  2. X13 5U 4GPU,X13DEG-QT-P,759TS-R2K21BP,RoHS

X13 5U 4GPU,X13DEG-QT-P,759TS-R2K21BP,RoHS

SYS-751GE-TNRT

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with Minimum 2 CPUs, 2 DIMMs, 2 GPUs, and 1 Storage device )

For this server, it's best to contact us for a fully validated, configured model. You can also add desired components to your cart, select "pay by bank transfer" at checkout, and we'll try to fulfill your wishes. We'll configure your system as closely as possible and send an updated quote with a validated system shortly. You can then decide if you want this configuration. The final payment method will be agreed upon after you accept the configuration.

https://safeconsulting.no/web/image/product.template/10492/image_1920?unique=a1dbe1e

kr 240,616.51 240616.51 NOK kr 240,616.51

kr 240,616.51

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    The Supermicro SYS-751GE-TNRT is designed to accelerate AI development and high-performance computing with its acoustically optimized design, dual-socket Intel Xeon processors, and support for up to four liquid-cooled GPUs. Ideal for engineering/scientific research and AI/deep learning training.

    Key Features

    • Acoustically optimized for quiet operation
    • 5th/4th Gen Intel® Xeon® Scalable processor support
    • Intel® C741 Chipset
    • 6 PCIe 5.0 x16
    • 8x 2.5" peripheral drive baysUp to 8x NVMe SSD support
    • Closed-loop liquid cooling for CPUs and GPUs
    • Supports up to four liquid-cooled GPUs

    Key Applications

    • High Performance Computing
    • Engineering/scientific research
    • AI/Deep Learning Training

    Description

    The Supermicro SYS-751GE-TNRT Liquid-Cooled Tower/5U Rackmount AI GPU Workstation revolutionizes AI development with unparalleled performance and versatility. Equipped with 5th/4th Gen Intel Xeon Scalable processors and a robust Intel C741 chipset, this workstation supports up to 64 cores per CPU, intricate PCIe configurations, and extensive memory capacity. All while maintaining acoustic efficiency, making it suitable for any environment, from data centers to home offices. It supports up to 4 liquid-cooled NVIDIA A100 GPUs, ensuring seamless AI, HPC, and scientific research applications.

    Product Specifications

    Specification Details
    Product SKUs
    SKUs
    • SuperWorkstation SYS-751GE-TNRT
    Motherboard
    Installed Motherboard
    • Super X13DEG-QT
    Processor
    CPU
    • Dual Socket E (LGA-4677)
    • 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
    Core Count
    • Up to 64C/128T; Up to 320MB Cache per CPU
    Note
    • Supports up to 350W TDP CPUs (Liquid Cooled)​
    GPU
    Max GPU Count
    • Up to 4 double-width GPUs
    Supported GPU
    • NVIDIA PCIe: A100
    CPU-GPU Interconnect
    • PCIe 4.0 x16 CPU-to-GPU Interconnect
    GPU-GPU Interconnect
    • NVIDIA® NVLink® Bridge (optional)
    System Memory
    Memory
    • Slot Count: 16 DIMM slots
    • Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM
    Memory Voltage
    • 1.1V
    On-Board Devices
    SATA
    • SATA (6Gbps) ; RAID 0/1/5/10 support
    Chipset
    • Intel® C741
    Network Connectivity
    • 2 RJ45 10GbE with Intel® X550-AT2
    • 1 RJ45 1GbE with ASPEED AST2600
    • 1 SFP28 25GbE (optional)
    Input / Output
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port(s)
    • 2 RJ45 10 GbE LAN port(s)
    USB
    • 2 USB 3.2 Gen1 port(s) (front)
    • 3 USB 3.2 Gen1 port(s) (rear)
    • 1 USB 3.2 Gen2 port(s) (rear)
    Video
    • 1 VGA port(s)
    DOM
    • 2 SATA DOM (Disk on Module) port(s)
    Audio
    • 7.1 HD Audio
    • Line Out
    • Mic in
    System BIOS
    BIOS Type
    • AMI 32MB SPI Flash EEPROM
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • ACPI/APM Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    • System Lockdown
    PC Health Monitoring
    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory
    • 8+4 Phase-switching voltage regulator
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors
    Chassis
    Form Factor
    • Tower or 5U Rackmount
    Model
    • CSE-759TS-R2K21BP
    Dimensions and Weight
    Height
    • 8.6" (218.4 mm)
    Width
    • 17.9" (454.7 mm)
    Depth
    • 27.6" (701 mm)
    Package
    • 25.8" (H) x 15.3" (W) x 37.6" (D)
    Weight
    • Gross Weight: 121 lbs (55 kg)
    • Net Weight: 88 lbs (44 kg)
    Available Color
    • Black Front & Black Body
    Front Panel
    LED
    • HDD activity LED
    • Information LED
    • Network 1 activity LED
    • Network 2 activity LED
    • Power status LED
    Buttons
    • Power On/Off button
    • Reset button
    Expansion Slots
    PCI-Express (PCIe) Configuration
    Default:
    • 6 PCIe 5.0 x16 FHFL slots

    Drive Bays / Storage
    Drive Bays Configuration
    Default: Total 8 bays:
    • 8 front hot-swap 2.5" NVMe/SAS*/SATA drive bays

    • (*SAS support may require additional storage controller and/or cables, please see the optional parts list for details)
    M.2
    • 2 M.2 NVMe slots (M-key 2280/22110)
    System Cooling
    Fans
    • 1 fan 8cm Fan(s)
    • 2 fan 12cm Fan(s)
    • 1 liquid cooling Fan(s)
    Liquid Cooling
    • Direct to Chip (D2C) Cold Plate (optional)
    Power Supply
    1x 2200W Redundant Titanium Level (96%) power supply
    Dimension (WxHxL):
    • 106.5 x 82.1 x 203.5 mm

    AC Input:
    • 1200W: 100-127Vac / 50-60Hz
    • 1800W: 200-220Vac / 50-60Hz
    • 1980W: 220-230Vac / 50-60Hz
    • 2200W: 220-240Vac / 50-60Hz (For UL/cUL Only)
    • 2090W: 230-240Vac / 50-60Hz
    • 2090W: 230-240Vdc / 50-60Hz (for CQC only)

    +12V:
    • Max: 100A / Min: 0A (100Vac-127Vac)
    • Max: 150A / Min: 0A (200Vac-220Vac)
    • Max: 165A / Min: 0A (220Vac-230Vac)
    • Max: 183.33A / Min: 0A (220Vac-240Vac) (for UL/cUL only)
    • Max: 174.17A / Min: 0A (230Vac-240Vac)

    12V SB:
    • Max: 3A / Min: 0A

    Output Type:
    • Backplanes (gold finger)

    Operating Environment
    Environmental Spec.
    • Operating Temperature: 10°C ~ 25°C (50°F ~ 77°F)
    • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity: 8% to 90% (non-condensing)
    • Non-operating Relative Humidity: 5% to 95% (non-condensing)

    Optional Part List

    Part Number Quantity Description
    Optional rack mount rail set
    MCP-290-00057-0N1Rail set, quick/quick, default for 4U 17.2" W
    Optional Storage Controller Card + Cable(s)
    AOC-S3908L-H8IR-16DD-O18 int 12Gb/s ports, x8 Gen4, ROC - LP, 16 HDD w/ exp,RoHS
    CBL-SAST-1281-1001Slimline x8 (STR) to 2x Slimline x4 (STR),80CM,100 OHM
