  2. FatTwin RIO 4U 8-Node DP;X12DPFR-AN6;CSE-F418BC3-R2K20BP

FatTwin RIO 4U 8-Node DP;X12DPFR-AN6;CSE-F418BC3-R2K20BP

SYS-F610P2-RTN

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with Minimum 1 CPUs, 4 DIMMs and one drive) per node. Single populated nodes support up to 270W and double populated support up to 185W.

For this server, it's best to contact us for a fully validated, configured model. You can also add desired components to your cart, select "pay by bank transfer" at checkout, and we'll try to fulfill your wishes. We'll configure your system as closely as possible and send an updated quote with a validated system shortly. You can then decide if you want this configuration. The final payment method will be agreed upon after you accept the configuration.

https://safeconsulting.no/web/image/product.template/10479/image_1920?unique=f7d9088

kr 150,139.11 150139.11000000002 NOK kr 150,139.11

kr 150,139.11

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    Supermicro SYS-F610P2-RTN combines dual-socket scalability with extensive storage and AIOM support, designed to meet the needs of modern data centers, virtualization, HPC, and hyperconverged infrastructures.

    Key Features

    • Socket P+(LGA 4189) Supports 3rd Generation Intel® Scalable Processors (Dual Socket)
    • Two M.2 Internal Drives
    • NVMe/SATA/SAS options
    • AIOM and M.2 support; 1 AIOM card support (PCIe 4.0)
    • Front access node for better serviceability; 6x 2.5” hot-swap HDDs per nodeUp to 6x SAS/SATA/NVMe Hot Swap 2.5” Drives

    Key Applications

    • Hyperscale / Hyperconverged
    • HPC and Big Data
    • Data Center Enterprise Applications
    • Scale-Out Storage
    • Virtualization Server
    • Telco Data Center

    Description

    The Supermicro SYS-F610P2-RTN is a 4U rackmount system designed for high performance and versatility. It supports dual 3rd Gen Intel® Xeon® Scalable processors with up to 36 cores per socket, 16 DIMM slots for up to 2TB of DDR4 memory, and Intel® Optane™ persistent memory 200 series. The system includes extensive network and storage options, such as two M.2 internal drives, AIOM and M.2 support, and six hot-swap 2.5-inch drive bays. Security is ensured with TPM 2.0 and Silicon Root of Trust compliant with NIST 800-193.

    Product Specifications

    Specification Details
    Product SKUs
    SKUs
    • SuperServer SYS-F610P2-RTN
    Motherboard
    Installed Motherboard
    • Super X12DPFR-AN6
    Processor (per Node)
    CPU
    • Dual Socket P+ (LGA-4189)
    • 3rd Gen Intel® Xeon® Scalable processors
    Core Count
    • Up to 36C/72T; Up to 54MB Cache per CPU
    Note
    • Supports up to 185W TDP CPUs (Air Cooled)
    System Memory (per Node)
    Memory
    • Slot Count: 16 DIMM slots
    • Max Memory (2DPC): Up to 2TB non-ECC DDR4
    • Supports Intel® Optane™ persistent memory 200 series
    On-Board Devices (per Node)
    Chipset
    • Intel® C621A
    Network Connectivity
    • 1 RJ45 1GbE
    Input / Output (per Node)
    LAN
    • 1 RJ45 1 GbE Dedicated BMC LAN port(s)
    USB
    • 2 USB 3.0 port(s) (rear)
    Video
    • 1 VGA port(s)
    System BIOS
    BIOS Type
    • AMI 32MB SPI FLASH ROM
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor® 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • ACPI/APM Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Cryptographically Signed Firmware
    • Secure Boot
    • Secure Firmware Updates
    • Automatic Firmware Recovery
    • System Lockdown
    PC Health Monitoring
    CPU
    • 4+1 Phase-switching voltage regulator
    • Monitors for CPU Cores, Chipset Voltages, Memory.
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    Chassis
    Form Factor
    • 4U
    Model
    • CSE-F418BC3-R2K20BP
    Dimensions and Weight
    Height
    • 6.96" (177 mm)
    Width
    • 17.63" (448 mm)
    Depth
    • 29" (737 mm)
    Package
    • 15" (H) x 28.3" (W) x 42.4" (D)
    Weight
    • Gross Weight: 200 lbs (90.71 kg)
    • Net Weight: 150 lbs (68.04 kg)
    Available Color
    • Silver
    Front Panel
    LED
    • HDD activity LED
    • Network activity LEDs
    • Power status LED
    • Universal Information (UID) LED
    Buttons
    • Power On/Off button
    • UID button
    Expansion Slots (per Node)
    PCI-Express (PCIe) Configuration
    Default:
    • 1 PCIe 4.0 x16 LP slot
    • 1 PCIe 4.0 x16 AIOM slot (OCP 3.0 compatible)

    Drive Bays / Storage (per Node)
    Drive Bays Configuration
    Default: Total 6 bays:
    • 6 front hot-swap 2.5" NVMe/SAS/SATA drive bays

    M.2
    System Cooling
    Fans
    • 3x 4cm Fan(s)
    Power Supply
    1x 2200W Redundant Titanium Level (96%) power supply
    Dimension (WxHxL):
    • 76 x 40 x 336 mm

    AC Input:
    • 1200W: 100-127Vac / 50-60Hz
    • 1800W: 200-220Vac / 50-60Hz
    • 2090W: 200-220Vac / 50-60Hz (for UL/cUL use only)
    • 1980W: 220-230Vac / 50-60Hz
    • 2200W: 220-240Vac / 50-60Hz (for UL/cUL use only)
    • 2090W: 230-240Vac / 50-60Hz
    • 2090W: 230-240Vdc / 50-60Hz (for CCC only)

    +12V:
    • Max: 100A / Min: 0A (100Vac-127Vac)
    • Max: 150A / Min: 0A (200Vac-220Vac)
    • Max: 165A / Min: 0A (220Vac-230Vac)
    • Max: 183.33A / Min: 0A (220Vac-240Vac) (for UL/cUL only)
    • Max: 174.17A / Min: 0A (230Vac-240Vac)
    • Max: 174.17A / Min: 0A (230Vdc-240Vdc) (for CCC only)
    • Max: 174.17A / Min: 0A (230Vac-240Vac) (for UL/cUL only)

    5V SB:
    • Max: 1A / Min: 0A

    Output Type:
    • Backplanes (gold finger)

    Operating Environment
    ROHS
    • RoHS Compliant
    Environmental Spec.
    • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity: 5% to 95% (8)
    • Non-operating Relative Humidity: 90% to 5% (95)

    Optional Part List

    Part Number Quantity Description
    Component
    BTR-CV3908-FT1-SuperCap for 3908 with bracket and 24in extension cable
    AOC-SMG4-2M2-F-2x M.2 NVMe carrier card (NO SATA)
    CBL-SAST-1223-85-Supports up to 2 NVMe drives for 1U systems.
    CBL-KIT-FRI10-NVME4-Supports up to 4 NVMe drives. For 1U systems.
    CBL-KIT-FRI10-NVME6-Supports up to 6 NVMe. For 1U systems.
    SCC-KIT-FRB10-3808-Supports 3808 SW/HBA RAID w/ cables. For 1U systems.
    AOC-KIT-FRB10-3908-Supports 3908 HW RAID w/ cables. For 1U systems.
    MCP-220-00178-0B-2.5” thin profile drive tray, Orange tab (for hotswap NVMe drive)
