Ethernet to Single mode fiber media converter

SKU: EKI-2541S-AE
Brand: Advantech
https://safeconsulting.no/web/image/product.template/13149/image_1920?unique=7297a8c

kr 2,939.96 2939.96 NOK kr 2,939.96 VAT Excluded

kr 2,939.96 VAT Excluded

Not Available For Sale

    This combination does not exist.

    Contact Us

    Terms and Conditions

    Summary Description

    The media converter converts Ethernet to single-mode fiber, supporting distances up to 30 km. It is housed in a durable IP30 metal case and operates from -40 to 75°C, perfect for industrial settings.

    Key Features

    • Converts Ethernet to Single-Mode Fiber
    • Supports Fiber Distances Up to 30 km
    • Wide Operating Temp: -40 to 75°C
    • Compact IP30 Metal Enclosure
    • Auto-Negotiation for Easy Setup
    • Dual Redundant Power Inputs
    • Advanced Surge Protection
    • DIN Rail and Wall Mount Options
    • Supports 10/100 Mbps Ethernet
    • LED Indicators for Quick Status

    Key Applications

    • Industrial Automation Networks
    • Remote Monitoring Systems
    • Traffic Management Solutions
    • Utility and Energy Applications
    • Environmental Monitoring
    • Oil and Gas Industry Communication
    • Transport and Safety Systems
    • Video Surveillance Extensions
    • Telecommunication Infrastructures
    • Military and Defense Communications

    Description

    The Ethernet to Single-Mode Fiber Media Converter transforms a 10/100 Mbps Ethernet signal into a 100 Mbps single-mode fiber optic signal, extending data communication up to 30 km. The device features a robust IP30 metal enclosure, supports wide operating temperatures from -40 to 75°C for industrial applications, and includes dual redundant power inputs to ensure continuous operation. Ideal for harsh environments, it offers advanced network management with features like auto-negotiation, surge protection, and multiple DIP switch configurations.

    Product Specifications

    Specification Details
    Connectivity
    Ethernet Port
    • 1 x 10/100 Mbps RJ45 Connector
    Fiber Port
    • 1 x 100 Mbps Single-Mode SC-Type
    Transmission
    DistanceEthernet:
    • Up to 100 m

    Fiber (Single-Mode):
    • Up to 30 km

    Speed
    • Up to 100 Mbps
    Power Supply
    Input Voltage
    • 12 ~ 48 VDC, Redundant Dual Inputs
    Consumption
    • Max 2.7 W
    ProtectionsReverse Power:
    • True

    Overload Current:
    • True

    Environmental
    Operating Temperature
    • -10 ~ 60°C (Standard), -40 ~ 75°C (Wide Temp Model)
    Storage Temperature
    • -40 ~ 85°C
    HumidityOperating:
    • 5 ~ 95% RH (Non-condensing)

    Storage:
    • 0 ~ 95% RH (Non-condensing)

    Certifications
    Safety
    • UL 60950-1
    • CAN/CSA-C22.2 No.60950
    EMI
    • FCC Part 15 Subpart B Class A
    • EN 55022 Class A
    EMS
    • EN 61000-4-2
    • EN 61000-4-3
    • EN 61000-4-4
    • EN 61000-4-5
    • EN 61000-4-6
    • EN 61000-4-8
    MechanicalDimensions:
    • 30 x 140 x 95 mm

    Enclosure:
    • IP30, Metal Shell with Solid Mounting

    Protection:
    • Shock IEC 60068-2-27
    • Freefall IEC 60068-2-32
    • Vibration IEC 60068-2-6
