3.5" QVGA, TI AM3517 600MHz,256MB with WinCE 6.0

SKU: TPC-31T-E3AE
GTIN (EAN/UPC): 4719896001768
Brand: Advantech
https://safeconsulting.no/web/image/product.template/13092/image_1920?unique=0d8b02a

kr 4,419.07 4419.07 NOK kr 4,419.07 VAT Excluded

kr 4,419.07 VAT Excluded

Not Available For Sale

    This combination does not exist.

    Summary Description

    Advantech TPC-31T-E3AE. Display diagonal: 8.89 cm (3.5"), Display resolution: 320 x 240 pixels, Display technology: LCD. Product colour: Silver, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Power consumption (typical): 8 W. Width: 120.8 mm, Depth: 26.5 mm, Height: 85.5 mm. Windows operating systems supported: Windows CE

    Key Features

    • Compact 3.5" TFT LCD Display
    • Low Power TI Cortex-A8 Processor
    • Supports 10/100Base-T Ethernet
    • Includes Windows CE OS
    • Open HMI Solution for Integration
    • Cost-effective for Small Applications
    • High Brightness: 450 cd/m²
    • Resistive Touchscreen Technology
    • Wide Operating Temperature Range
    • Communication-friendly Design

    Key Applications

    • Industrial Human Machine Interfaces
    • Small-sized Operator Interfaces
    • Embedded System Integration
    • High-temperature Environments
    • Energy-efficient Display Panels
    • Ethernet-connected Devices
    • Cost-sensitive Control Systems

    Description

    The TPC-31T model is a compact platform without redundant functions, and has been designed for small-sized operator interface applications. It has a 3.5" TFT LCD display which is a cost effective choice for a limited budget. Its RISC kernel, the TI Cortex-A8 processor consumes minimum power without sacrificing performance. The TPC-31T/61T has a 10/100Base-T Ethernet port offering solid communication ability and comes bundled with a Windows® CE OS that supports Thin-Client solutions. The built-in Windows CE OS platform lets the TPC-31T/61T become an Open HMI solution for system integration.

    Product Specifications

    Specification Details
    Display
    Display diagonal
    • 3.5
    Display technology
    • LCD
    LED backlight
    • Yes
    Display resolution
    • 320 x 240
    Display brightness
    • 450
    Touchscreen technology
    • Resistive
    Contrast ratio
    • 300:1
    Viewing angle, horizontal
    • 120
    Viewing angle, vertical
    • 110
    Performance
    Ethernet LAN
    • Yes
    Ethernet LAN data rates
    • 10,100
    Cabling technology
    • 10/100Base-T(X)
    Internal memory
    • 256
    Product colour
    • Silver
    Ports & interfaces
    USB 2.0 Type-A ports quantity
    • 1
    Power
    Power consumption (typical)
    • 8
    Weight & dimensions
    Width
    • 120.79
    Depth
    • 26.5
    Height
    • 85.5
    Weight
    • 0.25
    Operational conditions
    Operating relative humidity (H-H)
    • 10 - 95
    Operating temperature (T-T)
    • 0 - 50
    Storage temperature (T-T)
    • -20 - 60
    Other features
    Windows operating systems supported
    • Windows CE
