serial Port / Header1 COM Port (1 header)
    Expansion Slots
    PCI-Express4 PCI-E 3.0 x16 slots
    1 PCI-E 3.0 x1 slot
    *** 4 PCI-E 3.0 x16 slots (8/NA/16/16 or 8/8/8/16 or NA/4/8/16 (Skylake-X 28 Lanes/Cascade-X 48 Lanes) or NA/4/4/8 (Kabylake-X), 1 PCI-E 3.0 x1 slot ***
    M.2M.2 Interface: 2 PCI-E 3.0 x4
    Form Factor:slot1: 22110/2280, slot2: 2280
    Key: M-Key (RAID 0, 1 support)
    M-Key for SSD and Optane
    U.2U.2 Interface: PCI-E 3.0 x4 (Skylake-X/Cascade-X)
    System BIOS
    BIOS TypeUEFI 128Mb
    BIOS FeaturesACPI 3.0 or later
    SMBIOS 2.7 or later
    BIOS rescue hot-key
    SPI dual/quad speed support
    Overclock support
    Chassis
    Form FactorMid-Tower
    ModelCSE-GS5A-754K
    Dimensions and Weight
    Height18.1" (460mm)
    Width7.9" (201mm)
    Depth19.4" (493mm)
    Package24.9" (H) x 14.2" (W) x 24.0" (D)
    WeightNet Weight: 22.27 lbs (10.1 kg)
    Gross Weight: 28.22 lbs (12.8 kg)
    Available ColorsBlack
    Front Panel
    ButtonsPower On/Off Button
    Reset Button
    LEDsPower LED
    Hard drive activity LED
    Ports2 USB 3.0 ports
    1 Earphone, 1 Microphone port
    Drive Bays
    Fixed6 fixed 3.5" drive bays
    4 fixed 2.5" drive bays
    Peripheral2 standard 5.25" drive bays
    System Cooling
    Fans2x 12cm front cooling fans
    1x 12cm rear exhaust fan
    Power Supply
    750W Multi-output Power Supply for Desktop, semi-modular cable output750W Multi-output Power Supply for Desktop, semi-modular cable output
    AC Input100-240Vac, 50-60Hz
    +5VMax: 20A & Min: 0A
    +12VMax: 62A & Min: 0.1A (100Vac-240Vac)
    +3.3VMax: 20A & Min: 0A
    +5V SBMax: 2.5A & Min: 0A
    -12VMax: 0.3A
    Certification
    Gold Certified
    Gold Certified
    PC Health Monitoring
    Voltage+12V, +3.3V, +5V, 1.05 (PCH), 1.2V (VDIMM), 3.3V standby, Chassis intrusion header, Monitors CPU voltages, VBAT
    FAN5x 4-pin fan headers (up to 5 fans), Fan speed control, Overheat LED indication, PWM fan speed control, Thermal control tachometer fan connectors
    Other FeaturesACPI power management, ATX Power connector, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Intel Smart Response Technology, Voltage and Frequency Overclocking, WOL
    Operating Environment / Compliance
    RoHSRoHS Compliant
    Environmental Spec.Operating Temperature:10°C to 35°C (50°F to 95°F)
    Non-operating Temperature:-40°C to 70°C (-40°F to 158°F)
    Operating Relative Humidity:8% to 90% (non-condensing)
    Non-operating Relative Humidity:5% to 95% (non-condensing)

    Standard Part List

    Motherboard / Chassis
    Part NumberQuantityDescription
    MBD-C9X299-PGF1Super C9X299-PGF Motherboard
    CSE-GS5A-754K13U Mid-Tower Chassis
    Cable 1
    Part NumberQuantityDescription
    CBL-0044L2SATA,INT,FLAT,57.7CM,26AWG
    Manual
    Part NumberQuantityDescription
    MNL-2000-QRG15039AD-I Quick Reference Guide
    Parts
    Part NumberQuantityDescription
    MCP-260-00117-0N1-
    Power Supply
    Part NumberQuantityDescription
    PWS-754-PQ1SSR-750FX 750W Muli-output-output PS with modular cable

    Optional Part List

    Heat Sink
    Part NumberQuantityDescription
    SNK-P0050AP4-Active CPU Heat Sink
    Heat Sink(CPU TDP >= 165W)
    Part NumberQuantityDescription
    SNK-P3017A-Liquid Cooling Module w/ a 3-pin Pump Connector for SYS-5038AD-I and SYS-5039AD-T
    Cable(for 2.5" NVMe drives)
    Part NumberQuantityDescription
    CBL-SAST-0957-Mini SAS HD to PCIe SFF-8639 w/ Power, 55CM, 45CM, 34 AWG,RoHs
    Intel VROC Standard
    Part NumberQuantityDescription
    AOC-VROCSTNMOD-Intel VROC Upgrade Module Standard supports RAID 0/1/10
    Intel VROC Premium
    Part NumberQuantityDescription
    AOC-VROCPREMOD-Intel VROC Premium Module Premium supports RAID 0/1/10/5
    Intel VROC
    Part NumberQuantityDescription
    AOC-VROCINTMOD-Intel VROC Upgrade Module for Intel SSD only, RAID 0/1/10/5
    DVD-ROM & Cables
    Part NumberQuantityDescription
    DVM-LTE-DVDRW24-HBT-Black LITE-ON 5.25" HH 24X DVD-RW SATA drive PBF
    CBL-0082L-Y split, big 4-pin to two RA SATA power extension 15cm, 18AWG
    CBL-SAST-0624-SATA, INT, ROUND, ST-ST, 70cm, 30AWG
