X12 Dual Node SBB 90-bay Storage Server

SKU:

SSG-640SP-DE2CR90

Brand:

Supermicro

Produktnotat:

Complete System Only: To maintain quality and integrity, this product is sold only as a completely-assembled system (with Minimum 4 CPUs, 4 DIMMs, 2 Storage Devices and 2 Server-Grade M.2/internal SATA SSD)

For denne serveren er det best å kontakte oss for å få en fullstendig validert og konfigurert modell. Du kan også legge ønskede komponenter i handlekurven, velge «betal via bankoverføring» ved utsjekk, så forsøker vi å imøtekomme dine ønsker. Vi vil konfigurere systemet ditt så nøyaktig som mulig og sende deg et oppdatert tilbud med et validert system om kort tid. Deretter kan du bestemme om du ønsker denne konfigurasjonen. Den endelige betalingsmetoden avtales når du har akseptert konfigurasjonen.

kr 147 678,57 147678.57 NOK kr 147 678,57 Ekskl. mva

kr 147 678,57 Ekskl. mva

Denne kombinasjonen eksisterer ikke.

Legg i handlekurv

Salgsbetingelser

Beskrivelsesammendrag

The Supermicro SSG-640SP-DE2CR90 is a powerful and versatile 4U rackmount storage server, designed to meet the rigorous demands of Big Data, AI/ML, Telco, and Cloud Service Providers. With dual socket 3rd Gen Intel Xeon Scalable processors and support for up to 4TB of ECC DDR4 memory, this server offers unmatched performance and reliability.

Nøkkelfunksjoner

Dual socket 3rd Gen Intel® Xeon® Scalable processors, up to 72 Cores Per Node
16 ECC DDR4-3200: LRDIMM/RDIMM
3 x PCIe 4.0 x16 HHHL PCIe slots
90 3.5"/2.5" Hot-swap SAS3 drives, 2x Fixed slim SATA SSD, 2x NVMe M.2 (form factor: 2280 and 22110)
6x 8cm hot-swap counter-rotate redundant PWM cooling fans
2600W Redundant Power Supplies Titanium Level (96%)
Server remote management: IPMI 2.0 / KVM over LAN / Media over LANHBA Controller support via Broadcom® 3616
Dedicated node to node connectivity featuring high performance NTB PCIe 4.0 x16 , 1G private Ethernet, and IPMI for robust node fail-over support

Viktige bruksområder

Big Data & Analytics, Data Lake
HPC and AI/ML Workloads
Telco & Cloud Service Providers
Financial Services & Healthcare Image Archives
Content Repositories
Government Data Protection

Beskrivelse

The Supermicro SSG-640SP-DE2CR90 is the ultimate solution for organizations requiring superior performance and reliability. Featuring dual socket 3rd Gen Intel Xeon Scalable processors, up to 4TB ECC DDR4 memory, and 90 hot-swap SAS3 drive bays, this 4U rackmount server is optimized for Big Data, AI/ML, Telco, and cloud services. Key features include advanced system management, redundant titanium level power supplies, and robust security measures. Ideal for data-intensive environments such as financial services, healthcare, content repositories, and government data protection.

Produktspesifikasjoner

Specification	Details
Product SKUs
SKUs	SuperServer SSG-640SP-DE2CR90
Motherboard
Installed Motherboard	Super X12DSC-6
Processor (per Node)
CPU	Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors
Core Count	Up to 36C/72T; Up to 54MB Cache per CPU
Note	Supports 120W - 205W TDP CPUs (Air Cooled)
System Memory (per Node)
Memory	Slot Count: 16 DIMM slots Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
Memory Voltage	1.2V
On-Board Devices (per Node)
Chipset	Intel® C621A
Network Connectivity	2 RJ45 10GBASE-T
Input / Output (per Node)
LAN	1 RJ45 1 GbE Dedicated BMC LAN port(s) 2 RJ45 10 GBASE-T LAN port(s)
USB	2 USB 3.0 port(s) (rear)
Video	1 VGA port(s)
DOM	2 Super DOM (Disk on Module) port(s)
System BIOS
BIOS Type	AMI 128MB SPI Flash EEPROM
Management
Software	SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New!
Power configurations	Power-on mode for AC power recovery ACPI Power Management
Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery System Lockdown
PC Health Monitoring
CPU	Monitors for CPU Cores, Chipset Voltages, Memory 4+1 Phase-switching voltage regulator
FAN	Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
Chassis
Form Factor	4U Rackmount
Model	CSV-947HTS-R2K63P
Dimensions and Weight
Height	7"
Width	17.6"
Depth	42.1"
Package	29.92" (H) x 35.82" (W) x 53.15" (D)
Weight	Gross Weight: 240 lbs (108.86 kg) Net Weight: 150 lbs (68.04 kg)
Available Color	Black
Expansion Slots (per Node)
PCI-Express (PCIe) Configuration	Default: 3 PCIe 4.0 x16 LP slots
Drive Bays / Storage (per Node)
Drive Bays Configuration	Default: Total 92 bays: 90 top-loading hot-swap 3.5"/2.5" SAS/SATA drive bays 2 top-loading fixed 2.5" SATA drive bays
M.2	1 M.2 NVMe slot (M-key)
System Cooling
Fans	6 Heavy Duty 8cm Fan(s)
Power Supply
2x 2600W Redundant Titanium Level (96%) Hot-plug power supplies	Dimension (WxHxL): 73.5 x 40 x 265 mm AC Input: 2600W: 200-240Vac / 50-60Hz 2600W: 200-240Vdc / 50-60Hz (for CQC only) +12V: Max: 216A / Min: 0A (200Vac-240Vac) 12V SB: Max: 3.5A Output Type: Backplanes (gold finger)
Operating Environment
ROHS	RoHS Compliant
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (Non-Condensing) Non-operating Relative Humidity: 5% to 95% (Non-Condensing)

Valgfrie Opsjoner

Part Number	Quantity	Description
Network Cards
AOC-S25G-M2S	-	Standard LP, 2x 25GbE SFP28, Mellanox ConnectX-4 LX EN
AOC-S40G-I2Q	-	Standard LP 2-port 40GbE controller, Intel Fortville XL710
AOC-SGP-I2	-	Standard LP 2-port GbE, Intel 82575
More	-	AOC Compatibility Matrix (Select Storage & Generation)
TPM
AOM-TPM-9670V-O	1	TPM 2.0, vertical form factor, provisioned for server
AOM-TPM-9671V-O	1	TPM 1.2, vertical form factor, provisioned for server
