Ethernet to Single mode fiber media converter

SKU: EKI-2541S-AE
Brand: Advantech
https://safeconsulting.no/web/image/product.template/13149/image_1920?unique=b6a1da3

kr 2 939,96 2939.96 NOK kr 2 939,96 Ekskl. mva

kr 2 939,96 Ekskl. mva

Not Available For Sale

    Denne kombinasjonen eksisterer ikke.

    Kontakt oss

    Salgsbetingelser

    Beskrivelsesammendrag

    The media converter converts Ethernet to single-mode fiber, supporting distances up to 30 km. It is housed in a durable IP30 metal case and operates from -40 to 75°C, perfect for industrial settings.

    Nøkkelfunksjoner

    • Converts Ethernet to Single-Mode Fiber
    • Supports Fiber Distances Up to 30 km
    • Wide Operating Temp: -40 to 75°C
    • Compact IP30 Metal Enclosure
    • Auto-Negotiation for Easy Setup
    • Dual Redundant Power Inputs
    • Advanced Surge Protection
    • DIN Rail and Wall Mount Options
    • Supports 10/100 Mbps Ethernet
    • LED Indicators for Quick Status

    Viktige bruksområder

    • Industrial Automation Networks
    • Remote Monitoring Systems
    • Traffic Management Solutions
    • Utility and Energy Applications
    • Environmental Monitoring
    • Oil and Gas Industry Communication
    • Transport and Safety Systems
    • Video Surveillance Extensions
    • Telecommunication Infrastructures
    • Military and Defense Communications

    Beskrivelse

    The Ethernet to Single-Mode Fiber Media Converter transforms a 10/100 Mbps Ethernet signal into a 100 Mbps single-mode fiber optic signal, extending data communication up to 30 km. The device features a robust IP30 metal enclosure, supports wide operating temperatures from -40 to 75°C for industrial applications, and includes dual redundant power inputs to ensure continuous operation. Ideal for harsh environments, it offers advanced network management with features like auto-negotiation, surge protection, and multiple DIP switch configurations.

    Produktspesifikasjoner

    Specification Details
    Connectivity
    Ethernet Port
    • 1 x 10/100 Mbps RJ45 Connector
    Fiber Port
    • 1 x 100 Mbps Single-Mode SC-Type
    Transmission
    DistanceEthernet:
    • Up to 100 m

    Fiber (Single-Mode):
    • Up to 30 km

    Speed
    • Up to 100 Mbps
    Power Supply
    Input Voltage
    • 12 ~ 48 VDC, Redundant Dual Inputs
    Consumption
    • Max 2.7 W
    ProtectionsReverse Power:
    • True

    Overload Current:
    • True

    Environmental
    Operating Temperature
    • -10 ~ 60°C (Standard), -40 ~ 75°C (Wide Temp Model)
    Storage Temperature
    • -40 ~ 85°C
    HumidityOperating:
    • 5 ~ 95% RH (Non-condensing)

    Storage:
    • 0 ~ 95% RH (Non-condensing)

    Certifications
    Safety
    • UL 60950-1
    • CAN/CSA-C22.2 No.60950
    EMI
    • FCC Part 15 Subpart B Class A
    • EN 55022 Class A
    EMS
    • EN 61000-4-2
    • EN 61000-4-3
    • EN 61000-4-4
    • EN 61000-4-5
    • EN 61000-4-6
    • EN 61000-4-8
    MechanicalDimensions:
    • 30 x 140 x 95 mm

    Enclosure:
    • IP30, Metal Shell with Solid Mounting

    Protection:
    • Shock IEC 60068-2-27
    • Freefall IEC 60068-2-32
    • Vibration IEC 60068-2-6
